CS0122 NOZZLES | SWIVELS | PUMPS | FILTERS | REELS | HOSE | ACCESSORIES Phone 800-333-3331| Website JMEsales.com| Fax 800-563-8848 24-Hour Availability CAT# CS0122 45 YEARS OF EXCELLENCE
The BESTpit-stop for keeping every traveler fueled up and on the road. JME painstakingly scours the nation for the latest & greatest technologies and products to keep your business profitable, as well as running safely and efficiently. Put decades of knowledge to use and contact one of our experienced sales employees today. You’ll get the best product for your application shipped to you right away - at a great price, too! ELECTRIC VEHICLE CHARGING STATIONS Amps2Go Series 6 Smart EV Charging Station Dual Port Pedestal Station Gilbarco Tritium RT175-S DCFC Fast Charge Dual Electric Vehicle Charging Stations Bosch EV800 Series Electric Vehicle Bollard Charge Station PAGE 121 PAGE 122 PAGE 122
SECTION HIGHLIGHTS Quick Reference See a complete alphabetical index on pages125-126 NOZZLES Pages 5-13 BREAKAWAYS & SWIVELS Pages 10-18 DEF Pages 109121 CONTACT US TOLL FREE : 800-333-3331 LOCAL: 414-354-1414 FAX: 800-563-8848 E-MAIL: info @ jmesales.com or PurchaseOrder@jmesales.com 24/7 ONLINE ORDERING: www.jmesales.com Hours: Monday – Friday, 7:00 a.m. – 6:00 p.m. CST JOHN M. ELLSWORTH COMPANY, INC. P.O. Box 240072 • 8700 West Bradley Road • Milwaukee, Wisconsin 53224 Air Machines ...................... 50-51 Breakaways & Swivels .........10-18 DEF Equipment ............... 109-121 Dispenser Parts.................. 38-39 Drum Handling ....................97-99 Drum Pumps ........... 63-67, 79-82 Exhaust Hose ......................87-89 Fill Caps & Adapters ................ 25 Filters ..................................... 2-4 Fuel Containers ......................108 Grease Dispensing ............. 73-77 Gloves ..................................... 84 Hose .................. 19-20, 77, 85-89 Lube Oil Transfer .................61-72 Manholes............................ 28-31 Nozzles & Accessories ..........5-16 Pumps ..................... 63-67, 79-82 Reels.................................. 90-95 Sorbents.......................... 104-107 Sticks & Paste .................... 32-33 Tool Balancers......................... 96 Waste & Windshield............ 55-56 FULLLINE ATJMESALES.COM
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 2 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! • Innovative cup design is engineered to grip the filter and catch fuel when replacing dispenser filters...no mess! • Allows for faster change-outs and less dispenser downtime • Cup helps to avoid getting fuel directly on hands/skin and getting spills in sump • Fuel filter cup can be used on all brands & styles of fuel filters at the dispenser EZ-GRIP FILTER CUP Easily remove fuel filters at the dispenser! Model # Each CIM60070 $23.66 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Part # Each 1″-12 UNF 10 70059 40510W CIM300HS10II $9.16 1″-12 UNF 30 70064 40530W CIM300HS30II 9.12 Size Micron Cimtek # Petro Clear # Part # Each 1″-12 UNF 2 70806 N/A CIM70806 $10.08 1″-12 UNF 10 70010 40510P CIM30010 6.31 1″-12 UNF 30 70012 40530P CIM30030 6.13 1″-12 UNF 10 70058 N/A CIM300BMG10 14.24 Size Micron Baldwin # Part # Each 1″-12 UNF 15 BF955 BF955 $11.30 PARTICULATE REMOVAL Size Micron Cimtek # Media Part # Each 1″-12 UNF 10 70122 Microglass CIM300MB10 $11.88 1″-12 UNF 30 70018 Microglass CIM300MB30 11.66 MULTI-FUEL MONITOR FILTERS, 5.5" (Formerly Alcohol Monitors) This filter's exclusive design detects phase separation in ethanol blends AND water in straight gasoline. They offer the same great quality as before: surge supressing spring, pre-lubed gaskets, high efficiency microglass media, UL approved – and Made in the USA! An economical filter for use with service station dispensers pumping up to 25 gpm. Dresser and Tokheim Dispensers. FUEL FILTERS How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW 300 SERIES • Brand: Baldwin • Model: BF955 • Type: Fuel Storage Tank Spin-on • Style: Fuel Filter • Outside Diameter: 3 11/16 in. (93.7 mm.) • Length: 5 3/8 in. (136.5 mm.) • Micron Rating: 4 Nominal; 15 Absolute • Related To: BF971 (Long Version) • Thread Size: 1-12 • Includes: I. Gasket: G381-A • Application: Purolator Optional Filter Housings • Compatible With: Cim-Tek 700-10; Purolator F54725, F71601 • Notes: Can be used with FB1307, FB46183 bases. Baldwin's BF955 Spin-On Fuel Dispenser Filter helps protect engines and fuel system components from the damaging effects of contaminants such as water, fungus and bacteria, precipitates, particulates, and wax. The BF955 utilizes Microlite®filter media to trap harmful contaminants, without removing the important additives in the fuel. BALDWIN FILTERS BF955 SPIN-ON FUEL DISPENSER FILTER, 1IN. THREAD, 15 MICRON NEW 2022
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 3 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! An economical filter for use with Gilbarco® Advantage Series service station dispensers. PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Part # Each 1½″-16 UNF 2 70808 N/A CIM40002 $11.80 1½″-16 UNF 10 70015 40510PAD CIM40010 8.96 1½″-16 UNF 30 70016 40530PAD CIM40030 8.82 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Part # Each 1½″-16 UNF 10 70060 40510WAD CIM400HS10II $11.14 1½″-16 UNF 30 70065 40530WAD CIM400HS30II 11.01 MULTI-FUEL MONITOR FILTERS, 5.5" (Formerly Alcohol Monitors) Thisfilter's exclusive design detects phase separation in ethanol blends AND water in straight gasoline. They offer the same great quality as before: surge supressing spring, pre-lubed gaskets, high efficiency microglass media, UL approved – and Made in the USA! Size Micron Cimtek # Media Part # Each 1½″-16 UNF 10 70120 Microglass CIM400MB10 $12.89 1½″-16 UNF 30 70106 Microglass CIM400MB30 12.44 PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Part # Each 1½″-16 UNF 2 70814 N/A CIM80002 $28.68 1½″-16 UNF 10 70019 51110P CIM80010 19.59 1½″-16 UNF 30 70020 51130P CIM80030 18.53 1½″-16 UN 10 70028 N/A CIM800BMG10 34.06 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Part # Each 1½″-16 UNF 10 70063 51110W CIM800HS10II $27.68 1½″-16 UNF 30 70068 51130W CIM800HS30II 27.45 An economical filter for use with high-flow commercial fueling centers. FUEL FILTERS How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW 400 SERIES 800 SERIES Size Capacity Flow-Rate Part # Each 1½″-16 UNF 10 Micron 25 GPM PC40510PAD $7.81 • For high-flow fuel dispensers • Designed for particulate removal only (10 micron) • Compatible with neat gasoline, ethanol blended fuels and all diesels, including biodiesel fuels • Textured paint coating helps ensure a simple, mess-free installation and removal process • UL® recognized PETROCLEAR 40510P-AD 10 MICRON PARTICULATE HIGH FLOWSPIN-ON FUEL DISPENSER FILTER NEW 2022
