DAVCO Shop Pro FXP 95, 120V AC Electric Motor/Pump, 50/95 PSI Pressure Regulator, 150 GPH

The DAVCO Shop Pro FXP 95 is a multipurpose shop floor tool, custom designed to remove water and contaminants from a diesel fuel tank, transfer diesel fuel and prime heavy duty diesel engines including the Detroit Diesel DD13/DD15/DD16 engine line. Designed for Detroit GHG engines to open the two-stage valve for complete fuel system priming.

Notes: Approved for use with diesel fuel only. The 95 PSI setting is designed to be used only with Detroit Diesel DD13, 15 and 16 engines to open the two stage valve for complete fuel system priming. 50 PSI pressure setting for priming all other OEM's engines.

Features

• Primes engines after service
• Eliminates the use of hand priming pumps after performing maintenance
• Uses onboard fuel to prime engines and filters, avoids the hassle of keeping reserve fuel on hand
• Eliminates cross contamination of fuel

• Filters and transfers fuel in one operation
• Transfers fuel to repair tanks or crossover lines
• Transfers fuel for trucks being sold or taken out of service

• Removes contaminated fuel, sediment and water from fuel tanks of diesel powered equipment or from diesel storage tanks
• Cleans fuel tanks during service can be a value added service or a new revenue stream
• Eliminates downtime due to fuel contamination

Specifications

• Product: Shop Pro FXP 95
• Application: Designed to Remove Water and Contaminants From a Diesel Fuel Tank, Transfer Diesel Fuel and Prime Heavy Duty Diesel Engines With Flow Rates up to 150 Gallons Per Hour (GPH)
• Pump and Motor: 120 VAC Electric Motor/Pump Combination Rated for Continuous Operation, UL listed and CSA approved
• Flow Rate: 150 GPH (567.81 LPH)
• Electrical: UL Listed, Rear-Facing Receptacle; Waterproof ON/OFF Switch; Can Be Used On The Shop Floor; It Can Also Be Used With a Generator or High Capacity Inverter That Supports a 4.8 Amp Draw
• Cart: Custom Design With Heavy Duty Construction; Portable and Self-Contained
• Filtration: 7 Micron
• Height: 40.89 in. (1,038.61 mm.)
• Depth: 17 in. (431.80 mm.)
• Width: 23.3 in. (591.82 mm.)
• Weight, Dry: 74 lbs. (33.57 kg.)

Contents

• Pressure Hose
• Pick-up Wand
• Dispensing Wand
• 50/95 PSI Pressure Regulator
• Hose Retainer
• Suction Hose
• Sight Tube
• Filtration Unit
• Motor
• Pump
• Heavy Duty Cart
