The TLL122 is a user adjustable vertical float switch. This float switch can be tailored by the user to suit a particular application, by adjusting the length of the float switch tube. It is also possible to select the switching sense by inverting the float, giving either open on rise or close on rise operation. Mounting is via the 1 in. NPT header.
Note: The unit is supplied partly assembled, with detailed instructions for the user to complete assembly to the specifications of the application and to install the unit.
Specifications
- Model: TLL122-N500
- Type: Float Switch, Adjustable
- Liquid: Diesel, Water
- Connector: DIN 43650
- Thread: 1 in. NPT
- Length: 500 mm.
- Header: Brass
- Stem: Brass
- Float: Polypropylene
- Float Stop: 304 Stainless Steel
- Gasket: Klingersil C4324
- Flange: Brass
- Sealing: IP67 if fitted with mating connector
- Temperature: -4 to 158°F (-20 to +70°C)
- EMC: ISO13766:2006
- Max Voltage: 250 VAC/VDC
- Max Current: 1 A
- Max Power: 10 VA
