TECNA 9340AX ATEX Tool Balancer, 22 to 30.9 lbs Capacity

Description

TECNA was the first to develop a dedicated line with ATEX certification, suitable for use in areas with a potentially explosive atmosphere composed of flammable gases or combustible materials.

TECNA AX BALANCERS, depending on the models, are compatible with most flammable fumes, gases including Propane, Ethylene, Acethylene and Hydrogen (IIC group), as well as flammable dust.

ATEX certification, beside other features, requires products to be entirely conductive, grounded and with spark-proof materials.

TECNA AX BALANCERS line is perfect for Oil&Gas applications, oil plants and refineries, chemical plants, but also tank washers, as well as situations with flour or flammable powders in suspension.

TECNA AX BALANCERS LINE performs equal to the classic TECNA BALANCERS line, simply with full compliance with ATEX strict requirement.

Features

• Rugged construction, cast aluminum body.
• Stainless steel rope.
• Adjustable capacity.
• Auxiliary safety suspension.
• Adjustable stroke limiting device.
• Cable guide in antifriction material.
• Inert spring drum assembly.
• Polyamides thimble.
• Operating temperature between + 5°C to + 60°C.

Specifications

• Capacity Range: 22 - 30.9 lbs (10 - 14 Kg)
• Cable Type: Stainless Steel
• Stroke Length: 98.43 in. (2500 mm)
• Application Environment: Industrial (Standard)
