Udor ZETA 120 VAGR1 1 1/2 in. Diaphragm Pump, 3 cylinders, 31 GPM, 300 PSI

Udor ZETA 120 VAGR1 1 1/2 in. Diaphragm Pump, 3 cylinders, 31 GPM, 300 PSI

The Udor ZETA 120 VAGR1 is a robust, low-pressure diaphragm pump designed for horticultural and agricultural spraying applications. Built with anodized aluminum bodies, plasticized aluminum heads, stainless steel valves, and glass-filled nylon manifolds, this pump delivers exceptional durability and corrosion resistance. With a maximum flow of 31 GPM and pressure up to 300 PSI, the ZETA 120 ensures reliable performance for medium to large-scale spraying tasks. It features a gear reduction drive configuration for 1 inch shaft gas engines ranging from 8 to 20 HP, making it a dependable choice for professional spraying systems.

Industries: Lawn Care, Fire Fighting, Orchard/Nursery Spraying, De-Mucking, Decontamination, White Washing, Aquatic Plant Control, Spray Insulation, Hydrostatic Testing, Fluid Transfer, Chlorine Application, Crop Spraying, Fertilizer Application, Aircraft De-icing, Pest Control, Soft Wash

Features

• Durable Construction: Anodized aluminum body and stainless-steel components for long-lasting performance.
• High-Performance Output: Provides up to 31 GPM and 300 PSI for efficient spraying operations.
• Versatile Applications: Ideal for horticultural and agricultural spraying tasks.
• Corrosion-Resistant Design: Glass-filled nylon manifolds and plasticized aluminum heads for added protection.
• Gear Reduction Drive: Compatible with 1 inch shaft gas engines (8–20 HP) for smooth operation.

Specifications

• Bar: 20
• Dimensions: 13 in. L x 11 in. W x 12 in. H
• Drive Configuration: Gear Reduction for 1 in. Shaft Gas Engine
• GPM: 31
• Inlet Port: 1-1/2 in. HB
• Lubrication: 40 oz. Udor Lube 40W Premium Pump Oil
• Maximum Pressure: 300 PSI
• Maximum RPM: 550
• Model: ZETA 120 VAGR1
• Outlet Port: 3/4 in. HB

Downloads

Specification Sheet (PDF Download)
