GPI G2P10NQ9GMA 1 in. NPT Industrial PVDF Body Turbine Flow Meter w/ Battery Powered Display

GPI G2P10NQ9GMA 1 in. NPT Industrial PVDF Body Turbine Flow Meter w/ Battery Powered Display

The FLOMEC® G2 Series PVDF Turbine Flow Meter is engineered for harsh chemicals, acids, and bleach. Its durable PVDF construction and factory 5-point calibration deliver reliable, high-accuracy measurements across the 5–50 GPM flow range. Featuring a Q9 battery-powered LCD display and a modular design, it’s easy to install, maintain, and upgrade with optional 4-20mA output modules, remote displays, and sensors.

Features

• Highly Visible Q9 Display: Battery-powered LCD with up to a 2-year battery life
• Optional 4-20mA Module: Provides an industry-standard analog signal for integration with various control systems
• Multiple Engineering Units: Includes 11 pre-programmed units plus 1 custom option for versatile measurement needs
• High Accuracy Readings: Factory 5-point calibration ensures ±1.5% accuracy across the flow range
• Robust PVDF Housing: Corrosion-resistant build stands up to aggressive chemicals and is easy to maintain

Specifications

• Connection: 1 in. NPT (Female)
• Flow Range: 5 – 50 GPM (19–190 L/min)
• Accuracy: ±1%
• Technology: Turbine
• Pressure Rating: 100 PSI (6.9 bar)
• Operating Temperature: 0° F – 129° F (-18° C – 54° C)
• Meter Housing: PVDF
• Wetted Materials: Ceramic, Fluorocarbon, PVDF
• Warranty: 2-year meter warranty
• Approvals: ATEX EX, CE, FCC Part 15, FM Approved, c FM Approved, IECEx, IP65, NEMA 4, RoHS, UKCA, UKEx

Downloads

Product Manual (Turbine Housing) (PDF Download)

Product Manual (Q9) (PDF Download)
