Shop Hundreds of New Products at JMESales.com Phone 800-333-3331| Website JMEsales.com| Fax 800-563-8848 24-Hour Availability CAT# M0221 HOSE | PUMPS | METERS | VALVES | NOZZLES | COUPLINGS | ACCESSORIES YEARS OF EXCELLENCE 45
A HOSE FOR EVERY APPLICATION DUCTING FUEL OIL DELIVERY AVIATION FUEL DISPENSING CHEMICAL PETROLEUM TRANSFER STEAM AIR MATERIAL HANDLING FOOD & BEVERAGE MARINA FIRE HOSE
PH: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 1 DEF Pages 255266 TANKS & TOTES 100, 142147 PUMPS Pages 49-84 CONTACT US TOLL FREE : 800-333-3331 LOCAL: 414-354-1414 FAX: 800-563-8848 E-MAIL: info @ jmesales.com or PurchaseOrder@jmesales.com 24/7 ONLINE ORDERING: www.jmesales.com Hours: Monday – Friday, 7:00 a.m. – 6:00 p.m. CST JOHN M. ELLSWORTH COMPANY, INC. P.O. Box 240072 • 8700 West Bradley Road • Milwaukee, Wisconsin 53224 Table of Contents Complete alphabetical index on page 271 Air Compressors .............................................................. 250 Air Pressure...............................................................104-106 API couplers ..................................................................... 226 Aviation ......................................................................... 44-46 Breakaways ........................................................................ 20 Bulk Plant & Loading.........................................227-228, 232 Bulk Storage Tank Accessories ............................... 107-126 Clamps & Tools ..................................................... 208-209 Couplings................................................... 201-205, 210-216 DEF Equipment ........................................................ 255-266 Diaphragm Pumps (Air Operated) .............................. 83-84 Diesel Storage Tanks ...................................................... 152 D.O.T. Certified Transfer Tank Systems.......................... 164 Drum Pumps & Equipment ..........153-158, 161-162, 244-246 Dry Disconnects........................................................186-189 Electric Vehicle Chargers ......................................... 267-270 Farm Equipment............................................................41-43 Filters ................................................................................. 2-9 Fuel Management Systems......................................... 65-67 Fuel Oil Delivery ........................................................168-177 Fuel & Safety Containers................................................. 249 Gauges ...................................................................... 129-141 Gloves............................................................................... 178 Gravity Flow Tanks & Tank Labels...................................147 Grease Dispensing ................................................... 101-103 Grounding Equipment .............................................. 239-242 Heaters ......................................................................159-160 Hose & Hose Clamps ...........................21-22, 190-200, 207 Lube Oil Transfer.......................................................... 89-98 Marina............................................................................47-48 Meters.............................................................. 59-62, 85-88 Nozzles .......................................................................... 10-18 Oil Tanks Systems.......................................................99-100 Valves & Dispensing ................................................ 205-206 Portable Gas Trailers ................................................148-149 Propane Equipment .................................................. 179-185 Pumps.................................... 49-57, 60-65, 68-84, 153-154 Railroad............................................................................. 225 Ramps............................................................................... 251 Reels......................................................................... 233-239 Remote Tank Fill............................................................... 128 Service Station Equipment .......................................... 23-40 Sorbents ....................................................................252-254 Spill Control ............................................................... 247-248 Storage Tanks ........................................................... 150-151 Strainers ..................................................................... 111-113 Swivels........................................................................ 19, 229 Tank & Pump Packages ............................................142-147 Tanks & Totes................................................................... 100 Tank Truck Equipment ..............................................215-224 Thread Sealants................................................................. 33 Transfer Tanks & Accessories..................................163-165 FULL LINE AT JMESALES.COM Section Highlights Notice: Due tofluctuations in supply chains, prices are subject to change.
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 2 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! CIM-TEK 200 SERIES FUEL FILTER FUEL FILTERS PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1″-12 UNF w/ Drain 10 70002 40810PDV 6 CIM200E10 $8.01 1″-12 UNF w/ Drain 30 70046 40830PDV 6 CIM200E30 7.94 1″-12 UNF w/o Drain 2 70819 N/A 6 CIM250E02 11.15 1″-12 UNF w/o Drain 10 70003 40910P 6 CIM250E10 7.13 1⅜″-12 UNF w/ Drain 10 70004 40810PADV 6 CIM200AE10 9.94 1⅜″-12 UNF w/o Drain 2 70821 N/A 6 CIM250AE02 12.20 1⅜″-12 UNF w/ Drain 30 70045 40830PADV 6 CIM200AE30 9.98 1⅜″-12 UNF w/o Drain 10 70005 40910PA 6 CIM250AE10 7.69 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1″-12 UNF 10 70062 40910W 12 CIM260HS10II $12.24 1″-12 UNF 30 70067 40930W 12 CIM260HS30II 12.00 1⅜″-12 UNF 10 70061 40910WA 12 CIM260AHS10II 12.86 1⅜″-12 UNF 30 70066 40930WA 12 CIM260AHS30II 12.88 An economical filter for use with low-volume commercial power pumps and gravity