Holmbury IB10-F-06N 3/8 in. Carbon Steel ISO B Coupling 3/8 NPTF, ISO 7241:2014 W/ Nitrile Rubber Seal - Female

Description

Features

• Optional zinc nickel plating provides corrosion resistance (1200 hours with no red rust in salt spray tests)
• Poppet valves have balanced springs
• Locking ball system allows quick connection
• Bidirectional flow
• Carbon steel with trivalent plating (Zinc nickel plating available - for US request IBZ )
• Fitted with Nitrile seals (Viton seals available

Specifications

• Brand: Holmbury
• Series: IB Series
• Part Number:IB10-F-06N
• Body Size: 3/8 in.
• Body Material: Carbon steel W/ trivalent Plating
• Operating Temp: -40°C (-40°F) to 106°C (223°F)
• Seal material: NBR
• Flow-Rate: 6 GPM
• Flow-Rate: 23 LPM
• Thread Size: 3/8 NPTF
• Approvals/Certif: ISO 7241:2014
• Thread Type: NPTF
• Maximum working pressure (Coupled): 350 BAR
• Maximum working pressure (Coupled): 5075 PSI
• Burst pressure (Coupled): 1500 BAR
• Burst pressure (Coupled): 21750 PSI
• Burst pressure (Male *): 1500 BAR
• Burst pressure (Male *): 21750 PSI
• Burst pressure (Female **): 1550 BAR
• Burst pressure (Female **): 22475 PSI

Applications

• Hydraulic attachments
• Hammer circuits
• High pressure pulse applications
• Leak free environments
• Construction plant, mobile equipment, general industrial, mining and agricultural industries
• Agricultural

Downloads

Specification Sheet (PDF Download)
