Bosworth Guzzler® G2-0501N 1 1/4 in. 10 GPM Sap-Puller Double Diaphragm Pump

Bosworth Guzzler® G2-0501N 1 1/4 in. 10 GPM Sap-Puller Double Diaphragm Pump Description

The Bosworth Guzzler Sap Puller Double Diaphragm 115 VAC Motorized Pump is created with FDA-approved materials for wetted components. Ideal for pharmaceutical, food processing or biomedical applications.

Note: Commonly used to create a vacuum for maple sap collection.

Features

• Ideal for vacuum production on maple sap collection lines (up to 800 taps)
• No separator required - creates vacuum and transfers fluid
• Wetted components made of NSF compliant (or better) materials
• Can create vacuum and/or transfer fluid; no separator required
• 115 VAC induction motor - 72 rpm, features water resistant motor enclosure
• Connecting rod bearings required no lubrication
• Pump diaphragms easily accessible by removing pump bodies from housing
• Input/output manifolds can be oriented to point in same or opposite directions
• Wired with on/off switch and 6 ft. power cord
• Nitrile Rubber diaphragm and silicone umbrella valves made of FDA-approved materials
• Ships with two spare diaphragms

Specifications

• Inlet/Outlet: 1-1/4 in. PVC FNPT
• Body and Ports: Natural (Pigment-free) Delrin/White
• Flow-Rate: 10 gpm
• Max Pressure: 15 psi / 1 bar
• Max Vacuum: 22 in. Hg (0.7 bar)
• Max Lift: 20 ft. (6.1 m)
• Max Head: 25 ft. (7.6 m)
• Volume per stroke: 0.55 qt (0.52 l)
• Max Service Temp: 140° F (60° C)
• Housing and Support: Epoxy coated steel - resists corrosion
• Clamp Ring: Aluminum Motor Mounting Plate
• Valves: Umbrella (Silicone)
• Diaphragm: Nitrile Rubber (Nitrile) FDA-approved
• Clevis Button Assembly: Steel Crank Arm & Connecting Rod; Delrin Clevis
• Motor: 115VAC, rpm: 72, torq: 111 in-lbs | psi: 8, head (ft): 18 | Water res't

Downloads

Bosworth Guzzler G2-0501N Diaphragm Vacuum Pump Manual (PDF Download)