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 4 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! E85is the term for motor fuel blends of 85% ethanol & 15% gasoline. It is defined as an alternative fuel by the U.S Dept. of Energy. Ethanol burns cleaner than gasoline & is a completely renewable fuel. Biodiesel is a name used for cleaner burning alternative fuel produced by domestic, renewable resources. It contains no petroleum, but can be blended at any level with petroleum diesel to create a biodiesel blend. It can be used in compressionignition diesel engines without major modifications. Biodiesel is simple to use, biodegradable, nontoxic and essentially free of sulfur and aromatics. Find more info about alternative fuels at www.JMEsales.com For all your industrial filters, cartridges and assemblies, visit our website at www.JMEsales.com You'll find them after SHOP BY CATEGORYin theFILTERSsection. Also search for Racor. BIO-TEK HIGH ALCOHOL FILTER (PARTICULATE FILTER) Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 1 70025 12 CIM300BHA01 $31.39 1½″-16 UNF 1 70039 12 CIM400BHA01 34.65 1½″-16 UNF 5 70991 12 CIM400BHA05 27.52 BIO-TEK HYDROGLASS FILTER (PARTICULATE & WATER REMOVAL FILTER) For Ethanol Blends Up to E15 and Biodiesel Up to B100 Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 2 70232 12 CIM70232 $21.80 1″-12 UNF 10 70236 12 CIM70236 20.07 1½″-16 UNF 2 70037 6 CIM70037 37.03 1½″-16 UNF 10 70024 6 CIM70024 36.53 BIO-TEK MICROGLASS FILTER (PARTICULATE FILTER) For Ethanol Blends Up to E15 and Biodiesel Up to B100 Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 2 70230 12 CIM260BMG02 $21.65 1″-12 UNF 10 70234 12 CIM260BMG10 20.05 1⅜″-12 UNF 2 70221 12 CIM260ABMG02 23.31 1⅜″-12 UNF 10 70225 12 CIM260ABMG10 22.25 1″-12 UNF 2 70057 12 CIM300BMG02 14.67 1″-12 UNF 10 70058 12 CIM300BMG10 14.24 1½″-16 UNF 2 70105 12 CIM400MG02 18.02 1½″-16 UNF 10 70104 12 CIM400BMG10 15.41 1½″-16 UNF 2 70036 6 CIM800BMG02 35.43 1 ½″-16 UNF 10 70028 6 CIM800BMG10 34.06 FUEL FILTERS How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW E85, M85, B100
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 5 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! OPW 11B® SERIES – AUTOMATIC PREPAY NOZZLES The 11B® series of automatic nozzles is OPW’s premium, conventional, prepay nozzle for safe retail and commercial petroleumfilling. The 11B® and 11BP® nozzles are designed for use in retail and commercial filling applications (including prepay, self- and full-service, credit and debit card readers or card-lock systems) to help prevent gasoline spills. These nozzles will not open until the pumping system is pressurized and will close automatically when the pressure is removed. All of the nozzles in this series have a ¾" inlet. Safe for Use • UL and ULC listed for use in gasoline, diesel and up to 10% ethanol blends • FlowLock™ allows nozzles to shut off when falling out of a vehicle, and tipped up, limiting spillage and unsafe conditions Design Working Pressure • 50 PSI maximum pressure Construction • Body: Aluminum • Lever & Lever Guard: Duratuff® • Packing: Graphite with Teflon® • Disc: Viton® • Spout: Aluminum (SS Tip) • Inlet Size: 3/4" NPT • Weight: 2.73 lbs. each UL 2586 COMPLIANT The world’s BESTSELLING nozzle! Color Part # Each Green OPW11BP0100 $62.71 Silver OPW11BP0200 65.96 Red OPW11BP0300 62.70 Black OPW11BP0400 62.71 Blue OPW11BP0500 62.71 Orange OPW11BP0800 65.96 Yellow OPW11BP0900 62.71 Color Part # Each Green MCN8UOG $56.98 Silver MCN8UOS 56.98 Gold MCN8UOGO 56.98 Red MCN8UOR 56.98 Black MCN8UOB 56.98 Blue MCN8UOBL 56.98 White MCN8UOW 56.98 Yellow MCN8UOY 56.98 PREPAY UNLEADED NOZZLES PREPAY UNLEADED NOZZLES 5-STAR "S" CONVENTIONAL NOZZLES Made in the USA 5-STAR“S” NEW¾" AUTOMATICPREPAY NOZZLES New, lightweight automatic gasoline nozzle is ideal for prepay locations. It has a pressure-activated secondary shut-off that prevents fuel flow until the system is pressurized. "One hand" hold-open clip with patented "kicker" feature provides positive clip release with automatic shut off. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Kicker clip feature provides 100% clip release • Super Tuff nylon hand guard and lever • Viton seals & poppet disc for fuel blends up to E25 & biodiesel • ¾" NPT inlet 10 GPM UL 2586 COMPLIANT PREPAY ONLY! UNLEADED NOZZLES
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 6 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! Color Part # Each Black HU15950404 $85.00 Color Part # Each Black HU119040404 $400.74 ¾" 11BP SERIES ETHANOL NOZZLES - E85 The OPW 11BP Series Ethanol nozzles are designed and rigorously tested for use in today’s alternative fuels. It’s thefirst nozzle of its kind to be UL-Listed for use in Ethanol-blended fuels up to 85%. • Prevents gasoline spills in prepay or card-lock systems utilizing OPW’s unique No Pressure – No Flow Device; it cannot be opened until the pumping system is pressurized, and closes automatically when the pressure is removed • Prevents consumer from jamming the nozzle in an open position – blocker on lever guard • FlowLock™ allows nozzle to shut-off when falling out of a vehicle, and is sped up, limiting spillage • Durable lever guard won’t scratch customers’ vehicles • New hold-open clip spring lasts