ARO 666056-644 Classic Diaphragm Pump 13 GPM 100 PSI 1/2 in. Acetal

Description

Part of ARO's Compact Series of pumps, the 1/2 in. classic pumps feature big performance in a small package. With flow rates up to 13 GPM (49.2 LPM) and a wide range of material and porting configurations.

Features

• ARO has the world's best selling 1/2 in. ported diaphragm pump. Designed to meet your OEM application needs.
• Efficiency - Motor design delivers optimum air efficiency
• Reliability - ARO's patented 'Unbalanced' air valve ensures no-stall operation
• Versatility - Center, End, Dual Inlet / Outlet, and Swivel Top manifold configurations to fit your specific application
• Evironmentally Sound - Bolted construction for leak-free fluid handling
• Serviceability - Ease of service through modular design

Specifications

• Brand: ARO
• Series: Classic
• Manufacturer Part Number: 666056-644
• Power Source: Air
• Assembly Type: Bolt
• Fluid Chamber Assembly Type: Bolted
• Housing Material: Acetal
• Diaphragm Base Material: PTFE
• Diaphragm Plate Material: Santoprene
• Diaphragm Reinforcement: Not Reinforced
• Check Valve Material: PTFE
• Check Valve Type: Ball
• Check Seat Material: Acetal
• Max. Flow Rate: 13 gpm
• Max. Discharge Pressure: 100 psi
• Max. Feet of Head: 250 ft
• Max. Solids Dia.: 0.09 in
• Max. Viscosity: 15,000 cps
• Max. Media Temperature: 180 °F
• Displacement Per Stroke: 0.02 gal
• Max. Air Consumption: 20 scfm
• Max. Air Intake Pressure: 100 psi
• Fluid Intake Connection: 1/2 in NPT
• Fluid Discharge Connection: 1/2 in NPT
