Sunfire SF160 160,000 BTU Portable Dual Fuel Diesel/Kerosene Radiant Heater

The Sunfire SF160 is an ultimate commercial grade radiant heater. The frame, wheels and lifting bracket make the heater easy to lift, roll and transport to any location that needs to be heated. The heaters features XtremeClean™ technology for a clean, odorless and quiet experience. Using infrared radiant energy it warms areas, objects and people directly with breeze free and dustless heating.

The SF160 heater can warm up to a 3,700 ft² space and comes wired with a standard thermostat to regulate the temperature. This heater has dual fuel capabilities, it can run on both diesel and kerosene fuel. Requires a 120V power source. For use in shop garages, jobsites, and workshops.

Warning- Not for indoor use in household residence. Proper ventilation is required during operation.

Features

• Quiet-Low noise compares to forced air and torpedo style heaters.
• Clean-Sunfire technology offers a pure, odorless and smokeless flame
• Safe-Safely use in shops, warehouse, pole barn or garage
• RAPIDACCESS™-Easy maintenance hatch allows quick access to the nozzle assembly for tune-ups and maintenance
• Thermostat Capability-The SF160 is wired for an optional standard mechanical or battery operated wall thermostat of your choice. Thermostat not includedDon't use a thermostat requiring 120V power to operate.
• Portable-The SF80 heater is easily portable due to a small 19 3/4 in. width footprint. The tube frame makes it comfortable to grip, lift and transport to any location

Specifications

• BTU: 160,000
• Heating Space: 2,800 ft²
• Fuel: Diesel, Kerosene, #2 Fuel Oil
• Tank Capacity: 18 Gallons
• Run Time: Approx. 16 hours
• Flow Rate (GPH): 1.14GPH for Diesel/#2 Fuel Oil and 1.05 GPH for Kerosene
• Low Noise
• Rubber Flat-Free wheels
• Safety flame sensor
• Tip Switch
• Dimensions: 35 1/2 in. L x 31 in. W x 43 in. H
• Dry Weight: 160 lbs.
• Full Tank Weight: 305 lbs.
• Electrical Requirements: Compatible with generator, 120V 1.8A 60HZ or 12V Pure Sine power inverter (800W minimum)
• Standard Thermostat included
• ETL Listed
• Lifting Bracket for use with Crane, Sling, or Forklift
• Minimum Clearance: Front-84 in./ Right & Left Side-36 in./ Back- N/A
• Warranty: 2 Year Limited Warranty
• Made in the USA

Downloads

Specifications (PDF Download)

Warranty (PDF Download)

Thermostat Installation (PDF Download)