longer than previous designs (not on all models) • Uses Accu-Stop® to-the-penny Flow Control Technology • Comfortable, attractive 2-piece NEWGARD™ hand insulator • 50 PSI maximum pressure Color Part # Each Black OPW11BP0492E85 $203.29 Yellow OPW11BP0992E85 203.29 XS UNLEADED AUTOMATIC SHUT-OFF NOZZLE WITH HOLD-OPEN CLIP • The XS® nozzle shuts off when: the pump shuts off, the gas tank is full, the lever is opened before the pump is turned on or the leak detector has not completed the test cycle • Stainless steel spout bushing keeps spout tip round and acts as a captive fastener to prevent tip- end sensor damage • Equipped with a unique FloStop® device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal • StreamShaper® reduces turbulence for straighter uel flow and less splash back spillage • Comes standard with smooth, full grip guard • Body: One-piece die cast aluminum • Seals: Fluorocarbon • Packing: Double o-ring seal protected by fiber reinforced Teflon® • Lever: One-piece reinforced polymer • Inlet: ¾" (19.1 mm) NPT threads MICRO-FLOW1000 UNLEADED NOZZLE, 1" INLET This automatic gasoline nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals for fuel blends up to E25 and biodiesel • 1" NPT inlet, 13⁄16" spout UL 2586 COMPLIANT UL 2586 COMPLIANT UL 2586 COMPLIANT UL 2586 COMPLIANT UL Part # Each MCN1SLOB $69.62 MCN1SLOG 69.62 MCN1SLOY 72.85 Color Black Green Yellow UNLEADED NOZZLES • Unique internal interlock device that shuts off the fuel flow before the spout is out of the tank • Aluminum casting with high impact polymer hand guard provides a lightweight, easier to handle conventional nozzle • 2-piece lever requires 1/2 the force to use and is ADA compliant • A reinforced stainless steel spout bushing keeps spout tip round and acts as a captive fastener to prevent tip-end sensor damage • Drip Less spout reduces/eliminates drips from spout • StreamShaper® reduces turbulence for straighter fuel flow and less splash back spillage • Lightest insertion “force” of any safety interlock operated nozzle • Comes standard with smooth full grip guard • Unique tilt poppet maximizes “to-the-penny” dispensing • CARB compliant for drips, spills, spitting and liquid retention The OPW 11B Series is the most trusted conventional nozzle in the world for full service use. The OPW 11B Series is designed for use in retail and commercial filling applications including prepay, self and full service, credit/debit card readers or card-lock systems to help prevent gasoline spills. The OPW 11B will not open until the pumping system is pressurized, and closes automatically when the pressure is removed. HUSKY 3/4IN. ECO ENHANCEDCONVENTIONAL NOZZLE, UL LISTED, CARB CERTIFIED
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 7 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! DIESEL NOZZLES BIG MOUTH S DIESEL NOZZLE UL 2586 COMPLIANT HIGH FLOW NOZZLES The MCDS is a highflow automatic diesel nozzle. Ideal for the high volume truck stops and for fast refueling at fleet terminal operations. This nozzle is equipped with a pressure sensitive valve that only allows the nozzle to open when the pumping system is pressurized. As soon as the pressure drops it will automatically close. Ideal for prepay and card lock locations. • Super tough nylon Handguard • Pure Teflon stem packing eliminates leaks • Roto matic latch pin for smoother auto shut off • Kicker assures the hold open clip will always release when automatic shut off occurs MCD HIGH FLOWNOZZLES Pressure Activated? Part # Each Yes MCN9OG 129.50 The lightweight Big Mouth S diesel nozzle provides efficient refueling and durability at an economical price. Classic rear hold open clip. This automatic diesel nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure-activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Brass tip end holds more securely in the spout – doesn't crack • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals and poppet disc for fuel blends up to E25 and biodiesel • 1" NPT inlet and 1⅛" aluminum spout Part # Each MCN3SOY $87.19 UL 2586 COMPLIANT Color Part # Each Green OPW11B0100 $64.22 Red OPW11B0300 64.22 Black OPW11B0400 64.22 Blue OPW11B0500 65.96 Yellow OPW11B0900 64.22 PREPAY DIESEL NOZZLES OPW 11B® SERIES – AUTOMATIC PREPAY NOZZLES The 11B® series of automatic nozzles is OPW’s premium, conventional, prepay nozzle for safe retail and commercial petroleumfilling. The 11B® and 11BP® nozzles are designed for use in retail and commercial filling applications (including prepay, selfand full-service, credit and debit card readers or card-lock systems) to help prevent gasoline spills. These nozzles will not open until the pumping system is pressurized and will close automatically when the pressure is removed. All of the nozzles in this series have a ¾" inlet. Safe for Use • UL and ULC listed for use in gasoline, diesel and up to 10% ethanol blends • FlowLock™ allows nozzles to shut off when falling out of a vehicle, and tipped up, limiting spillage and unsafe conditions Durable & Long Lasting Design • Cycle tested and proven to last longer than 1 million cycles – better than any other nozzle available on the market today • Stainless steel spout tip lasts four times longer than standard aluminum spouts • Durable lever guard won’t scratch your customers’ vehicles – made from Duratuff® Design Working Pressure • 50 PSI maximum pressure Construction • Body: Aluminum • Lever & Lever Guard: Duratuff® • Packing: Graphite with Teflon® • Disc: Viton® • Spout: Aluminum (SS Tip) • Inlet Size: 3/4" NPT • Weight: 2.73 lbs. each UL 2586 COMPLIANT 25 -30 GPM
