Udor ZETA 170 TS2C 1 1/2 in. Diaphragm Pump, 4 cylinders, 45 GPM, 300 PSI

Udor ZETA 170 TS2C 1 1/2 in. Diaphragm Pump, 4 cylinders, 45 GPM, 300 PSI

The Udor ZETA 170 TS2C is a robust, low-pressure diaphragm pump designed for horticultural and agricultural spraying applications. Built with anodized aluminum bodies, plasticized aluminum heads, stainless steel valves, and glass-filled nylon manifolds, this pump offers superior durability and corrosion resistance. A pulsation dampener is standard on all models for smooth operation. Delivering a maximum flow of 45 GPM and pressure up to 300 PSI, the ZETA 170 is equipped with a 1-3/8 in. 6-spline male PTO thru-shaft for reliable power transfer, making it ideal for professional spraying systems.

Industries: Lawn Care, Fire Fighting, Orchard/Nursery Spraying, De-Mucking, Decontamination, White Washing, Aquatic Plant Control, Spray Insulation, Hydrostatic Testing, Fluid Transfer, Chlorine Application, Crop Spraying, Fertilizer Application, Aircraft De-icing, Pest Control, Soft Wash

Features

• High-Performance Output: Provides up to 45 GPM for efficient spraying operations.
• Durable Construction: Anodized aluminum body and stainless-steel components for long-lasting service.
• Smooth Operation: Includes a pulsation dampener for consistent performance.
• Versatile Applications: Perfect for horticultural and agricultural spraying tasks.
• PTO Drive Compatibility: Equipped with a 1-3/8 in. 6-spline male PTO thru-shaft for secure connection.

Specifications

• Bar: 20
• Dimensions: 15.5 in. L x 12.5 in. W x 17.5 in. H
• Drive Configuration: 1-3/8 in. 6-Spline Male PTO Thru-Shaft
• GPM: 45
• Inlet Port: 1-1/2 in. HB
• Lubrication: 44 oz. Udor Lube 40W Premium Pump Oil
• Maximum Pressure: 300 PSI
• Maximum RPM: 540
• Model: ZETA 170 TS2C
• Outlet Port: 1 in. HB

Downloads

Specification Sheet (PDF Download)
