Balcrank AODD Pivot Series UP15 1 1/2 in. Aluminum Diaphragm Pump

The UP15 Pivot Series pump combines universal design with a unique frictionless Pivot-Shaft Air Valve to provide maximum performance and efficiency. The pump was designed for simplified cleaning and maintenance. All Pivot series pumps are designed for maximum fluid flow and reduced air consumption. The UP15 pump combines a conventional flow design with a pivoting air valve for increased reliability. This pump can transfer fluids up to 125 GPM. The pump can be used as a stand-alone pump for transfer applications or as a system pump for fluid distribution.

Balcrank does not recommend pumping windshield wash or any other fluid below 100° flash point.

Specifications

• Air inlet: 1/2in FNPT
• Fluid inlet port: 1 1/2 in. FNPT
• Fluid Outlet Port: 1 1/2 in. FNPT
• Max Flow Rate: 125 GPM (470 LPM)
• Air Pressure Range: 22 to 120 PSI ( 1.5 to 8 bar)
• Solid in suspension: 1/4 in. (6.4 mm)
• Body Material: Aluminum
• Recommended fluids: Anti-Freeze, , Lubricants and Hydraulic Oil
• Markets served: Car & Truck Dealers, Fleets, Lube Trucks, In-Plant Transfer, Mining & Construction, and Agriculture/Farm
• Recommended Applications: Very Large Volume Transfer, De-Watering and Fluid Evacuation

Downloads

Specifications (PDF Download)

Manual (PDF Download)