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 8 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! PREPAY DIESEL NOZZLE 7HB SERIES – PRESSURE ACTIVATED FOR PREPAY/SELF SERVE M. CARDER FUELMASTER PREPAY HIGH FLOWDIESEL NOZZLE Color Part # Each Green OPW7HB0100 $121.83 Black OPW7HB0400 128.29 Yellow OPW7HB0900 121.83 Retaining Ring FUELMASTER S DIESEL NOZZLE The Fuelmaster is highflow automatic diesel nozzle designed to meet the higher capacity fueling requirements at high volume truck stops and terminal operations. This nozzle has the traditional rear hold open clip that is preferred by many customers. The Fuelmaster has been in continuous production over 25 years. The exceptional durability and reliability are the results of many years of innovations and refinements that are incorporated into the current model. 1 Year Warranty • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Brass tip end holds more securely in the spout – doesn't crack • Super Tuff nylon hand guard and hold-open clip • Viton seals and poppet disc for fuel blends up to E25 and biodiesel • 1" NPT inlet • 13⁄16" aluminum spout Part # Each MCN4SOB $112.72 UL 2586 COMPLIANT 30 GPM If you operate a full-service truck stop, refuel your ownfleet or manage a cardlock refueling location, the low cost, long life and durability of the OPW 7HB® Series of nozzles can help increase your productivity, sales and profits. 13/16" spout. SAFE FOR USE • UL and ULC listed for use in gasoline, diesel and up to 10% ethanol blends. • Prevents gasoline spills in prepay or cardlock systems utilizing OPW’s unique “No Pressure – No Flow Device.” The nozzle cannot be opened until the pumping system is pressurized, closing automatically when the pressure is removed. • Prevents consumer from jamming the nozzle in an open position – blocker on lever guard. • FlowLock™allows nozzle to shut-off when falling out of afill pipe (tipped up), limiting spillage and unsafe conditions. • Low, reliable shut-off – specifically designed to ensure proper automatic shut-off as low as 5 gallons per minute. DURABLE & LONG LASTING DESIGN • Cycle tested and proven to last longer than 1 million cycles – better than any other nozzle available on the market today.* • Durable lever guard that won’t scratch your customers’ vehicles – made from Duratuff® . • New hold-open clip spring lasts longer than previous designs. APPEALING TO CUSTOMERS • Easy to use – utilizing Accu-Stop® to-the-penny flow control technology. • Easy to open, even at high pressures, utilizing dual poppets. • Even, smooth spray pattern – minimizes diesel foaming and false shut-offs. • Smooth closing action and reduced line shock from incorporated dashpot technology. • Convenient – one-finger hold-open clip that is easy to set theflow rate. • Spout retaining ring – adds extra measure in securing nozzle spout infill pipe where required. DESIGN WORKING PRESSURE • 50 PSI maximum pressure. DIESEL NOZZLES
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 9 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! MAX 1 AUTOMATIC 1" DIESEL PREPAY NOZZLE The Max 1 diesel nozzle is designed for durability. This heavy-duty nozzle can be used in high-volume truckstop applications as well as a high-volume service station diesel nozzle. This nozzle is a prepay, no-pressure, no-flow nozzle. The prepay nozzle is specifically designed for unattended self-service and cardlock refueling locations. The prepay feature enables the station operator to control the dispensing of fuel. Either nozzle can be configured to meet the customer’s specific needs. The Max 1 has a 1" NPT inlet with a 1-3⁄16" OD aluminum spout. • Single body, sand cast aluminum construction • Lever and handguard are Super-Tuff glass filled nylon • O-rings and seals are Viton™ • One-hand, hold open mechanism • Dashpot minimizes line shock • Rugged design • All nozzles available as self serve • UL/ULC Listed • Longer spout with anchor bushing • Attitude device MIGHTY MAC DIESEL NOZZLE The Mighty Mac diesel nozzle is designed to provide efficient service for diesel island car, truck, bus and fleet fueling. This single poppet nozzle delivers consistent flow rates of 25+ GPM. Durable and tough, the Mighty Mac is the most economical answer to your diesel needs. • Available as full serve or self serve; automatic shutoff • Completely rebuildable • All major oil company colors available • Custom logo available upon request • BSPP and BSPT threads available upon request • Rugged heavy duty design • Spout easily replaced • Full scuff guard provided for added protection Part # Each CLN1AH $77.96 Part # Each CLN1AL $72.47 CLASSIC 1A DIESEL AUTOMATIC NOZZLE The Catlow Classic 1A nozzle is the most durable aluminum nozzle in petroleum history. The design of this nozzle was the forerunner of all standard gasoline dispensing nozzles today. Utilizing a single poppet in this nozzle affords smooth flow from high GPMs to minimal flow rates. This true 1" NPT nozzle is completely rebuildable and can be used for unleaded fuel as well as diesel refueling. • Available as full serve or self serve • Unleaded or leaded (diesel) spout assembly • All major oil company colors available • Automatic shutoff • UL/uLC Listed • Custom logo available • BSPP and BSPT threads available • Attitude device (AD) available MICRO-FLO1000 DIESEL NOZZLE, 1" INLET This automatic gasoline nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals for fuel blends up to E25 and biodiesel • 1" NPT inlet, 15⁄16" spout Color Part # Each Black CLNM1PARADBK $150.21 Green CLNM1PARADGR 150.21 Additional colors and custom logo available on request Color UL Part # Each Black MCN1SLOB $69.62 Green MCN1SLOG 69.62 Yellow MCN1SLOY 72.85 CALL OR SEARCH ONLINE FORQUANTITY DISCOUNTS! UL 2586 COMPLIANT DIESEL NOZZLES DIESEL NOZZLES
