AMT 4201-95 Cast Iron Straight Centrifugal Pump | 2 in. x 1-1/2 in. 5 HP Pedestal Pump

Description

The AMT Cast Iron 1750 RPM Solids Handling End Suction Centrifugal pump delivers high efficiency performance that minimizes operation and energy costs. Built to last, each pump features a precision cast bronze impeller that is dynamically balanced to minimize vibration and maximize motor bearing life. Pull-from-rear design simplifies maintenance without disturbing piping connection. Gauge taps at the suction and discharge ports allow for system monitoring. Maximum 1/4 in. diameter solids handling and optional seal flush/air relief valve is available for vertical installations. Pumps require a flooded suction and positive suction pressure.

Features

• Cast Iron Construction
• FKM Silicon Carbide/Carbon Mechanical Seal
• Silicon Bronze Precision Cast Dynamically
• Balanced Impeller
• Bronze Case Wear Ring
• 2 in. x 1 1/2 in. NPT Ports
• 1/4 in. NPT Gauge Taps on Suction & Discharge Ports for System Monitoring
• Bronze Shaft Sleeve to Protect Motor Shaft
• Maximum Flow-Rate 180 GPM
• Maximum Casing Pressure 175 PSI
• Maximum Temperature 200° F
• Includes Seal Flush/Air Relief Valve
• Front Drain Plugs
• 1750 RPM TEFC JM NEMA Frame IE2/EPAC
• Energy Efficient Motors

Specifications

• Maximum Solids Handling Capacity: 1/4 in. Dia.
• HP: 5
• PH: 3
• Frame: 182JM
• ENC: TEFC
• Voltage @ 60 Hz: 208-230/460
• Full Load Amps: 22/11
• Suction: 2 in. FNPT
• Discharge: 1 1/2 in. FNPT
