Reotemp TSTA Sanitary Pressure Transmitter W/ 3 In. Tri-Clamp, M12

Description

The Reotemp TSTA Sanitary Pressure Transmitter delivers dependable performance in hygienic environments where accuracy and cleanliness are critical. Built with robust 316 stainless steel wetted parts, it is fully compatible with CIP (Clean-in-Place) and SIP (Sterilize-in-Place) procedures, making it well-suited for a variety of processing applications. Its high-stability silicon piezoresistive sensing technology ensures reliable pressure measurement with excellent long-term stability, even in demanding process conditions. The TSTA supports multiple electrical outputs and offers flexible installation options. With its 3-A Tri-Clamp® sanitary connection and ability to withstand media temperatures up to 750°F, the TSTA provides a rugged, sanitary solution that maintains accuracy and reliability in mission-critical operations

Features

• 3-A" Tri-Clamp® Sanitary Connection
• 316 Stainless Wetted Parts
• Designed for "Clean-in-Place" (CIP) and "Sterilize-inPlace" (SIP)
• Media Temperatures up to 750 ° F
• ± 0.5% Accuracy (3/4" Tri-clamp® ±1.0%)
• Excellent Long-Term Stability

Specifications

• Brand: ReoTemp
• Series: TSTA
• Output Signal: 4-20mA, 2-Wire (Standard), 0-5V, 0-10V, (3-Wire)
• Measuring Principle: High-Stability Silicon Piezoresistive
• Pressure Ranges: Vacuum, Compound, Pressure to 1,000psi
• Proof Pressure: 2 x Range, Up to a Maximum of the"Clamp" Pressure Rating
• Burst Pressure: Determined By Customer's "Clamp" Pressure Rating Up to a Max of 2,000 psi
• Accuracy NLH at 77 ° F: ±0.5% (3/4" Tri-Clamp® ±1.0%)
• Input: 11-28 VDC (4-20mA, 0-5V) 15-28 VDC (0-10V)
• Temperature Effect: 1.5" or 2" Tri-Clamp®: ±0.1% of Span/10 ° F (for Zero and Span) or ±0.02 psi/10 ° F (Greater of) Note: 3/4" Tri-Clamp® Not Recommended for Temperature Variations. Effect is less than or equal too ±0.9 psi/10 ° F
• Environmental Rating: IP65 (Hirschmann, M12), IP68 (Cable)
