Udor VXX-B 75/350 R Plunger Pump W/ 40mm Solid Keyed Shaft, 19.8 GPM, 5075 PSI

Udor VXX-B 75/350 R Plunger Pump W/ 40mm Solid Keyed Shaft, 19.8 GPM, 5075 PSI

The Udor VXX-B 75/350 R is a heavy-duty industrial plunger pump designed for high-pressure applications such as sewer jetting, street cleaning, and oil field operations. Delivering a maximum flow of 19.8 GPM and pressures up to 5075 PSI, this pump is built for durability and efficiency. It features an anodized aluminum crankcase, nickel-plated manifold, and stainless steel check valves for superior corrosion resistance and reliability. With a 40mm solid keyed shaft and rated speeds of 1000 RPM, the VXX-B 75/350 R ensures consistent performance in demanding environments.

Industries: Pressure Washing, Truck Wash, Car Wash, Food Processing, In Plant Cleaning Systems, Graffiti Removal, Fire Fighting, Sewer Jetting, Hydro Excavating, Reverse Osmosis, Desalination Process, De-Mucking, Misting/Fogging/Cooling, Air Conditioning Cleaning, Ground and Sod Aeration, Machine Tool Coolant, Tree Debarking, Directional Boring and Drilling, Hydrostatic Testing, Soft Wash

Features

Durable Construction: Anodized aluminum crankcase for corrosion resistance; nickel-plated manifold for enhanced longevity
High-Performance Components: Stainless steel check valves for reliable operation; heavy-duty bronze connecting rods and roller bearings
Optimized Design: 1-1/2 inch BSP-F inlet and 1 inch BSP-F outlet for secure connections; 128 oz oil capacity for proper lubrication
Temperature & Pressure Handling: Maximum fluid temperature of 160°F; rated for up to 5075 PSI

Specifications

• Crankshaft Stroke: 42.0mm
• GPM: 19.8
• Inlet Size: 1-1/2 in. BSP-F
• Lubrication: 128 oz Udor Lube
• Max Pressure: 5075 PSI / 350 Bar
• Max Speed: 1000 RPM
• Model: VXX-B 75/350 R
• Outlet Size: 1 in. BSP-F
• Plunger Diameter: 28mm
• Power Requirement: 67.3 HP Electric
• Seal Kit: 6061.N2
• Valve Kit: 6061.N3

Downloads

Specification Sheet (PDF Download)
