Kuriyama Piranhaflex PF628 1/2 in. Hydraulic Hose, 3500 PSI - Hose Only

SKU:
KUPF62808
Manufacturer:
Kuriyama
Size:
1/2 in.
Temperature Range:
-65°F to +200°F (-54°C to 93°C)
Material:
Copolyester
Pressure:
3500 PSI
Ends:
Hose Only - No Ends
Length:
Per ft.
Weight:
0.17 LBS
$4.80
Made-To-Order (MTO) item is non-returnable/non-refundable/non-cancellable unless there is a defect or warranty issue. Please allow time for assembly before shipping.
Adding to cart… The item has been added

Description

Piranaflex PF628 Series hoses are designed for high-pressure hydraulic applications, including hydraulic oil and lubrication lines on industrial equipment and vehicles. They are well-suited for construction, agriculture, material handling, and other demanding equipment environments. These hoses can also be used with hydraulic tools.

Features

  • Abrasion Resistant - Polyurethane cover outlasts rubber versionsin applications where the hose rubs against abrasive surfaces.
  • Lightweight - Approximately 37% lighter weight than similar rubberhoses.
  • Pin Pricked Cover (PF628 Series Only) - Allows for the escape ofgasses, if necessary, eliminating risk of cover blistering.
  • Low Temperature Flex - Designed to flex at temperatures as low as-65°F; well suited for cold storage applications.

Specifications

    • Brand: Kuriyama
    • Part Number: PF628-08
    • Weight: 0.17 lbs/ft
    • Series: PF628
    • ID Size: 1/2 in. (12.9 mm)
    • OD Size: 0.82 in. (20.8 mm)
    • Length: Per Ft.
    • Service Temperature Range: -65°F to +200°F (-54°C to 93°C)
    • Working Pressure: 3500 PSI
    • COLOR: Black
    • Tube Material: Copolyester
    • Cover Material : Conductive Pin pricked, abrasion resistant polyurethane
    • Reinforcement Material: Braided aramid fibers
    • Ends: No Ends - Hose only
    • Compatible Fluids: Hydraulic Fluids, Petroleum
    • Min Bend Radius: 3 1/2 in. (89 mm)
    • Standards / Compliance: ANSI 92.2 (vehicle mounted aerial devices), SAE 100R8, SAE J517

Downloads

Specification Sheet (PDF Download)

Product Literature (PDF Download)
