Faudi Aviation VFH-12 Vertical Filter Housing

The Faudi Aviation Vertical Filter Housing (VFH) assembly provides two element options to meet aviation filtration industry requirements: Coalescer/Separator and Microfilter (Pre-filter). The VFH system provides high economy efficiency and easy installation. It is designed and constructed for easy element change-out. The VFH is for use with JET Fuel, AVGas and MoGas.

When used as a coalescer/separator system consists of two elements to generate a two stage separation process. It is used to remove free water and fine solids- like rust, dirt and other contaminants from aviation fuels. The system is meets EI1581 6th edition specifications.

As a Microfilter it has a single stage element to remove fine solids down to one micron from aviation fuels. When contaminated fuel enters the vessel, fine solids are removed, providing clean fuel to engines one equipment. The microfilter is qualified to meet EI 1590 3rd Editions specifications.

Features

• Filter elements have excellent dirt holding capacity and high separation efficiency
• Simplified element change
• Easy maintenance

Specifications

• Design pressure: 145 PSI (10 bar)
• Flow Rate: 46 GPM (177 LPM)
• Inlet/Outlet port: G 1 1/2 in.
• Cover seal: Natural rubber (Buna-N)
• Locking ring collar
• Manual vent valve
• Manual drain valve
• Operating temperature: 14° to 122° F (-10° to 50° C)
• Material: Die-cast aluminum head and steel filter bowl
• Powdered coated components