flow applications pumping up to 25 gpm. How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1″-12 UNF 10 70059 40510W 12 CIM300HS10II $8.40 1″-12 UNF 30 70064 40530W 12 CIM300HS30II 8.33 Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1″-12 UNF 2 70806 N/A 12 CIM70806 $9.16 1″-12 UNF 10 70010 40510P 12 CIM30010 5.84 1″-12 UNF 30 70012 40530P 12 CIM30030 5.78 1″-12 UNF 10 70058 N/A 12 CIM300BMG10 13.97 PARTICULATE REMOVAL Size Micron Cimtek # Media Case Qty. Part # Each 1″-12 UNF 10 70122 Microglass 12 CIM300MB10 $11.00 1″-12 UNF 30 70018 Microglass 12 CIM300MB30 11.10 MULTI-FUEL MONITOR FILTERS, 5.5" (Formerly Alcohol Monitors) This filter's exclusive design detects phase separation in ethanol blends AND water in straight gasoline. They offer the same great quality as before: surge supressing spring, pre-lubed gaskets, high efficiency microglass media, UL approved – and Made in the USA! An economical filter for use with service station dispensers pumping up to 25 gpm. CIM-TEK 300 SERIES FUEL FILTER
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 3 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FUEL FILTERS An economical filter for use with Gilbarco® Advantage Series service station dispensers. EZ-GRIP FILTER CUP Easily remove fuel filters at the dispenser! • Innovative cup design is engineered to grip the filter and catch fuel when replacing dispenser filters...no mess! • Allows for faster change-outs and less dispenser downtime • Cup helps to avoid getting fuel directly on hands/skin and getting spills in sump • Fuel filter cup can be used on all brands & styles of fuel filters at the dispenser Model # Each CIM60070 $21.51 How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1½″-16 UNF 2 70808 N/A 12 CIM40002 $11.45 1½″-16 UNF 10 70015 40510PAD 12 CIM40010 8.38 1½″-16 UNF 30 70016 40530PAD 12 CIM40030 8.25 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1½″-16 UNF 10 70060 40510WAD 12 CIM400HS10II $10.82 1½″-16 UNF 30 70065 40530WAD 12 CIM400HS30II 10.74 MULTI-FUEL MONITOR FILTERS, 5.5" (Formerly Alcohol Monitors) This filter's exclusive design detects phase separation in ethanol blends AND water in straight gasoline. They offer the same great quality as before: surge supressing spring, pre-lubed gaskets, high efficiency microglass media, UL approved – and Made in the USA! Size Micron Cimtek # Media Case Qty. Part # Each 1½″-16 UNF 10 70120 Microglass 12 CIM400MB10 $12.27 1½″-16 UNF 30 70106 Microglass 12 CIM400MB30 11.85 PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1½″-16 UNF 2 70814 N/A 6 CIM80002 $28.68 1½″-16 UNF 10 70019 51110P 6 CIM80010 17.81 1½″-16 UNF 30 70020 51130P 6 CIM80030 17.15 1½″-16 UN 10 70028 N/A 6 CIM800BMG10 31.39 HYDROSORB WATER & PARTICULATE REMOVAL Size Micron Cimtek # Petro Clear # Case Qty. Part # Each 1½″-16 UNF 10 70063 51110W 6 CIM800HS10II $26.61 1½″-16 UNF 30 70068 51130W 6 CIM800HS30II 25.77 An economical filter for service station, truck stop and commercial high-volume fueling locations. CIM-TEK 800 SERIES FUEL FILTER CIM-TEK 400 SERIES FUEL FILTER
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 4 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FUEL FILTERS E85is the term for motor fuel blends of 85% ethanol & 15% gasoline. It is defined as an alternative fuel by the U.S Dept. of Energy. Ethanol burns cleaner than gasoline & is a completely renewable fuel. Biodiesel is a name used for cleaner burning alternative fuel produced by domestic, renewable resources. It contains no petroleum, but can be blended at any level with petroleum diesel to create a biodiesel blend. It can be used in compressionignition diesel engines without major modifications. Biodiesel is simple to use, biodegradable, nontoxic and essentially free of sulfur and aromatics. Find more info about alternative fuels at www.JMEsales.com For all your industrial filters, cartridges and assemblies, visit our website at www.JMEsales.com You'll find them after SHOP BY CATEGORY in theFILTERSsection. Also search for Racor. BIO-TEK HIGH ALCOHOL FILTER (PARTICULATE FILTER) E85, M85, B100 Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 1 70025 12 CIM300BHA01 $31.40 1½″-16 UNF 1 70039 12 CIM400BHA01 34.66 1½″-16 UNF 5 70991 12 CIM400BHA05 27.52 BIO-TEK HYDROGLASS FILTER (PARTICULATE & WATER REMOVAL FILTER For Ethanol Blends Up to E15 and Biodiesel Up to B100 Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 2 70232 12 CIM70232 $21.81 1″-12 UNF 10 70236 12 CIM70236 20.07 1½″-16 UNF 2 70037 6 CIM70037 37.03 1½″-16 UNF 10 70024 6 CIM70024 36.52 BIO-TEK MICROGLASS FILTER (PARTICULATE FILTER) For Ethanol Blends Up to E15 and Biodiesel Up to B100 Size Micron Cimtek # Case Qty. Part # Each 1″-12 UNF 2 70230 12 CIM70232 $21.81 1″-12 UNF 10 70234 12 CIM70236 20.07 1⅜″-12 UNF 2 70221 12 CIM70037 37.03 1⅜″-12 UNF 10 70225 12 CIM70024 36.52 1″-12 UNF 2 70057 12 CIM300BMG02 14.67 1″-12 UNF 10 70058 12 CIM300BMG10 13.97 1½″-16 UNF 2 70105 12 CIM400MG02 16.38 1½″-16 UNF 10 70104 12 CIM400BMG10 15.41 1½″-16 UNF 2 70036 6 CIM800BMG02 35.43 1 ½″-16 UNF 10 70028 6 CIM800BMG10 31.39 How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 5 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FUEL FILTERS Part # Each NSNS10 $49.86 NSNS10BOWL 27.30 Part # Each NS20 $11.03 For regular grades of gas, diesel, & ethanol. FOR FARMPUMPS & GRAVITY APPLICATIONS NSNS10: A fuel filter for regular grade of gasoline and diesel fuel. Has a painted, die-cast aluminum cap. Comes complete with NS20 element and see-thru clear plastic bowl and drain cock. 1″ NPT (female) inlet and outlet. NSNS10BOWL: Replacement clear plastic bowl for NSNS10 Filter. NS20: Replaceable treated paper element for use with NSNS10filters. Has approximately 350 square inches of filtering surface. Micron rating is approximately 10. COMPARABLE TO THE LEADING BRAND Filter Kits Include: • Fuel filter • Filter head • Close nipple CIM200HA ADAPTERS FOR 200E, 250E, 260AND 300 SERIES FILTERS Pipe In/Out Nose Outside Thread Material Case Qty. Part # Each ¾″ NPT 1″-12 UNF Cast Iron 6 CIM200H $14.21 ¾″ NPT 1″-12 UNF Aluminum 1 CIM200HA 17.95 1″ NPT 1″-12 