The Mix-A-Tote agitation system from Agri-Inject allows growers, ag retailers and chemical wholesalers to safely and conveniently perform mixing processes in IBC storage containers. Agri-Inject develops products that merge quality, efficacy and safety at the highest level and Mix-A-Tote is a prime example. This product has been carefully designed to perform better than any existing mixing unit and be the simplest and safest to use.
Note: Image shown is the single phase system.
Features
- Control Switch: Toggle-type control switch mounted in the electrical junction box of the motor to easily turn the unit On/Off
- Safe Power Cord: Designed to extend over the edge of the tank but not all the way to the ground, ensuring the cord doesn't sit in a puddle of liquid - Cord is long enough to comfortably connect to an extension cord that can be secured to the tank's metal cage
- 6 in. IBC Lid: Connects directly to an IBC tote for easy sealing and mixing
- Commercial Grade/Corrosion Resistant: All of the wetted components, handle components and lid/bracketry are either 300 series stainless steel or in the cage of the IBC lid, high quality glass filled polypropylene
- Easy to Handle and Use: The handle hardware has been designed to be easy to lift, carry and install into the IBC container - The handles are 7/8 in. and feel comfortable in nearly any hand size - The control switch is mounted and easy to use location with a gripping rubber cover to ensure non-slip engagement
- Effective Impellers: Designed to provide thorough agitation - The direction of mixing is configured for "up-pumping" agitation, eliminating vortexing and creating an "enveloping effect" within the tank, providing excellent and rigorous mixing
Specifications
| Mix-A-Tote Model Comparison and Specifications | ||
|---|---|---|
| Type | Single Phase | Three Phase |
| Weight: | 34 lbs. | 37 lbs. |
| Overall Length (Includes Motor): | 47 in. | 47 in. |
| Handle Width (Max. Width): | 17 in. | 17 in. |
| Shaft Length: | 35 in. | 35 in. |
| Impellers (Two Each Shaft): | 4 in. MaxFlow Style | 4 in. MaxFlow Style |
| Motor - Full Load Amps: | 8 | 0.9 |
| Cord Length: | 21 in. | 70 in. |
| Switch: | Single Phase, SPST | 3-Contact Manual Motor Protector |
| Plug: | Standard Single Phase 15-Amp, Grounded | Not Included, User Installed |
| IBC Lid Size: | 6 in. Buttress Thread | 6 in. Buttress Thread |
| IBC Lid Material: | Glass-Filled Polypropylene | Glass-Filled Polypropylene |
| All Wetted Metal Parts & Handle: | 300 Series Stainless Steel | 300 Series Stainless Steel |
Downloads
Data Sheet (PDF Download)