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 10 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! COLD WEATHER PRODUCTS COLD WEATHER NOZZLES The OPW241TPS provides two-plane swiveling rotation for easy nozzle positioning and reduced hose wear. The OPW 241TPS swivel is designed for cold weather applications where easy nozzle and hose handling is important for customer convenience. The OPW241TPS is installed between the nozzle and hose to reduce customer strain, provideflexibility and reduce premature hose wear. OPW 241TPS DUAL PLANE COLD WEATHER SWIVELS Size Part # Each 3/4" OPW241TPS0241C $24.75 1" OPW241TPS1000C 49.38 COLD WEATHER SWIVELS The OPW 11B Series is the most trusted conventional nozzle in the world for full service use. The OPW 11B Series is designed for use in retail and commercial filling applications including prepay, self and full service, credit/debit card readers or card-lock systems to help prevent gasoline spills. The OPW 11B will not open until the pumping system is pressurized, and closes automatically when the pressure is removed. • Durable and long-lasting design • Compatible to -54°C (-65°F) • Cycle-tested and proven to last longer than 1 million cycles - Better than any other nozzle available on the market today • Durable lever guard that won’t scratch your customers’ vehicles – Made from Duratuff® • New hold open clip spring lasts longer than previous designs. (OPW 11B® and 7HB® Series Only) • Easy to use – Utilizing Accu-Stop® to-the-penny Flow Control Technology OPW 11BP EXTREME COLD WEATHER UNLEADED NOZZLE 3/4IN. NPT INLET 13/16IN. SPOUT Colors Part # Each Green OPW11BP0100XC $81.36 Black OPW11BP0400XC 81.36
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 11 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! COLD WEATHER NOZZLES If you operate a full-service truck stop, refuel your ownfleet or manage a card-lock refueling location, the low-cost, long-life and durability of the OPW 7HB high flow nozzle can help increase your productivity, sales and profits. The OPW 7HB will not open until the pumping system is pressurized, and closes automatically when the pressure is removed. • Durable and long-lasting design • Compatible to -54°C [-65°F]* • Cycle-tested and proven to last longer than 1 million cycles - Better than any other nozzle available on the market today* • Durable lever guard that won’t scratch your customers’ vehicles – Made from Duratuff®. • New hold open clip spring lasts longer than previous designs. (OPW 11B® and 7HB® Series Only) • Easy to use – Utilizing Accu-Stop® to-the-penny Flow Control Technology. OPW 7HB EXTREME COLD WEATHER DIESEL TRUCK STOP NOZZLE 1IN. INLET 1 3/16IN. SPOUT Colors Part # Each Green OPW7HB0100XC $163.72 Black OPW7HB0400XC 163.72 Yellow OPW7HB0900XC 163.72 DIESEL NOZZLES The OPW 11 Series automatic nozzles are OPW’s premium conventional nozzles for safe retail and commercial petroleumfilling. The OPW 11 Series is the most trusted conventional nozzle in the world for full service use. The OPW 11B Series is designed for use in retail and commercial filling applications including prepay, self and full service, credit/debit card readers or card-lock systems to help prevent gasoline spills. The OPW 11B will not open until the pumping system is pressurized, and closes automatically when the pressure is removed. The OPW11B nozzle has a 3/4" NPT inlet with a 15/16" OD spout which is designed for fueling diesel automobile's and light trucks. • UL and ULC listed for use with diesel fuel. • Prevents consumer from jamming the nozzle in an open position – Blocker on lever guard. • FlowLock allows nozzle to shut-off when falling out of a vehicle, and tipped up limiting spillage and unsafe conditions. • Compatible to -64° F • Cycle tested and proven to last longer than 1 million cycles - Better than any other nozzle available on the market today • Durable lever guard that won’t scratch your customers’ vehicles – Made from Duratuff. • New hold open clip spring lasts longer than previous designs. • Easy to use – Utilizing Accu-Stop to-the-penny Flow Control Technology. OPW EXTREME COLD LIGHT TRUCK AND CAR DIESEL NOZZLE 3/4IN. NPT INLET 15/16IN. SPOUT Colors Part # Each Green OPW11B0100XC $81.36 Black OPW11B0400XC 81.36 Yellow OPW11B0900XC 81.36
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 12 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! VAPOR BALANCE NOZZLE & BREAKAWAYS HUSKY BREAKAWAY Valve poppets - close on both ends of breakaway to limit fuel spillage. Easy, two-hand, "pushn-twist" reconnect - to help put dispenser back in service quickly. Rugged, durable construction - Duratuff® outer sleeve to protect coupling and sealing parts from damage, for long, trouble-free service life. • All Husky Safe-T-Breaks stop theflow of fuel on both sides of the separation • For balance systems: coaxial hoses with fuel “inside” hose, vapor return in “outside” hose • Reconnects with only 10–12 lbs. force OPW PHASEII ENHANCEDVAPORRECOVERY RECONNECTABLE BALANCE BREAKAWAY For more than a decade, the 66CLP has earned the reputation as the industry standard in preventing fuel vapors from escaping during a separation incident on balance systems. Its proven design minimizes downtime and allows all hose points to be put back in service as quickly and easily as possible after a separation event. The OPW 66CLP is also approved for VST Phase II Enhanced Vapor Recovery Systems. • UL listed: gas, diesel and up to 10% ethanol blends • Separates at 300 pounds of axial force • Push-back reconnect style • Durable, lightweight construction • Minimal pressure drop • 50 PSI maximum pressure Part # Length Threads Each HU3360VR 6.87 1 7/8" x 12 $136.05 NOW CARB EVR CERTIFIED Still using vapor balance nozzles? We continue to offer a full line of products for your pumps: nozzles, breakaways, swivels and hose. If you don't see it in this catalog or on our website, JMEsales.com, please call for a customized quote. Part # Each OPW66CLP5100 $235.51 VAPOR RECOVERY EQUIPMENT