UNF Cast Iron 6 CIM200H1 14.36 ADAPTER FOR 400 SERIES FILTERS Pipe In/Out Nose Outside Thread Material Case Qty. Part # Each 1″ NPT 1½″-16 UNF Aluminum 1 CIM400UL $24.35 1″ NPT 1½″-16 UNF Nickel Plated 1 CIM400BHA 37.36 ADAPTERS FOR 800 SERIES FILTERS Pipe In/Out Nose Outside Thread Material Case Qty. Part # Each 1″ NPT 1½″-16 UNF Aluminum 1 CIM805 $26.33 1½″ NPT 1½″-16 UNF Aluminum 1 CIM810 35.91 1½″ NPT 1½″-16 UNF Nickel Plated 1 CIM810N 50.47 2″ NPT 1½″-16 UNF Aluminum Two FIlters 1 CIM820 149.10 Pipe In/Out Nose Outside Thread Material Case Qty. Part # Each 1″ NPT 1⅜″-12 UNF Cast Iron 6 CIM200AH $16.59 ADAPTER FOR 200AEAND 250AE SERIES FILTERS FILTER KITS ¾″ INLET/OUTLET Fuel Type Part # Each Gas ACIM34G $24.33 Diesel ACIM34D 24.23 Biofuels ACIM34B 36.33 1″ INLET/OUTLET Fuel Type Part # Each Gas ACIM1G $24.98 Diesel ACIM1D 24.98 Biofuels ACIM1B 37.07 CIM400UL CIM200AH How To Choose The Right Filter www.youtube.com/johnellsworthcompany VIDEO ONLINE VIEW CIM805 CIM810 E85 Compatible E85 Compatible E85 Compatible E85 Compatible ACIM34G NSNS10 NSNS10BOWL
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 6 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FUEL FILTERS REPLACEMENT TOP CAPS FORSEE-THRU FILTERS SEE-THRU FUEL FILTERS SPIN-ON FUEL FILTERS REPLACEMENT TOP CAPS FOR SPIN-ON FILTERS REPLACEMENT STRAINERS FORSEE-THRU FILTERS REPLACEMENT SEE-THRU BOWL REPLACEMENT GASKETS FOR SEE-THRU FILTERS FILTER WRENCH GOLDENRODSEE-THRU FILTERS GOLDENRODSPIN-ON FILTERS • Easy-to-use sediment drain valve • 5 GPM • 24" Head • Working PSI: 150 • Heavy-duty top cap provides durability • Alcohol- and impact-resistant see-thru bowl Description NPT Part # Each Zinc Die-Cast (NOT for use with Biodiesel) 1" DL4701 $14.80 Zinc Die-Cast (NOT for use with Biodiesel) ¾" DL47075 14.80 Nickel Plated(For use with Bio-Flo filter) 1" DL4701N 33.80 Nickel Plated(For use with Bio-Flo filter) ¾" DL47075N 33.80 Description Mesh Micron Part # Each Stainless Steel 80 178 DL47016 $17.40 Stainless Steel 40 381 DL47015 15.00 Part # Description Each DL4954 For 495 & 496 Filters $19.90 Description Part # Each Gasket Fits 495 & 496 Filters (NOT for use w/ Biodiesel) DL4707 $0.80 Gasket Fits Filter 497 DL4709 3.20 Part # Each DL491 $6.60 Type NPT Micron Part # Each Standard See-Thru Filter with Top Cap ¾" 10 DL49575 $39.60 Standard See-Thru Filter with Top Cap 1" 10 DL4951 39.60 Replacement Element for DL49575 & DL4951 DL4705 7.50 WATER-BLOCK See-Thru Filter with Top Cap ¾" 17 DL49675 44.40 WATER-BLOCK See-Thru Filter with Top Cap 1" 17 DL4961 44.40 Replacement Element for DL49675 & DL4961 DL4965 13.40 BiO-FLO See-Thru filter with Top Cap ¾" 10 DL49775 60.90 BiO-FLO See-Thru filter with Top Cap 1" 10 DL4971 60.90 Replacement Element for DL4971 & DL49775 DL4975 14.80 Type NPT Micron Part # Each Standard Spin-On Filter with Top Cap 1" 10 DL5951 $29.10 Standard Spin-On Filter with Top Cap ¾" 10 DL59575 29.10 Replacement Canister for Model 595 DL5955 9.30 WATER-BLOCK Spin-On Filter with Top Cap 1" 10 DL5961 35.90 WATER-BLOCK Spin-On Filter with Top Cap ¾" 10 DL59675 35.90 Replacement Canister for Model 596 DL5965 17.20 Type NPT Part # Each Zinc Die-Cast for Use with 595 & 596 Models (NOT for use with Biodiesel) 1" DL5701 $14.80 Zinc Die-Cast for Use with 595 & 596 Models (NOT for use with Biodiesel) ¾" DL57075 14.80 Canister Top Cap Filter with Top Cap Filter with Top Cap Top Cap Replacement Element
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 7 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FILTERS Inlet/Outlet Part # Each 1 1/4 in. NPT DNX011745 $353.02 Inlet/Outlet Part # Each 1 1/4 in. NPT DNX011448 $395.63 Inlet/Outlet Part # Each 1 1/2 in. FNPT DNX920006 $443.10 COMPACT CLEAN DIESEL KIT - 4 MICRON The Compact Clean Diesel Kit is designed for use on mobile service trucks, slip tanks, D-tanks, inside fuel dispensers and other tight locations. Donaldson Clean Diesel Kits provide simple, effective outlet filtration on fuel dispensers to allow you to pump clean fuel into your vehicles and equipment. These kits are easy to install on any fuel dispenser and come with everything needed tofilter out even thefinest contaminants before they can enter your equipment's fuel system. With the included easy to follow step by step instructions, you will have effective efficient filtration in minutes. STANDARD CLEAN DIESEL KIT - 4 MICRON The Standard Clean Diesel Kit is perfect for smaller operations that need clean fuel delivered efficiently in any environment. Donaldson parallel filtration Clean Diesel Kits provide simple, effective outlet filtration on fuel dispensers to allow you to pump clean fuel into your vehicles and equipment. These kits are easy to install on any fuel dispenser and come with everything needed tofilter out even thefinest contaminants before they can enter your equipment's fuel system. With the included easy to follow step by step instructions, you will have effective efficient filtration in minutes. STANDARD CLEAN DIESEL KIT - 4 MICRON The Thermally Reactive Advanced Protection (T.R.A.P.) Breather assembly protects thefluids in your storage tank from airborne particulate moisture contamination and ambient moisture. It combines a high capacity 3 micron air filter with a deliquescent breather that dries itself when air is expelled from the tank. This self-regenerating capability of T.R.A.P. enables extended life and functionality. Keep your fluids clean and dry with a Donaldson T.R.A.P. Breather. Micron Part # Each 4 DNDBB8666 $183.64 7 DNDBB8665 172.57 25 DNDBB8664 166.57 STANDARD REPLACEMENT FILTERS Micron Part # Each 4 DNDBB5333 $120.70 7 DNX011448 395.63 25 DNX011448 395.63 COMPACT REPLACEMENT FILTERS • Easy to install • Protect expensive fuel injection systems • Prevent premature plugging of onboard fuel filters • Reduce maintenance costs • Prevent unplanned downtime • Recommended for all diesel and biodiesel blends • Providesfiltration to ISO 14/13/11 diesel cleanliness in a single pass • High efficiency air filtration • Longer life and lower airflow restriction than typical silica gel breathers • Self-regenerating moisture adsorption • Easy to service • Easy to install • Providesfiltration to ISO 14/13/11 diesel cleanliness in a single pass • Recommended for all diesel and biodiesel blends • Protect expensive fuel injection systems • Prevent premature plugging of onboard fuel filters • Reduce maintenance costs • Prevent unplanned downtime DONALDSON CLEAN DIESEL KITS DONALDSON T.R.A.P.™3 MICRON BREATHER
