Building on the heritage of Graco's first electronic meter, the EM Series features a robust design at an affordable price. Weather-rated and shock-resistant construction protects the electronics from intense, high-pressure cleaning and mechanical vibration common in industrial applications. EM Series handheld and in-line meters are designed to last from small service centers and lubrication trucks to heavy-duty repair facilities. Graco's EM Series meters are backed by our robust warranty and feature upgraded electronics and easy-to-read LCD with simple operator controls that measures in quarts, gallons, pints and liters.
Features
- Proven in harsh conditions with sealed electronics (IP69K) protected against direct pressure washing and dust
- Features upgraded electronics for long battery life and easily replaceable AAA batteries.
- Easy-to-hold locking handle prevents accidental dispenses
- Twist-close nozzle prevents leaking and is available in multiple extensions including rigid, flexible and gear lube
- High-flow rates capable of up to 8 GPM
- Easy-to-read LCD featuring simple operator control. Measures in quarts, gallons, pints and liters
- Legacy valve with 1/2 inch inlet, compatible with oil, ATF, anti-freeze and gear lube
- Easily track fluid usage with individual dispenses or display total dispense history
Specifications
- Flow Range: 0.25 to 8 GPM (0.95 to 30.3 LPM)
- Maximum Operating Pressure: 1500 PSI
- Unit of Measure: Quarts, Gallons, Pints & Liters
- Accuracy/Repeatability: +/- 0.5%
- Inlet: 1/2 in. NPT
- Outlet: 3/4 straight thread O-ring boss
- Maximum Totalizer: 19,999 units
- Maximum Recorded Dispense: 19,999 units
- Operating Temperature Range: -22°F to 180°F (-30°C to 82°C)
- Storage Temperature Range: -40°F to 185°F (-40°C to 85°C)
- Materials: Antifreeze, Motor Oil, Gear Oil and Oil
- Outdoor Use: Yes - IP69k as per KIN 40050-9
- Battery: 2 (AAA) alkaline or 2 (AAA) lithium
- Wetted Parts: Aluminum, Stainless steel, carbon steel, acetal, nitrile rubber, Geolast
- Meter Pressure Loss*: 30 PSI @ 6 GPM
- Dimensions: 13 in L x 3.5 in. W x 5.25 in. H (33 cm L x 9 cm W x 13.3 cm H)
- Weight: 3.1 lbs.
- Warranty: Five years overall, three years electronics and one year wear parts
- Instruction Manual: 3A5588
Applications
- Automotive dealerships
- Service and fast lube centers
- Lube trucks
- Mining
- Heavy-duty dealerships
- Fleet service facilities
- In-plant
