Reelcraft D83000 OLS Stainless Steel Spring Retractable Hose Reel - Reel Only - 3/4 in. x 75 ft. - 500 PSI

Reelcraft's stainless steel hose reels are ideal for food processing, pre-rinse, wash down, chemical transfer and industrial-solvent handling. Also suitable for coastal, offshore and on-board ship in marine applications where the harsh environment of salt water spray requires the use of stainless steel hose reels. Swivels include Viton o-rings.

Features

• Full-flow stainless steel shaft and swivel assures maximum product delivery
• The steel guide arm and dual pedestal base are stamped with ribs and gussets and robotically welded to insure maximum strength and lightest possible weight
• Full flow stress free swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
• Long life drive spring - The unitized cast aluminum fluid path with built in declutching arbor virtually eliminates possibility of leakage and spring damage due to reverse winding
• Heavy duty brackets eliminate bending due to angular hose pull
• Multi-position guide arm permits wall, floor ceiling, pit or truck mounting
• Nylon guide rollers reduce hose drag and abrasion
• Pos-i-latch will maintain the desired working length of hose, assures a positive latch of the hose
• Vibration-proof self-locking fasteners assures assembly integrity
• 304L grade of stainless steel
• Aluminum fluid path -standard latch parts are made from aluminum
• Quality finish and corrosion resistant - Stainless steel components offer the maximum protection from premature corrosion

Specifications

• Inlet/Outlet Size: 3/4 in. FNPT
• Hose Length Capacity: 75 ft.
• Max Pressure: 500 psi
• Max Temperature: 210°F
• Seal Type: Viton
• Swivel Material: Stainless Steel
• Fluid Path Casting: Aluminum
• Size Index: 2

Downloads

Series D80000 Hose Reel Manual (PDF Download)

Series D83000 Reel Dimensions (PDF Download)