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 8 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FILTERS Flow Rate Part # Each 10-30 GPM RAFBO14DPL $662.09 RACOR FBO-14 FILTER ASSEMBLY W/ DIFFERENTIAL PRESSURE GAUGE, SIGHT GLASS & DRAIN VALVE Size Part # Each 25 Micron RAFBO60338 $142.55 10 Micron RAFBO60356 141.61 5 Micron RAFBO60337 146.42 RACOR FBO-14 FILTER CARTRIDGES - 6X 14 FILTER ELEMENT FOR FBO 14 Flow Rate Part # Each 5-15 GPM RAFBO10DPL $650.84 RACORFBO-10 FILTERASSEMBLY W/ DIFFERENTIAL PRESSUREGAUGE, SIGHT GLASS& DRAINVALVE Fuel Filter/Water Separator For High-Flow Applications. FBO-10 and FBO-14 filter assemblies are designed to meet the toughest hydrocarbon refueling conditions and designed for easy cartridge changeouts. The FBO assembly can be used on mobile refuelers or installed in refueling cabinets. The FBO unit can also be used for diesel fuel dispensing pumps, as a primary fuel filter/water separator for large diesel engines, or as bulk fuel handling, fuel transfer, and other higher flow applications. The FBO assembly canflow from 10 GPM (38 LPM) to 75 GPM (284 LPM), depending on which model, filter, and type of fuel to be filtered. • Die-cast aluminum head • Steel filter bowl assembly • Powder coated components • Mounting bracket • Locking ring collar “no V-clamps” • 1.5” NPT inlet and outlet • Viton® seals • Designed to withstand a max pressure of 150 PSI and a max temperature of 240°F • Manual drain valve (1/4” NPT) • Manual vent valve • Sight glass (1/2” NPT) • 120 volt AC explosion proof heater option available • Wide variety of accessories, filters and applications available RACOR FBO-10 FILTER CARTRIDGES - 6X 10 FILTER ELEMENT FOR FBO 10 Size Part # Each 25 Micron RAFBO60329 $134.07 10 Micron RAFBO60353 135.69 5 Micron RAFBO60328 138.98 TURBINE SERIES REPLACEMENT FILTER ELEMENTS Part # Size Each RA2010PMOR 30 Micron $7.95 RA2010TMOR 10 Micron 7.95 RA2010SMOR 2 Micron 7.95 Part # Size Each RA2020N02 2 Micron $9.97 RA2020V10 10 Micron 9.97 RA2020V30 30 Micron 9.97 500 SERIES Racor replacement elements for Turbine Series Filters feature Aquabloc II media which is a blend of a high-grade cellulose compound with resins and a special chemical treatment. These elements filter harmful tiny particles of dirt and algae from fuel. Aquabloc II replacement elements come as a kit with all the seals you need. 1000 SERIES RA2010PMOR RA2020N02 Part # Size Each RA2040V02 2 Micron $8.20 RA2040V10 10 Micron 8.48 RA2040V30 30 Micron 8.48 900 SERIES RA2040N02
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 9 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! FUEL FILTERS 200 SERIES FUEL FILTER/WATER SEPARATORS Part # Size Each RAR15S 2 Micron $34.13 RAR15T 10 Micron 33.44 RAR15P 30 Micron 33.44 Part # Size Each RAR25S 2 Micron $32.78 RAR25T 10 Micron 28.90 RAR25P 30 Micron 30.84 LOWFLOWDIESEL REPLACEMENT ELEMENTS 200 Series Fuel Filter/Water Separators The 215R, 230R, and 245R fuel filter/water separators come standard with an integral priming pump and a new see-thru contaminant bowl which can operate in applications up to 30 PSI. Another design upgrade is the optional 200-watt in-bowl heater for colder operating conditions. Applications include light-duty and medium-duty trucks and vehicles, construction, agricultural, and other diesel-powered equipment. • Die-cast aluminum unitized head ports • Mounting holds spaced at 1.4" (35.6 mm), for 1/4" bolt • 2 piece powder-coated aluminum construction • Filters gasoline, diesel, and gasoline/oil blended fuels • Compact design • Heavy duty construction • Easy to service FOR215R2/10/30 FOR245R2/10/30 FOR230R2/10/30 FOR120AS/T/POR 140R (10 MICRON) RAR15S RAR12S Part # Size Each RAR20S 2 Micron $26.90 RAR20T 10 Micron 26.30 RAR20P 30 Micron 24.33 Part # Size Each RAR12S 2 Micron $20.32 RAR12T 10 Micron 20.18 RAR12P 30 Micron 20.18 RAR20S RAR12S 110A SERIESLOWFLOWFUEL FILTER Part # Size Each RAR11T 10 Micron $18.07 LOWFLOWFUEL FILTERR11T ELEMENT - 10 MICRON 110A - Maximum Protection in Minimum Space The 110A is designed for fuel-injected gasoline engines with high working pressures and also can be used on diesel engines. A metal housing is standard. Typical applications include smaller diesel and gasoline engines used in generator sets, pressure washers, and other equipment. It's compact sizefits tight mounting locations and multiple ports offer installationflexibility. • Port Size: 1/4" - 18 NPTF (SAE J467) • Flow Rates (Gasoline): up to 35 GPH • Flow Rates (Diesel): up 15 GPH • Clean Pressure Drop: 0.15 PSI • Max Pressure: 100 PSI DIESEL SPIN-ON SERIES REPLACEMENT FILTERS
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 10 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! PREPAY UNLEADED NOZZLES PREPAY DIESEL NOZZLES NOZZLES OPW 11B® SERIES – AUTOMATIC PREPAY NOZZLES OPW11BP OPW5BBS2135 The 11B® series of automatic nozzles is OPW’s premium, conventional, prepay nozzle for safe retail and commercial petroleumfilling. The 11B® and 11BP® nozzles are designed for use in retail and commercial filling applications (including prepay, self- and full-service, credit and debit card readers or card-lock systems) to help prevent gasoline spills. These nozzles will not open until the pumping system is pressurized and will close automatically when the pressure is removed. All of the nozzles in this series have a ¾" inlet. Safe for Use • UL and ULC listed for use in gasoline, diesel and up to 10% ethanol blends • FlowLock™ allows nozzles to shut off when falling out of a vehicle, and tipped up, limiting spillage and unsafe conditions Durable & Long Lasting Design • Cycle tested and proven to last longer than 1 million cycles – better than any other nozzle available on the market today • Stainless steel