Kuriyama Piranhaflex PF528 1/4 in. Hydraulic Hose Assembly w/ Male JIC Seat x Female JIC Seat

Description

Piranhaflex PF528 Series hoses are designed for high-pressure hydraulic applications, including hydraulic oil and lubrication lines on industrial equipment and vehicles. They are well-suited for use in construction, agriculture, material handling, and other demanding equipment environments. These hoses can also be used with hydraulic tools.

Assembled with Male JIC Seat x Female JIC Seat

We cut and couple all hose assemblies in-house. If you do not see the length you need or would like a different type of end fitting, please give us a call and we will be happy to build a custom assembly to meet your requirements.

Features

• Kink Resistant Technology - Proprietary design shown to exhibit 50% better resistance to kink initiation, and 17% less force to bend, versus competitive 100R8 hose in comparison testing.
• Abrasion Resistant - Polyurethane cover outlasts rubber versions in applications where the hose rubs against abrasive surfaces.
• Lightweight - Approximately 24% lighter weight than similar rubber hoses.
• Low Temperature Flex - Designed to flex at temperatures as low as -65°F; well suited for cold storage applications.
• Pin Pricked Cover (PF528 Series Only) - Allows for the escape of gasses, if necessary, eliminating risk of cover blistering.

Specifications

• Brand: Kuriyama
• Part Number: PF528-04
• Hose Only Weight: 0.112 lbs/ft
• Series: PF528
• ID Size: 1/4 in. (6.5 mm)
• OD Size: 0.584 in. (14.8 mm)
• Length: Per Ft.
• Service Temperature Range: -65°F to +200°F (-54°C to 93°C)
• Working Pressure: 5000 PSI
• Color: Black
• Tube Material: Nylon
• Cover Material : Conductive Pin pricked, abrasion resistant polyurethane
• Reinforcement Material: Braided high tensile strength fibers
• Ends: Male JIC Seat x Female JIC Seat
• Compatible Fluids: Hydraulic Fluids, Petroleum
• Min Bend Radius: 2 in. (50 mm)
• Standards / Compliance: SAE 100R8
