BadgerFlex 1 1/4 in. FOD Hose Assemblies w/ Male NPT x Female NPSH Swivel Ends

1 1/4 in. Fuel Oil Delivery Hose Assembly Male NPT x Female NPSH Swivel

The BadgerFlex 1 1/4 in. FOD hose assembly is a 300 PSI hose for everyday fuel oil and diesel delivery. Built with a male NPT end and female NPSH swivel end (both brass), it combines a nitrile rubber tube, nitrile rubber/PVC cover, braided synthetic yarn reinforcement, and an integrated stainless steel static wire.

The hose is designed to resist kinking and twisting during handling and performs especially well when installed on fuel delivery reels. This construction supports smooth handling and consistent flow while helping reduce downtime for fuel delivery contractors and petroleum service teams. Assemblies are available in lengths from 5 ft. to 200 ft.

We cut and couple all hose assemblies in-house. If you don’t see the length you need or would like a different type of end fitting, please give us a call and we will be happy to build a custom assembly to meet your requirements.

Features

• Fuel compatibility: Fuel oil and diesel
• Service: Fuel oil delivery applications
• Connections: Male NPT x female NPSH swivel (brass)
• Hose construction: Nitrile rubber tube with a nitrile rubber/PVC cover, two-layer braided synthetic yarn reinforcement, and stainless steel static wire
• Available lengths: 5, 10, 15, 20, 25, 30, 40, 50, 60, 70, 75, 80, 90, 100, 125, 150, 175, and 200 ft.

Specifications

• Application: Fuel oil delivery
• Brand: BadgerFlex
• Inner Diameter: 1 1/4 in.
• Outer Diameter: 1 4/5 in.
• Maximum Working Pressure: 300 PSI
• Bend Radius: 9.1 in.
• Connections: Male NPT x female NPSH swivel
• Tube Material: NBR (nitrile rubber)
• Cover Material: Nitrile rubber/PVC blend
• Reinforcement: Two-layer braided synthetic yarn
• Static Wire: Stainless steel
• Temperature Range: -40°F to 140°F (-40°C to 82°C)