spout tip lasts four times longer than standard aluminum spouts • Durable lever guard won’t scratch your customers’ vehicles – made from Duratuff® Design Working Pressure • 50 PSI maximum pressure Description Size Part # Each Spout for 11BP Unleaded Nozzles 13⁄16" O.D. OPW5BBPS2137 $34.89 Spout for 11B Diesel Nozzles 15⁄16" O.D. OPW5BBS2135 33.73 REPLACEMENT SPOUTS Construction • Body: Aluminum • Lever & Lever Guard: Duratuff® • Packing: Graphite with Teflon® • Disc: Viton® • Spout: Aluminum (SS Tip) • Inlet Size: 3/4" NPT • Weight: 2.73 lbs. each UL 2586 COMPLIANT VISIT US ONLINE for nozzles to meet every need: DEF, diesel, farm, aircraft, cold weather, marina and many more! Color Part # Each Green OPW11B0100 $64.22 Silver OPW11B0200 65.96 Red OPW11B0300 64.22 Black OPW11B0400 64.22 Blue OPW11B0500 65.96 Yellow OPW11B0900 64.22 The world’s BESTSELLING nozzle! Color Part # Each Green OPW11BP0100 $62.71 Silver OPW11BP0200 65.96 Red OPW11BP0300 62.70 Black OPW11BP0400 62.71 Blue OPW11BP0500 62.71 Orange OPW11BP0800 65.96 Yellow OPW11BP0900 62.71 Color Options • Call for a quote on any colors not listed below
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 11 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES 5-STAR "S" CONVENTIONAL NOZZLES Made in the USA Color Part # Each Black MCN8UOB $51.80 Blue MCN8UOBL 51.80 Gold MCN8UOG 51.80 Green MCN8UOGR 51.80 Red MCN8UOR 51.80 Silver MCN8UOS 51.80 White MCN8UOW 51.80 Yellow MCN8UOY 51.80 Color Part # Each Black MCN7UOB $51.80 Blue MCN7UOBL 51.80 Gold MCN7UOG 51.80 Green MCN7UOGR 51.80 Red MCN7UOR 51.80 Silver MCN7UOS 51.80 White MCN7UOW 51.80 Yellow MCN7UOY 51.80 Color Part # Each Black MCN8OB $57.00 Blue MCN8OBL 57.00 Gold MCN8OG 57.00 Green MCN8OGR 57.00 Red MCN8OR 57.00 Silver MCN8OS 57.00 White MCN8OW 57.00 Yellow MCN8OY 57.00 Color Part # Each Black MCN7OB $57.00 Blue MCN7OBL 57.00 Gold MCN7OG 57.00 Green MCN7OGR 57.00 Red MCN7OR 57.00 Silver MCN7OS 57.00 White MCN7OW 57.00 Yellow MCN7OY 57.00 5-STAR“S” NEW¾" AUTOMATICPREPAYNOZZLES New, lightweight automatic gasoline nozzle is ideal for prepay locations. It has a pressure-activated secondary shut-off that prevents fuel flow until the system is pressurized. "One hand" holdopen clip with patented "kicker" feature provides positive clip release with automatic shut off. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Kicker clip feature provides 100% clip release • Super Tuff nylon hand guard and lever • Viton seals & poppet disc for fuel blends up to E25 & biodiesel • ¾" NPT inlet 5-STAR NEW¾" AUTOMATIC STANDARD NOZZLES New, lightweight automatic gasoline nozzles provide for reliable fueling. Features for these nozzles are the same as the 5 Star "S" models, except they do not have the pressurized system secondary shut-off. Due to new UL regulations (2586), these nozzles should NOTbe used on a prepay system in a retail setting. 10 GPM UL 2586 COMPLIANT PREPAY ONLY! 11BP UNLEADED PREPAY NOZZLES UNLEADED PREPAY UNLEADED PREPAY DIESEL PREPAY DIESEL PREPAY Type Part # Each Outright MCR7UOB $47.40 Core Credit* 5.00 11B DIESEL/AUTO-DIESEL PREPAY NOZZLES Type Part # Each Outright MCR7LOB $47.40 Core Credit* 5.00 *Outright prices are charged for all units. A core credit will be issued after the manufacturer determines that the core is rebuildable and is a like for like exchange, when necessary. All cores require an RMA # from JME and must be returned to the manufacturer within 30 days in order to receive a credit. REMANUFACTUREDAUTOMATIC NOZZLES CLARENCE SAYS: M. Carder rebuilt nozzles are a sure thing! MADE like new ones, TESTED like new ones, WARRANTIED like new ones, BUT SAVE $$$unlike new ones! A REMANUFACTURED NOZZLE THAT WORKS GUARANTEED! These nozzles are remanufactured using the same standards and testing process utilized for all of the new M. Carder nozzles. At least 30 new parts are used in the each assembly. Models have a pressureactivated secondary shut-off that prevents the fuel flow until the system is pressurized. Equipped with a hold-open clip. Non-UL Listed. 1 YEAR WARRANTY
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 12 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! Retaining Ring NOZZLES OPW 7H® AUTOMATIC SHUTOFF DIESEL NOZZLE FOR HEAVY-DUTY, HIGH-FLOWTRUCK, BUS & FLEET SERVICE If you operate a full-service truckstop, refuel your ownfleet, or manage a cardlock refueling location, the low cost, long life and durability of the OPW 7H® High Flow Nozzle can help increase your productivity, sales and profits. OPW 7H Series of nozzles all have a 1" inlet. • Spout retaining ring adds extra measure in securing nozzle spout infill pipe • Helps reduce spills a unique two-stage lever design assures a positive shutoff, even if held wide open • Low reliable shutoff specially designed to ensure proper shutoff as low as 5 gallons per minute • Easily replaced spout simply remove three screws • Replacement kits readily available from OPW • Dash-pot action for smoother closing action and reduced line shock • Dual poppets easy to open nozzle against high pressure • FlowLock™ designed to shutoff automatically when the spout is tipped up, limiting spillage • Even, smooth spray pattern** minimizes diesel foaming and false shut-offs PREPAY DIESEL NOZZLE 7HB SERIES – SAME AS 7H, EXCEPT PRESSURE ACTIVATED FOR PREPAY/SELF SERVE Prepay remote truck stop nozzle. 7HB shuts off when the pump stops and flow cannot resume until the pump is started and the system is re-pressurized. Color Part # Each Green OPW7H0100 $113.11 Black OPW7H0400 113.11 Yellow OPW7H0900 113.11 Color Part # Each Green OPW7HB0100 $128.29 Black OPW7HB0400 128.29 Yellow OPW7HB0900 128.29 Due to new UL requirements, OPW 7H Seriesnozzles will no longer have hold-open clips. OPW 7HB Seriesnozzles will continue to ship with hold-open clips. Call for further assistance. UL 2586 ** Do not use these nozzles with a hold-open device on pre-pay self-service installations. Failure to comply is a violation of NFPA Code 30A and may create a hazardous condition. Use of foreign objects to hold open automatic nozzles could result in a shut-off failure and personal injury.
