Midland Industries 20082N 90° Push-to-Connect Swivel Male Elbow, 1/4 in. PTC x 1/4 in. Male Global Thread, Brass & Nickel-Plated

Midland Industries 20082N 90° Push-to-Connect Swivel Male Elbow, 1/4 in. PTC x 1/4 in. Male Global Thread, Brass & Nickel-Plated Description

The Midland Industries 20082N 90° Push‑to‑Connect Swivel Male Elbow is engineered for efficient, leak‑resistant connections in pneumatic and fluid transfer systems. Featuring a 1/4‑inch push‑to‑connect inlet and a 1/4‑inch male global swivel thread, this fitting allows quick installation while supporting flexible alignment during assembly. Constructed from robust brass and finished with nickel plating, it offers durability, corrosion resistance, and smooth swivel performance. Its compact elbow design enables streamlined directional changes, making it well‑suited for tight spaces and demanding industrial environments requiring dependable sealing and consistent operation under rated pressure and temperature conditions.

Features

• Push‑to‑Connect Design: Allows rapid tube installation without tools for efficient, secure connections.
• Swivel Male Thread: 1/4‑inch global swivel thread provides improved alignment and reduced stress during installation.
• Nickel‑Plated Brass Body: Offers enhanced corrosion resistance and long‑lasting durability.
• Compact 90° Configuration: Enables smooth directional changes within confined system layouts.

Specifications

• Connection Size: 1/4 in. x 1/4 in.
• Connection Type: Push‑to‑Connect | Male Global Swive
• Finish: Nickel‑Plated
• Fitting Type: 90‑deg
• Elbow Hex Size: 0.59 in.
• Material: Brass
• Pressure Rating: 290 psi
• Temperature Rating: -4 to 176 °F

Downloads

Product Literature (PDF Download)
