Solberg 843 Small Vacuum Pump Polyester Replacement Filter Element

The 800 Series polyester filter elements offer long-lasting performance for applications where durability and reuse are important. The polyester media removes particles down to 5 microns with very high efficiency while allowing strong airflow through the pleated design. This construction helps reduce maintenance frequency and supports clean, dependable operation.

Each polyester element is reinforced with epoxy-coated steel wire and an expanded metal inner support for added strength and resistance to wear. Built to handle continuous operation across a wide temperature range, these filters are well suited for environments with higher dust loads or where extended filter life is desired.

Features

• Durable polyester media removes particles down to 5 microns while supporting consistent airflow
• Pleated construction provides higher dirt holding capacity, reducing the need for frequent filter changes
• Reinforced with epoxy-coated steel wire and internal metal support for added durability in demanding environments

Specifications

• Mann Ref. Number: C1112
• Capacity: 55 SCFM
• Material: Polyester, Epoxy-Coated Steel
• Temp (continuous): -15°F (-26°C) to 220°F (104°C)
• Filter Change Out Differential: 15-20 in. H2O over initial ΔP
• Removal Efficiency: 99+% to 5 micron
• Dimensions:
  • Outer Diameter: 3.85 in. (98 mm)
  • Inner Diameter: 2.38 in. (60 mm)
  • Height: 2.73 in. (69 mm)