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 13 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES OPW 14E® SERIES NOZZLE The OPW 14E ECO Enhanced Conventional Gasoline nozzle is part of the OPW 14 Series cleaner fueling experience nozzles, featuring innovative patented dripless free-draining spout technology. Other dripless technologies capture fuel in the spout where it is allowed to evaporate and increase VOC emissions. Utilizing a special interlock system inside the bellows to activate theflow of fuel. The OPW 14E dripless spout technology is designed to keep gasoline from dripping on your customers' hands, clothing, vehicles and the ground to provide a cleaner, greener, and more satisfying customer experience. The OPW 14C is part of the new OPW 14 Series cleaner fueling experience nozzles, featuring innovative patented* diesel-capture technology that drains fuel, rather than retains it. This innovation is designed to provide a cleaner, greener fueling experience for customers while keeping the retail-fueling site clean. • True Dripless Technology: Patented dripless, free-draining spout with no dams or hidden reservoirs to catch liquid - Designed to exceed CARB dripless requirements • Rugged Durability: Designed to meet the rigorous demands of high-volume sites • Auto Shutoff: FlowLock allows nozzle to shut off when falling out of a vehicle or is tipped up, limiting spillage and unsafe conditions. • Enhanced Drip Control (14E Models only): - Specially designed interlock prevents fuel fromflowing unless the spout is fully inserted in the vehiclefill pipe and the actuator is engaged - a CARB requirement • Cycle tested and proven to last longer than 1 million cycles • Durable lever guard that won't scratch your customers' vehicles - made from Duratuff® • Easy to use - Utilizing Accu-Stop® to-thepenny Flow Control Technology • Attractive two-piece NEWGARD Hand Insulator is the most comfortable nozzle in the industry to use • Convenient - one-finger hold-open clip that is easy to set theflow rate • Diesel Fuel Capture Technology: The patented technology allows excess diesel fuel to drain into a uniquely engineered chamber located in the body of the nozzle located at the base of the spout - This excess diesel fuel is then introduced back into the fuel stream • Drip Guard: designed to capture any fuel that runs out onto the outside of the nozzle • Approved for diesel-fuel blends up to B20 • Rugged Durability: designed to meet the rigorous demands of high-volume sites • FlowLock allows nozzle to shut off when falling out of a vehicle or is tipped up, limiting spillage and unsafe conditions • Cycle tested and proven to last longer than 1 million cycles • Durable lever guard that won't scratch your customers' vehicles, made from Duratuff® • Easy to use: Utilizing Accu-Stop® to-thepenny Flow Control Technology • Two-piece hand insulator which includes NEWGARD barrel cover and colored scuff guard, is the most comfortable nozzle in the industry to use • Convenient: One-finger hold-open clip that is easy to set theflow rate OPW 14E ECO Enhanced Conventional Gasoline Nozzle - CARB Certified OPW 14C Diesel Capture Nozzle Color Part # Each Red OPW14E0300 $304.58 Green OPW14E0100 304.58 Black OPW14E0400 304.58 Color Part # Each Green OPW14C0100 $100.07 Black OPW14C0400 100.07 • Body: Aluminum • Lever & Lever Guard: Duratuff® • Packing: Graphite with Teflon® • Disc: Viton® • Spout: Aluminum with Stainless Steel tip and Teflon-coated inside • Inlet Size: 3/4 in. NPT • Max Working Pressure: 50 PSI (3.45 bar) • Weight: 2.73 lbs. each • Listings and Certifications: UL listed, CARB certified, US patents 7,134,580 and 9,126,820 • Body: Aluminum • Lever & Lever Guard: Duratuff® • Packing: Graphite with Teflon® • Disc: Viton® • Spout: Aluminum • Inlet Size: 3/4 in. NPT • Max Working Pressure: 50 PSI (3.45 bar) • Weight: 2.73 lbs. each • Listings and Certifications: UL listed, CARB certified, US patents 7,134,580 and 9,126,820
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 14 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES REMANUFACTUREDDIESEL NOZZLES 1 YEAR WARRANTY The lightweight Big Mouth S diesel nozzle provides efficient refueling and durability at an economical price. Classic rear hold open clip. This automatic diesel nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure-activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Brass tip end holds more securely in the spout – doesn't crack • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals and poppet disc for fuel blends up to E25 and biodiesel • 1" NPT inlet and 1⅛" aluminum spout Part # Each MCN3SOY $79.27 UL 2586 COMPLIANT FUELMASTER S DIESEL NOZZLE The FUELMASTER S diesel nozzle provides the higher flow capacity required for efficient refueling at many truck stops and terminals. Classic rear holdopen clip. It has a pressure-activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Brass tip end holds more securely in the spout – doesn't crack • Super Tuff nylon hand guard and hold-open clip • Viton seals and poppet disc for fuel blends up to E25 and biodiesel • 1" NPT inlet • 13⁄16" aluminum spout Part # Each MCN4SOB $102.47 UL 2586 COMPLIANT 25 -30 GPM 40 -45 GPM CLARENCE SAYS: M. Carder rebuilt nozzles are a sure thing! MADElike new ones, TESTEDlike new ones, WARRANTIEDlike new ones, BUT SAVE $$unlike new ones! Get yourself the same quality and warranty as a new nozzle while saving yourself some money. M. Carder 7H Automatic Diesel Nozzles are completely factory rebuilt and tested. Specifications and assembly standards are the same as a new nozzle. At least 30 new parts are used in the assembly. These nozzles feature a 1" inlet with a 1 3/16" OD spout. 1 Year Warranty • Spout retaining ring - adds extra measure in securing nozzle spout infill pipe • Helps reduce spills - a unique two-stage lever design assures a positive shut-off, even if held wide open • Design Working Pressure - OPW products are designed to work at 50 PSI maximum pressure • Easily replaced spout - simply remove three screws. Replacement kits are readily available from OPW • Dash-pot action - for smoother closing action and reduced line shock • Dual poppets - easy to open nozzle against high pressure • FlowLock™ - designed to shut-off automatically when the spout is tipped up, limiting spillage • Low reliable shut-off - specially designed to ensure proper shut-off as low as 5 gallons per minute • Even, smooth spray pattern - minimizes diesel foaming and false shut-offs • Listed by Underwriters Laboratories, Inc. - UL Listed 40 -45 GPM BIG MOUTH S DIESEL NOZZLE Color Part # Each Black MCR8BOB $92.68 Green MCR8BOG 92.68 Yellow MCR8BOY 92.68 REBUILT 7HB Color Part # Each Black MCR8OB $78.10 Green MCR8OG 78.10 Yellow MCR8OY 78.10 REBUILT 7H