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 13 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! VACUUM ASSIST NOZZLES & BREAKAWAYS EMCOWHEATON BALANCE SYSTEMVAPOR RECOVERY NOZZLES Developed to be user friendly, the A4005/A4015 Vantage nozzles utilize the most up-to-date vapor recovery technology available. The A4005/A4105 offers the same lightweight and streamlined design advantages characteristic of the A4000 series product line. A low restriction vapor valve is built into the A4005/A4105 so it does not require an external vapor valve. This nozzle includes the no-seal, no-flow interlock mechanism and automatic shutoff for reliable, safe operation. It also has an internal pressure shutoff to detect vapor blockage. Approved to UL 2586 specification (no hold-open clip). Spout Part # Each Long EWA4005NUL $264.71 Short EWA4015NUL 261.76 Part # Each HU625004104 $293.38 V34 VACUUMASSIST AUTOMATIC NOZZLE Vapor Assist Part # Each Complete CLCTMVA $151.30 Lower Half Only CLCTMVAL 58.97 CAM TWIST™ MAGNETIC IN-LINE BREAKAWAY • Durable plastic cover prevents damage to the breakaway during a drive off • No repair kit needed • Maximum separation force is less than 300 lbs. • One year warranty • Minimal flow restriction • Seals both ends of the breakaway • Magnetic snap-back technology • Lightweight • UL/ULC listed • Carb Certified • Meets NFPA 30A codes • Inspectable, no need for "remove by" date Part # Each OPW66CAS0300 $167.71 66CAS0300 BREAKAWAY Engineered to separate at a max. 300 lbs. of axial pull force, this breakaway will withstand line shocks up to 250 PSI disconnect force while protecting your dispensing system from catastrophic damage. Developed for use with inverted coaxial metric hoses and designed to meet today’s demanding standards. • Dual poppets close to prevent product spillage, vapor leakage • Requires only 15 lbs. of force to reconnect • Designed to help prevent liquid from spraying the operator during the reconnection operation • Outer sleeve to protect coupling and sealing parts from damage for long, trouble-free service life • CARB Certified and UL Listed per Standard 567 Pressure activated for self service, full service and unattended stations. • Unleaded • Standard hold-open clip • Spout covered by 1-year warranty • UL Listed, CARB Certified • Made in the USA • Automatic shut-off and equipped with a unique FloStop device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal VAPOR RECOVERY EQUIPMENT
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 14 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! • Enhances the appearance of your gasoline nozzle • More pleasant for your customers • Won’t deform or crack in cold weather SPLASH SHIELDS SPLASH SHIELDS Part # Maker Color Material Each OPW8R0300 OPW Red Rubber $8.79 OPW8Y0900 OPW Yellow Rubber 8.79 OPW8G0100 OPW Green Rubber 8.79 OPW8B0500 OPW Blue Rubber 8.79 OPW8BL0400 OPW Black Rubber 8.79 OPW8S0200 OPW Silver Rubber 8.79 OPW8GL0750 OPW Gold Rubber 8.79 MCS//GRED M. Carder Red HD Rubber $6.27 MCS//GYELLOW M. Carder Yellow HD Rubber 6.27 MCS//GGREEN M. Carder Green HD Rubber 6.27 MCS//GBLUE M. Carder Blue HD Rubber 6.27 MCS//GBLACK M. Carder Black HD Rubber 6.55 FOR 11A/AP, 11B/BP & 21GE NOZZLES Part # Maker Color Material Each CLC176BK Catlow Black Rubber $5.66 CLC176GR Catlow Green Rubber 5.66 CLC176Y Catlow Yellow Rubber 5.66 HU180802 Husky Red HD Rubber 7.55 HU180805 Husky Yellow HD Rubber 7.55 HU180816 Husky BP Green HD Rubber 7.55 HU180803 Husky Green HD Rubber 7.55 HU180801 Husky Blue HD Rubber 7.55 HU180804 Husky Black HD Rubber 7.55 HU180809 Husky Silver HD Rubber 7.55 HU180808 Husky Gold HD Rubber 7.55 FOR 7H DIESEL NOZZLES
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 15 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! • Enhances the appearance of your gasoline nozzle • More pleasant for your customers • Won’t deform or crack in cold weather SCUFF GUARDS SCUFF GUARDS Part # Maker Color Each OPW6HKR0300 OPW Red $17.62 OPW6HKY0900 OPW Yellow 17.62 OPW6HKG0100 OPW Green 17.62 OPW6HKB0500 OPW Blue 17.62 OPW6HKBL0400 OPW Black 17.62 OPW6HKS0200 OPW Silver 17.62 OPW6HKGL0750 OPW Gold Call for Pricing MCG079RED M. Carder Red 7.60 MCG079YELLOW M. Carder Yellow 7.60 MCG079BLUE M. Carder Blue 7.60 MCG079BLK M. Carder Black 7.60 Part # Maker Color Each OPW6BR0300 OPW Red $17.22 OPW6BY0900 OPW Yellow 19.89 OPW6BG0100 OPW Green 19.89 OPW6BB0500 OPW Blue 15.79 OPWE00308M OPW Black 16.43 OPW6BS0200 OPW Silver 19.89 OPW6BGL0750 OPW Gold 19.89 Part # Maker Color Each OPW6SY0900 OPW Yellow $19.40 OPW6SG0100 OPW Green 19.40 OPW6SBL0400 OPW Black 16.70 Part # Maker Color Each OPW6SBY0900 OPW Yellow $19.40 OPW6SBG0100 OPW Green 19.40 OPW6SBBL0400 OPW Black 19.40 FOR 11A/AP UNLEADED NOZZLES FOR 11B/BP UNLEADED PREPAY NOZZLES FOR 7H DIESEL NOZZLES FOR 7HB DIESEL PREPAY NOZZLES Description Part # Each Adapter Only (Balance System) MCAV34B $29.70 Adapter Only (Vacuum Assist System) MCAV34V 29.70 Adapter Only (Healy System) MCAV34VH 29.70 TRANSITIONAL CONVERSION ADAPTER KITS AV34B AV34V AV34VH Inlet: Balance Vacuum Healy Outlet: ¾" NPT ¾" NPT ¾" NPT O-Rings: Viton — — Diameter: 2½" 1½" 1½" Length: 2½" 2½" 2½" M. CARDER TRANSITIONAL CONVERSION ADAPTER KITS The EPA and most state environmental agencies will permit convenience stores/service stations to change from vapor recovery to standard fueling equipment. Canisters on vehicles now capture the vapor when fueling.
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 16 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! REPLACEMENT SPOUTS We carry nozzles from all of the major manufacturers: OPW, Husky, Emco-Wheaton, M. Carder and Morrison Bros. – just to name a few. Description Part # Each 1A-Leaded/Auto-Diesel MCS1AN $15.30 1AP-Unleaded MCS1APN 15.30 11A-Leaded/Auto-Diesel MCS7BN 15.30 11AP-Unleaded MCS7BPN 15.30 Fuelmaster-Diesel MCSFMN 33.99 Big Mouth-Diesel MCSBMN 20.90 7H-Diesel 7″ Long MCS7HN 33.99 7H-Diesel 12″ Long MCS7HNL 73.71 11B-Leaded/Auto-Diesel MCS7BNB 15.30 11BP-Unleaded MCS7BPNB 15.30 7HB-Diesel Prepay OPW5BBH0136 66.39 Husky VIII HU2279 64.57 MCS7HN MCS7BN Mix and match for quantity breaks! CLARENCE SAYS: NOZZLE COVERS Made of tough vinyl plastic–simply slips over the nozzle. Available in red or yellow. *NOTE: Prices are for cases of 12. Color Part # Case* Yellow TSN79780059 $12.90 Red TSN79780062 12.90 SINGLE PLANE HOSE AND PUMP SWIVELSALUMINUM & BRASS Description Part # Each ¾" – Straight Swivel MCAWS34 $21.01 1" – Straight Swivel MCAWS10 32.01 ¾" x ¾" – 90° Swivel MCAWSP349 53.07 1" x ¾" – 90° Swivel MCAWSP1349 56.24 1" x 1" – 90° Swivel MCAWSP119 76.42 TURNS EASILY AND DOESN'T LEAK All of M. Carder's single plane swivels are machined of aluminum and brass bar stock. The precision-machined surfaces provide the strongest, the best and the smoothest surface for the o-rings to seal between two swivel halves. No Leaks! Brass male end prevents galling in the aluminum nozzle castings. Straight Swivels Ask us about single plane high-flow swivels! NOZZLE ACCESSORIES
