The VISCOFLUX Lite standard drum unloading system for handling low to medium viscosity products (up to 50,000 cps viscosity) in industrial applications. Pump in stainless steel material with PTFE stator. System designed for standard steel drums with 22-1/2"ID. System requires 120V for the electric motor on top of the pump and compressed air to raise the follower plate back up. Pump includes 1.5 inch hose connection. Use with the following medias: Substances just capable of flowing by gravity, Soft lubricating greases up to NLGI class 1, Leveling compounds, Base materials for paints and varnishes, Solvent-based blend pastes, Coating compounds (base coats), Adhesives/construction glues/fixing compounds, and Corrosion protection gels.
To Order: The Viscoflux Lite system and all FLUX series 500 pumps are designed for handling high viscosity fluids or products and are subject to technical review with the manufacturer before sale/order release. Please provide the liquid or product to be pumped and the viscosity.
Note: FLUX also offers VISCOFLUX Lite System with different components for other drum dimensions and for other applications including sanitary applications in the food processing industry, for handling flammable products, for higher viscosity products (up to 100,000 cps viscosity), with air operated motor, with elastomers in other materials and other options. Discharge hose sold separately. Higher viscosities possible with special motors. Please contact JME Sales at 800-333-13331 for more information.
Features
- Simple to install
- Captures over 98% of the products in the drum
- Transfer higher viscosity substances that are just capable of flowing
- Gentle handling of sensitive products
- Assists in pumping substances that are just capable of flowing by gravity
- Quick disassembly allows for fast cleaning
- Low installation height requirement
- Eccentric worm-drive pump for gentle transport of the medium with little turbulence and pulsation
- Follower plate with seal pushes the product down into the pump section
Applications
- Light grease up to NLGI #2
- Mayonnaise
- Ketchup
- Mustard
- Salad dressings
Specifications
- 120V Electric motor
- 12 GPM (45 LPM) max flow-rate * As tested with water at 68°F at pump outlet with full, open discharge (+/- 10%); Max pressure measured with closed outlet. Performance will vary based on type of liquid(s) or product(s) being transferred.
- Max 116 PSI delivery pressure * As tested with water at 68°F at pump outlet with full, open discharge (+/- 10%); Max pressure measured with closed outlet. Performance will vary based on type of liquid(s) or product(s) being transferred.
- Up to 50,000 cPs viscosity
- Pump immersion length is 39 in. L
- Air connection for raising the follower plate
- For use with 55 Gallon drum with 22 1/2 in. diameter
- Pump with 1.5 in. hose connection on discharge
- Wetted materials: Stainless steel, FKM, Silicone carbide, NBR
- Residual product in drum is less than 1 to 2%
- Max temperature is 248° F (120° C)
- 12 Month warranty from date of delivery, covers defects in materials and workmanship