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 15 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! MAX 1 AUTOMATIC 1" DIESEL PREPAY NOZZLE The Max 1 diesel nozzle is designed for durability. This heavy-duty nozzle can be used in high-volume truckstop applications as well as a high-volume service station diesel nozzle. This nozzle is a prepay, no-pressure, no-flow nozzle. The prepay nozzle is specifically designed for unattended self-service and cardlock refueling locations. The prepay feature enables the station operator to control the dispensing of fuel. Either nozzle can be configured to meet the customer’s specific needs. The Max 1 has a 1" NPT inlet with a 1-3⁄16" OD aluminum spout. • Single body, sand cast aluminum construction • Lever and handguard are Super-Tuff glass filled nylon • O-rings and seals are Viton™ • One-hand, hold open mechanism • Dashpot minimizes line shock • Rugged design • All nozzles available as self serve • UL/ULC Listed • Longer spout with anchor bushing • Attitude device NOZZLES MIGHTY MAC DIESEL NOZZLE The Mighty Mac diesel nozzle is designed to provide efficient service for diesel island car, truck, bus and fleet fueling. This single poppet nozzle delivers consistent flow rates of 25+ GPM. Durable and tough, the Mighty Mac is the most economical answer to your diesel needs. • Available as full serve or self serve; automatic shutoff • Completely rebuildable • All major oil company colors available • Custom logo available upon request • BSPP and BSPT threads available upon request • Rugged heavy duty design • Spout easily replaced • Full scuff guard provided for added protection Part # Each CLN1AH $67.22 Part # Each CLN1AL $67.73 CLASSIC 1A DIESEL AUTOMATIC NOZZLE The Catlow Classic 1A nozzle is the most durable aluminum nozzle in petroleum history. The design of this nozzle was the forerunner of all standard gasoline dispensing nozzles today. Utilizing a single poppet in this nozzle affords smoothflow from high GPMs to minimal flow rates. This true 1" NPT nozzle is completely rebuildable and can be used for unleaded fuel as well as diesel refueling. • Available as full serve or self serve • Unleaded or Diesel spout assembly • All major oil company colors available • Automatic shutoff • UL/uLC Listed • Custom logo available • BSPP and BSPT threads available • Attitude device (AD) available MICRO-FLO1000 DIESEL NOZZLE, 1" INLET This automatic gasoline nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals for fuel blends up to E25 and biodiesel • 1" NPT inlet, 15⁄16" spout Color Part # Each Black CLNM1PARADBK $136.03 Green CLNM1PARADGR 136.03 Additional colors and custom logo available on request UL 2586 COMPLIANT Color UL Part # Each Non-UL Part # Each Black MCN1SLOB $63.29 MCN1LOB $52.20 Green MCN1SLOG 63.29 MCN1LOG 52.20 Yellow MCN1SLOY 66.23 MCN1LOY 52.20 CALL OR SEARCH ONLINE FORQUANTITY DISCOUNTS! MCD HIGH FLOWNOZZLES Ideal for truck stops andfleet fueling. Offers "one-hand" hold-open clip with patented safety Kicker. The "Kicker" is designed to assure the hold-open clip will always release when automatic shut-off occurs. 1" inlet - spout size 1-3/16" UL 2586 compliant. Pressure Activated? Part # Each No MCN2OB $106.10 Yes MCN9OB 117.72 MCN2 MCN9
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 16 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES Description Part # Each 3/4" Elite Diesel Nozzle CLNEPL $67.90 3/4" Elite Unleaded Nozzle CLNEPNL 67.90 3/4" Elite E85 Compatible Nozzle CLNEPNLE85 232.96 Color Part # Each Black HU15950404 $85.00 ¾" 11BP SERIES ETHANOL NOZZLES The OPW 11BP Series Ethanol nozzles are designed and rigorously tested for use in today’s alternative fuels. It’s the first nozzle of its kind to be UL-Listed for use in Ethanol-blended fuels up to 85%. • Prevents gasoline spills in prepay or card-lock systems utilizing OPW’s unique No Pressure – No Flow Device; it cannot be opened until the pumping system is pressurized, and closes automatically when the pressure is removed • Prevents consumer from jamming the nozzle in an open position – blocker on lever guard • FlowLock™ allows nozzle to shut-off when falling out of a vehicle, and is sped up, limiting spillage • Durable lever guard won’t scratch customers’ vehicles • New hold-open clip spring lasts longer than previous designs (not on all models) • Uses Accu-Stop® to-the-penny Flow Control Technology • Comfortable, attractive 2-piece NEWGARD™ hand insulator • 50 PSI maximum pressure Color Part # Each Black OPW11BP0492E85 $203.29 Yellow OPW11BP0992E85 203.29 3/4" ELITE AUTOMATIC SHUT-OFF NOZZLES The lightweight, single body with sand cast aluminum construction produces a smooth-working, rugged nozzle – specifically designed for endurance. The Elite prepay nozzle was created for self-service or card-lock systems. The no-pressure,no-flow feature enables the station operator to control the dispensing of fuel. • One-hand hold-open device • Diesel and unleaded nozzles are UL 2586 compliant • Automatic shut-off • Splash shield included with each nozzle • Mates with all standard ⅝" and ¾" hoses • BSPT and BSPP threads, attitude sensing device (AD) all available on request • All major oil company colors available; custom logos on request XS UNLEADED AUTOMATIC SHUT-OFF NOZZLE WITH HOLD-OPEN CLIP • The XS® nozzle shuts off when: the pump shuts off, the gas tank is full, the lever is opened before the pump is turned on or the leak detector has not completed the test cycle • Stainless steel spout bushing keeps spout tip round and acts as a captive fastener to prevent tip- end sensor damage • Equipped with a unique FloStop® device that shuts off the nozzle if it falls from the fill tank or raises above the horizontal • StreamShaper® reduces turbulence for straighter uel flow and less splash back spillage • Comes standard with smooth, full grip guard • Body: One-piece die cast aluminum • Seals: Fluorocarbon • Packing: Double o-ring seal protected by fiber reinforced Teflon® • Lever: One-piece reinforced polymer • Inlet: ¾" (19.1 mm) NPT threads MICRO-FLOW1000 UNLEADED NOZZLE, 1" INLET This automatic gasoline nozzle is a traditionally styled nozzle with all of the M. Carder refinements. It has a pressure activated secondary shut-off that prevents fuel flow until the system is pressurized. • Micro Touch valve offers precise to-the-penny flow control • Roto Matic latch pin provides smooth and consistent automatic shut-off • Pure Teflon packing eliminates stem leaks • Snap-on lever and handle cover • Super Tuff nylon hand guard and hold-open clip • Viton seals for fuel blends up to E25 and biodiesel • 1" NPT inlet, 13⁄16" spout UL 2586 COMPLIANT UL 2586 COMPLIANT CLNEPNL UL 2586 COMPLIANT UL 2586 COMPLIANT ULPart# Each MCN1SUOB $66.23 MCN1SUG 66.17 MCN1SUY 66.17 Non-UL Part # Each MCN1UOB $52.20 MCN1UG 52.11 MCN1UY 52.11 Color Black Green Yellow CALL OR SEARCH ONLINE FORQUANTITY DISCOUNTS!