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 17 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! Size Part # Each 3⁄4" x 3⁄4" MCAC3434 $29.04 1" M x 3⁄4" F MCAC1034 29.04 1" x 1" MCAC1010 59.18 C1 & C2 MULTI-PLANE SWIVELS TURNS EASILY AND DOESN'T LEAK M.Carder's new multi-plane swivels are different from all others on the market. To provide the best surface for the o-rings to seal, we have inserted a precisely machined brass sleeve into the aluminum castings. The super-smooth surface for the o-ring allows for easy rotation and and extended life for both the o-rings and the swivel. All o-rings are compatible with gasoline blends to E25 and biodiesel. UL Listed. SWIVELS Multi-plane swivel allows for 360° rotation. Compact and lightweight. Size Part # Each ¾″ x ¾″ HU000350 $29.74 1″ M x ¾″ F HU000352 31.18 1″ x 1″ HU000087 53.03 SWIVEL For truck and high volume fueling. Size Part # Each 1″ x 1″ HU4860 $83.82 EXTRA HEAVY DUTY 45° SWIVEL 45° design allows a full 360° rotation on both swivel planes. TWISTER SWIVEL The Twister Swivel from Catlow raises the level of swivel flexibility with two (2) high flow, 360 degree, rotating swivel ends. Special seals protect this heavy-duty swivel from extreme cold weather conditions, and it is designed for blended fuels. Its high tech engineering, durable construction and economical price will not only “twist & turn” your hoses, but your profits as well. Size Part # Each ¾" x ¾" OPW241TPS $31.29 1" x 1" OPW241TPS1000 58.42 ¾" for E-85/Biodiesel OPW241TPS0492 49.61 241 SWIVEL 360° on first swivel, 270° on second swivel plane. Size Part # Each ¾″ x ¾″ OPW455060 $29.36 1″ x 1″ OPW455075 56.53 Size Part # Each 1" M x 1" F CLC7201X1 $65.59 ¾" M x ¾" F CLC72075 33.41 SWIVELS
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 18 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! REPAIRABLE: SNAPS BACK TOGETHER WITH A REPAIR KIT SINGLE USETHROWAWAY RECONNECTABLE JUST SNAPS BACK TOGETHER! Size Part # Each ¾″ MCAB34 $32.73 ¾″ MCBA34KRepair Kit 6.15 1″ MCAB1 66.83 1″ MCBA1KRepair Kit 6.15 Reconnects easily–no kit required. Just push and twist and you’re back in business. Has a 350 lb. breaking force. OPW HUSKY MAGBREAK MAGNETIC BREAKAWAY Size Part # Each ¾″ OPW66REC1000 $85.81 Part # Each OPW68EZR7575 $69.11 Unique design allows breakaway at only 200 lbs. No repair kit needed. Just push and twist to reconnect. HUSKY Size Part # Each ¾″ HU3360 $87.11 1″ HU2276 125.79 IN-LINE BREAKAWAY CAM TWIST™ MAGNETIC Description Part # Each ¾" Complete CLCTM75 $90.60 ¾" Lower Half Only CLCTM75L 54.09 1" Complete CLCTM100 131.94 1" Lower Half Only CLCTM100L 56.27 Vapor Assist Complete CLCTMVA 151.30 Vapor Assist Lower Half Only CLCTMVAL 58.97 FEATURES: • Inspectable, no need for ‘remove by’ date • Magnetic snap-back technology • Lightweight • UL/ULC listed • CARB certified • Meets NFPA 30A Codes BENEFITS: • No repair kit needed • Maximum separation force is less than 300 lbs. • Minimal flow restriction • Seals both ends of the breakaway • Patented magnetic separation and reconnect mechanism • Easy reconnect feature • Low scuff housing • Line shock-absorbing design • Stopsflow on both sides of break • Durable plastic cover prevents damage to the breakaway during a drive off • One year warranty Size Part # Each ¾″ OPW66V0300 $32.53 1″ OPW66V1300 74.70 OPWEconomical breakaway design with dual valve seats to stop theflow of fuel instantly. One time use. Size Part # Each ¾″ HU2273 $40.13 1″ HU5812 91.32 Size Part # Each ¾″ HU8330 $82.63 1″ HU8331 $124.61 This disposable, lightweight and inexpensive Safe-T-Break separates under 250 lbs. of pull force. HUSKY ® 68 EZR 3/4" RECONNECTABLE BREAKAWAY • Fast and easy reconnection • Clear visual reconnection instructions • An audible click and green indicator to know it is locked and secure • Trusted, proven technology • No annual maintenance • Lowest total cost of ownership The 68EZR uses patent pending, UL listed innovation to ensure that it is not only the fastest and easiest breakaway in the industry to reconnect, but also the one that delivers the greatest peace of mind that it is securely reconnected. This breakaway features simple "Push-Twist-Click" technology: simply realign the valve, push in and then twist until you hear the audible click and see the green indicator in cover's outer shell. Approved for gasoline, ethanol blends up to 25% (E25) and biodiesel blends up to 20% (B20). M. Carder's Breaktime Breakaways have a unique break-ring design that provides consistent and reliable performance. Compact, lightweight and easily repaired with a kit. Ball check valves seal both ends upon separation. Machined from solid aluminum bar stock. O-rings compatible with gasoline blends to E25 and biodiesel. BREAKAWAYS
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 19 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! WHIP HOSES ⅝″ WIRE BRAIDHARDWALL WITH¾″ MALENPT ENDS 5/8" x Part # Each 8' AGYHW063X8MXM $39.67 8½' AGYHW063X8.5MXM 41.49 9' AGYHW063X9MXM 43.31 9½' AGYHW063X9.5MXM 45.01 10' AGYHW063X10MXM 46.83 10½' AGYHW063X10.5MXM 48.65 12' AGYHW063X12MXM 54.00 13' AGYHW063X13MXM 57.53 14' AGYHW063X14MXM 61.06 ¾″ WIRE BRAID HARDWALL WITH¾″ MALE NPT ENDS 3/4" x Part # Each 8' AGYHW075X8MXM $42.21 8½' AGYHW075X8.5MXM 44.35 9' AGYHW075X9MXM 46.38 9½' AGYHW075X9.5MXM 48.30 10' AGYHW075X10MXM 50.44 10½' AGYHW075X10.5MXM 52.47 12' AGYHW075X12MXM 58.57 13' AGYHW075X13MXM 62.63 14' AGYHW075X14MXM 66.70 17' AGYHW075X17MXM 78.90 20' AGYHW075X20MXM 91.11 25' AGYHW075X25MXM 111.45 50' AGYHW075X50MXM 213.12 100' AGYHW075X100MXM 416.64 1″ WIRE BRAID HARDWALL WITH 1″ MALE NPT ENDS 1" x Part # Each 8' AGYHW100X8MXM $51.39 8½' AGYHW100X8.5MXM 53.95 9' AGYHW100X9MXM 56.51 9½' AGYHW100X9.5MXM 59.07 10' AGYHW100X10MXM 61.62 12' AGYHW100X12MXM 71.74 14' AGYHW100X14MXM 81.86 17' AGYHW100X17MXM 97.11 20' AGYHW100X20MXM 112.36 25' AGYHW100X25MXM 137.74 50' AGYHW100X50MXM 264.80 100' AGYHW100X100MXM 518.96 150' AGYHW100X150MXM 773.13 • 1′ OAL also available, please call for pricing. WITH MXM OR MXM SWIVEL ENDS Description Part # Each ¾" x 8" OAL AGYHW075X.5MXMW $15.37 1" x 8" OAL AGYHW100X.5MXMW 16.62 ¾" x 8" OAL w/ Swivel AGYHW075X.5MXMSW 24.61 1" x 8" OAL w/ Swivel AGYHW100X.5MXMSW 31.66 Wecut andassemble our own hose. Please call for any size not listed. A whole lot easier to handle (especially at Ellsworth pricing!) • ADD $10.85 FOR ONE SWIVEL END ON⅝" AND ¾" HOSE — $15.25 FOR 1" • MIX &MATCH FORBEST PRICE— • CUSTOMLENGTHS ALWAYS AVAILABLE! ® FLEXSTEEL® FUTURA™ HARDWALL HOSEWITH ENDS CLARENCE SAYS: DISPENSER HOSE
