Gizmo Engineering T6 Series Digital Waterproof AC Powered Industrial Production Timer - Large Display

Gizmo Engineering T6 Series Digital Waterproof AC Powered Industrial Production Timer - Large Display

An essential tool for a wide range of industrial applications, designed to provide precise timing operations with clear visual and audible alerts. It offers versatile functionality, allowing users to count up or down according to their specific needs. With its large digital display, stack light indicators, and robust power relay output, this timer is built to perform in the demanding environments of factories and industrial sites. Installation is straightforward, requiring only mounting with screws, and its waterproof and corrosion-proof construction ensures long-term reliability in rugged conditions.

Features

• Adjustable Timing: Range from 1 second to 100 hours for diverse applications
• Simple Installation: Easy mount-and-plug setup
• Robust Build: Waterproof and corrosion-proof for industrial durability
• Loud Alarm: 103 dB buzzer ensures audibility in noisy environments
• Clear Display: Large digital screen with 30mm digits for easy viewing
• Versatile Modes: Multiple modes for countdown, count up, and specialized functions
• Indicator Lights: Green, red, and amber LEDs for status alerts
• Powerful Relay: 15A output for controlling external devices

Specifications

• Timing Range: 1 second to 100 hours
• Display Size: 3.54 in. x 1.38 in. (90 mm. x 35 mm.)
• Relay Output: 15A at 120VAC
• Ingress Protection: IP65
• Temperature Range: -40°F to 122°F (-40°C to 50°C)
• Enclosure Material: PVC
• LED Lens Cover: Lexan
• Cover Screws: 316 stainless steel
• Timing Accuracy: ± 0.01%
• Power Consumption (Alarming): 30mA
• Sound Pressure Level: 103dB at 2 ft.
