Reelcraft 5650 OLP-SE 3/8 in. x 50 ft. Premium Duty Hose Reel - Reel & Hose

Reelcraft Series 5005 hose reels are durable and compact for a wide range of applications with critical space requirements.

Features

• Hose is plumbed into the base to eliminate the risk of undue stress on the swivel
• The bent tube swivel design offers a smooth hose transition onto the spool
• The swivel is nested inside the spool for protection from impact and the environment
• Low-pressure 3/8 in. x 50 ft. PVC hose included; hose is for air or water service only
• Base plate and upright are constructed from 14 gauge steel; the guide arm is 13 gauge and the spool is 16 gauge steel
• The reliable speed latch allows for positive locking of the spool in two positions per rotation
• Individually powder-coated steel components provide maximum protection from premature corrosion
• Robotically welded steel base offers maximum strength and consistent quality
• Guide arm adjusts to two positions
• Made in the USA

Fluid Path Materials

• Internal Fluid Path: Steel
• Swivel Assembly: Copper
• Swivel Seal: Nitrile Rubber

Specifications

• Weight: 36 lbs
• Series: 5005
• Hose ID: 3/8 in.
• Hose OD: 0.600 in.
• Hose Length: 50 ft.
• Pressure: 300 psi
• Hose End: 1/4 in. NPT(M)
• Inlet: 3/8 in. NPT(F)
• Reel Outlet: 1/4 in. NPT(F)
• Hose Included: Yes
• Max Temperature: 150 °F
• UPC: 699567000167

Downloads

Product Manual