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 20 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! CONVENTIONAL SOFTWALL CURB PUMP HOSE 1″ SOFTWALL SINGLE BRAID WITH 1″ MALE ENDS 1" x Part # Each 8' AGYSW100X8MXM $73.83 8½' AGYSW100X8.5MXM 76.58 9' AGYSW100X9MXM 79.32 9½' AGYSW100X9.5MXM 82.18 10' AGYSW100X10MXM 84.93 10½' AGYSW100X10.5MXM 87.67 12' AGYSW100X12MXM 96.03 20' AGYSW100X20MXM 140.57 25' AGYSW100X25MXM 168.53 ¾" SOFTWALL SINGLE BRAID WITH¾″ MALE ENDS 3/4" x Part # Each 8' AGYSW075X8MXM $39.86 8½' AGYSW075X8.5MXM 41.40 9' AGYSW075X9MXM 42.83 9½' AGYSW075X9.5MXM 44.38 10' AGYSW075X10MXM 45.81 10½' AGYSW075X10.5MXM 47.24 12' AGYSW075X12MXM 51.65 20' AGYSW075X20MXM 75.27 25' AGYSW075X25MXM 90.08 3/4" x Part # Each 8' AJMEE85075X8MXM $59.64 8½' AJMEE85075X8.5MXM 62.98 9' AJMEE85075X9MXM 66.43 9½' AJMEE85075X9.5MXM 69.79 10' AJMEE85075X10MXM 73.16 12' AJMEE85075X12MXM 86.94 15' AJMEE85075X15MXM 107.70 20' AJMEE85075X20MXM 142.67 25' AJMEE85075X25MXM 177.88 BULK CURB PUMP HOSE Description Part # Price ¾″ Softwall Continental/ContiTech Pacer™ GY075PACER50BLK (Specify Length) $3.21/foot 1″ Softwall Continental/ContiTech Pacer™ GY100PACER50BLK (Specify Length) 6.04 /foot ⅝″ Hardwall Continental/ContiTech Flexsteel® GY063FLXSTLFUTURABLK (Specify Length) 3.76/foot ¾″ Hardwall Continental/ContiTech Flexsteel® GY075FUTURABLK (Specify Length) 4.27 /foot 1″ Hardwall Continental/ContiTech Flexsteel® GY1FLEXSTEEL (Specify Length) 5.34 /foot EVERYTHING YOU NEED TO DO IT YOURSELF! Hose should be properly grounded when assembled. • Call for additional lengths not offered above. 1 in. ID hose also available - please call for a quote. • Hose should be properly grounded when assembled. REUSABLE CURB PUMP HOSE END Size Hose O.D. Part # Each 1″ 1⅜″ DX850841 $30.40 STANDARD NOSWIVEL (FOR HARDWALL) Material is chrome-plated brass, except where noted. HARDWALL HOSE ASSEMBLIES WHIP HOSE E25 & E85 ETHANOL BLEND3/4IN. HARDWALL DISPENSINGHOSE ASSEMBLIES The durable construction of this hose resists deterioration from highly ethanol blended fuels such as E25, E85, ozone, sunlight and cracking. This hose supports blended fuels up to 85% ethanol. The one wire braid steel reinforcement provides a working pressure of 200 psi. These hose assemblies include crimped fittings that are built to withstand the rough treatment received at curb pump selfservice stations, as well as industrial and construction use. • Tube: NBR/PVC, RMA Class A • Cover: U/L approved, Class B • Reinforcement: Wire braid HOSE Size Part # Each 3/4 in. ATM075E85X.5MXMW $15.87 • Cover Color: Black • Male x Male NPT Ends • Tube: NBR/PVC, RMA Class A • Cover: U/L approved, Class B • Reinforcement: Wire braid • Temperature Range: -40°F to +180°F JME E25 & E85 3/4IN. X 8IN. WHIP HOSE NEW 2022
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 21 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! HANGING HARDWARE KITS Size Part # Each 9' AUN9MC $149.90 Size Part # Each 12' ADNTS12MC $254.70 3/4" HOSE ASSEMBLIES • Unleaded rebuilt prepay nozzle with a 13/16” OD spout and splash guard • Dual plane swivel - 3/4 in. • Repairable breakaway - 3/4 in. • 3/4 in. x 9 ft. dispense hose • 3/4 in. x 8 in. whip hose • Gasoila thread sealant - 2 oz. tube Diesel Unleaded *Please call us if you would like a different length of hose. We can make any size you need. 1" HOSE ASSEMBLIES • Truck stop style diesel pre-pay rebuilt nozzle with a 13/16” OD spout and splash guard • Dual plane swivel - 1 in. • Repairable breakaway - 1 in. • 1 in. x 12 ft. dispense hose • 1 in. x 8 in. whip hose • Gasoila thread sealant - 2 oz. tube UNLEADED& DIESEL PREPAY NOZZLE COMPLETE HANGINGHARDWARE HOSE ASSEMBLY Changing out your hanging hardware has never been easier. JME now offers complete pre-assembled hose assemblies that allow you to easily replace your old or defective equipment in seconds. Simply remove your old hose set up at the dispenser and screw in the new hanging hardware hose assembly. We even include a tube of Gasoila for sealing the whip hose threaded connection at the dispenser. The components are shipped fully assembled and include a whip hose, repairable breakaway, Continental ContiTech Flexsteel dispensing hose, dual plane swivel and a prepay unleaded dispensing nozzle with splash shield. The nozzles are pressure activated with automatic shut-off for full-service and self-service stations. ONE YEAR WARRANTY. The unleaded nozzle spout has a 13/16 in. outside diameter which is standard for all cars and trucks using unleaded gasoline. OPW DIESEL NOZZLE HANGINGHARDWARE KIT Upgrade your dispenser with quick and easy hanging hardware kits from OPW! These kits are all preassembled making installation a breeze thus reducing dispenser downtime. Order your factory assembled kit today! These Kits come with a certificate assuring they were 100% tested and certified by OPW ensuring warranty compliance. Kit Includes • A - 3/4" 11B Series Prepay Nozzle • B - 3/4" 241TPS 2-Plane Swivel • C - 3/4" x 9" Whip Hose, 3/4" NPT Ends • D - 3/4" 68EZR Reconnectable Breakaway • E - 3/4" x 8 1/2' Dispensing Hose, 3/4" NPT Ends • F - Fillgard® Splash Guard Color will match Nozzle Color Part # Each Green OPWPKEZR0100L1 $362.21 Yellow OPWPKEZR0900L1 362.21 Black OPWPKEZR0400L1 362.28 HANGING HARDWARE KITS