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 17 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES • Enhances the appearance of your gasoline nozzle • More pleasant for your customers • Won’t deform or crack in cold weather SPLASH SHIELDS Part # Maker Color Material Each OPW8R0300 OPW Red Rubber $7.99 OPW8Y0900 OPW Yellow Rubber 7.99 OPW8G0100 OPW Green Rubber 7.99 OPW8B0500 OPW Blue Rubber 7.99 OPW8BL0400 OPW Black Rubber 7.99 OPW8S0200 OPW Silver Rubber 7.99 OPW8GL0750 OPW Gold Rubber 7.99 MCS//GRED M. Carder Red HD Rubber 5.70 MCS//GYELLOW M. Carder Yellow HD Rubber 5.70 MCS//GGREEN M. Carder Green HD Rubber 5.70 MCS//GBLUE M. Carder Blue HD Rubber 5.70 MCS//GBLACK M. Carder Black HD Rubber 5.95 FOR 11A/AP, 11B/BP & 21GE NOZZLES Part # Maker Color Material Each CLC176BK Catlow Black Rubber $5.63 CLC176GR Catlow Green Rubber 5.63 CLC176Y Catlow Yellow Rubber 5.63 HU180802 Husky Red HD Rubber 7.55 HU180805 Husky Yellow HD Rubber 7.55 HU180816 Husky BP Green HD Rubber 7.55 HU180803 Husky Green HD Rubber 7.55 HU180801 Husky Blue HD Rubber 7.55 HU180804 Husky Black HD Rubber 7.55 HU180809 Husky Silver HD Rubber 7.55 HU180808 Husky Gold HD Rubber 7.55 FOR 7H DIESEL NOZZLES
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 18 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! NOZZLES • Enhances the appearance of your gasoline nozzle • More pleasant for your customers • Won’t deform or crack in cold weather SCUFF GUARDS Part # Maker Color Each OPW6HKR0300 OPW Red $16.01 OPW6HKY0900 OPW Yellow 16.01 OPW6HKG0100 OPW Green 16.01 OPW6HKB0500 OPW Blue 16.01 OPW6HKBL0400 OPW Black 16.01 OPW6HKS0200 OPW Silver 16.01 MCG079RED M. Carder Red 6.91 MCG079YELLOW M. Carder Yellow 6.91 MCG079BLUE M. Carder Blue 6.91 MCG079BLK M. Carder Black 6.91 Part # Maker Color Each OPW6BR0300 OPW Red $15.65 OPW6BY0900 OPW Yellow 18.07 OPW6BG0100 OPW Green 18.07 OPW6BB0500 OPW Blue 14.35 OPWE00308M OPW Black 14.93 OPW6BS0200 OPW Silver 18.07 OPW6BGL0750 OPW Gold 18.07 Part # Maker Color Each OPW6SY0900 OPW Yellow $17.64 OPW6SG0100 OPW Green 17.64 OPW6SBL0400 OPW Black 15.19 Part # Maker Color Each OPW6SBY0900 OPW Yellow $17.64 OPW6SBG0100 OPW Green 17.64 OPW6SBBL0400 OPW Black 17.64 FOR 11A/AP UNLEADED NOZZLES FOR 11B/BP UNLEADED PREPAY NOZZLES FOR 7H DIESEL NOZZLES FOR 7HB DIESEL PREPAY NOZZLES SINGLE PLANE HOSE AND PUMP SWIVELSALUMINUM & BRASS Description Part # Each ¾" – Straight Swivel MCAWS34 $19.10 1" – Straight Swivel MCAWS10 29.10 ¾" x ¾" – 90° Swivel MCAWSP349 48.25 1" x ¾" – 90° Swivel MCAWSP1349 51.13 1" x 1" – 90° Swivel MCAWSP119 69.48 TURNS EASILY AND DOESN'T LEAK All of M. Carder's single plane swivels are machined of aluminum and brass bar stock. The precision-machined surfaces provide the strongest, the best and the smoothest surface for the o-rings to seal between two swivel halves. No Leaks! Brass male end prevents galling in the aluminum nozzle castings. Straight Swivels Ask us about single plane high-flow swivels!
PHONE: 800-333-3331 • 24 HOURFAX: 800-563-8848 • ONLINE: www.JMEsales.com 19 IF YOU DON’T SEE IT, CALL! WE CAN GET IT! SWIVELS Size Part # Each 3⁄4" x 3⁄4" MCAC3434 $26.40 1" M x 3⁄4" F MCAC1034 26.40 1" x 1" MCAC1010 53.80 C1 & C2 MULTI-PLANE SWIVELS TURNS EASILY AND DOESN'T LEAK M.Carder's new multi-plane swivels are different from all others on the market. To provide the best surface for the o-rings to seal, we have inserted a precisely machined brass sleeve into the aluminum castings. The super-smooth surface for the o-ring allows for easy rotation and and extended life for both the o-rings and the swivel. All o-rings are compatible with gasoline blends to E25 and biodiesel. UL Listed. SWIVELS Multi-plane swivel allows for 360° rotation. Compact and lightweight. Size Part # Each 1" M x 1" F CLC7201X1 $65.13 ¾" M x ¾" F CLC72075 30.00 Size Part # Each ¾″ x ¾″ HU000350 $29.74 1″ M x ¾″ F HU000352 31.18 1″ x 1″ HU000087 53.03 SWIVEL For truck and high volume fueling. Size Part # Each 1″ x 1″ HU4860 $83.82 EXTRA HEAVY DUTY 45° SWIVEL 45° design allows a full 360° rotation on both swivel planes. TWISTER SWIVEL The Twister Swivel from Catlow raises the level of swivel flexibility with two (2) high flow, 360 degree, rotating swivel ends. Special seals protect this heavy-duty swivel from extreme cold weather conditions, and it is designed for blended fuels. Its high tech engineering, durable construction and economical price will not only “twist & turn” your hoses, but your profits as well. CONTROLLER SWIVEL & BREAKAWAY You can now have the freedom of movement with the security of a breakaway – all in one product. The controller swivel and breakaway utilizes our heavy-duty swivel with the added benefit of a breakaway that allows you to protect your dispenser without affecting the existing hose length. Special seals protect this part from cold weather conditions and chemical degradation. Size Part # Each ¾" x ¾" OPW241TPS $23.91 1" x 1" OPW241TPS1000 52.63 ¾" for E-85/Biodiesel OPW241TPS0492 49.61 241 SWIVEL 360° on first swivel, 270° on second swivel plane. Size Part # Each 1″ x 1″ CLSBS1X1 Discontinued Size Part # Each ¾″ x ¾″ OPW455060 $29.36 1″ x 1″ OPW455075 56.53
