Kuriyama Piranhaflex PF267 1/2 in. Hydraulic Hose, 2000 PSI - Hose Only

Description

Piranaflex PF267 Series hoses are designed for hydraulic oil and lubrication line applications on industrial equipment and vehicles, including construction, agriculture, and material handling machinery. Built for dependable performance in demanding hydraulic systems, these hoses help support fluid transfer where durability and flexibility are required

Features

• Kink Resistant Technology - Proprietary design shown to exhibit53% better resistance to kink initiation, and 16% less force to bend,versus competitive 100R7 hose in comparison testing.
• Abrasion Resistant - Polyurethane cover outlasts rubber versionsin applications where the hose rubs against abrasive surfaces.
• Low Temperature Flex - Designed to flex at temperatures as low as-65°F; well suited for cold storage applications.
• Pin Pricked Cover (PF267 Series Only) - Allows for the escape of gasses, if necessary, eliminating risk of cover blistering.

Specifications

• Brand: Kuriyama
• Part Number: PF267-08
• Weight: 0.17 lbs./ft
• Series: PF267
• ID Size: 1/2 in. (13.1 mm)
• OD Size: 0.834 in. (21.2 mm)
• Length: Per Ft.
• Service Temperature Range: -65°F to +200°F (-54°C to 93°C)
• Working Pressure: 2000 PSI
• COLOR: Black
• Tube Material: Copolyester
• Cover Material: Conductive Pin pricked, abrasion resistant polyurethane
• Reinforcement Material: Braided high tensile strength fibers
• Ends: No Ends - Hose only
• Compatible Fluids: Hydraulic Fluids, Petroleum
• Min Bend Radius: 3 in. (76 mm)
• Standards / Compliance: ANSI 92.28 (vehicle mounted aerial devices), SAE 100R7, SAE J517

Downloads

Specification Sheet (PDF Download)

Product Literature (PDF Download)
