CAT# CH0121 Phone 800-333-3331| Website JMEsales.com| Fax 800-563-8848 24-Hour Availabilty 45 YEARS OF EXCELLENCE SCAN ME! Chemical Handling Equipment
A HOSE FFOR EVERY APPLICATION FUEL DISPENSING CHEMICAL DUCTING PETROLEUM TRANSFER MATERIAL HANDLING FUEL OIL DELIVERY AVIATION FOOD & BEVERAGE MARINA FIRE HOSE AIR STEAM The John M. Ellsworth Company is proud to offer an unmatched variety of hose and coupled assemblies for every type of application: industrial, construction, commercial, residential, brewery, agriculture, and more. Whether you’re looking to buy a custom cut and coupled assembly or buk hose, we guarantee a solution for moving product from one location to another. With the latest advances in hose assembly in house, we’re your one-stop hose shop!
1 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Whether you prefer talking to one of our friendly sales agents or ordering online, we want your buying experience to be the best one possible. John M. Ellsworth Co., Inc. P.O. Box 240072 8700 W. Bradley Rd. Milwaukee, Wisconsin 53224 Contact Us Fax line (24 Hour) 800-563-8848 E-mail info@jmesales.com 24/7 Online Ordering www.JMEsales.com/chemical HOURS Monday – Friday 7:00 a.m. – 6:00 p.m. CST Toll Free 800-333-3331 Local 414-354-1414 Quick Reference Guide Agitators ....................................................... 27 Air Compressors......................................... 70 Air Fittings ...............................................76-77 Air Pressure............................................71-73 Butterfly Valves..............................43-45, 154 Clamps & Banding.......59, 80, 117, 123-125 Couplings................................................81-98 DrumProducts.......38,75,168-172, 174-176 Dry Disconnects...................................99-105 Duct .............................................................. 67 Elbows................. 94, 119, 139,142, 157-158 Ferrules .............................................. 127-129 FlowMonitoring................................. 155-156 Gasket Sizing Guide..................... 144-145 Gaskets.................................96,118, 146-151 Gauges ................................................74, 196 Grounding Equipment...................... 161-167 Hose.....................52-66, 68-69, 78, 185-186 Hose/Pipe Support ..................................... 79 IBCTotes & Tanks....................................... 28 LoadingArms .................................... 120-121 Locks.......................................................... 191 Lube Oil Transfer....................................... 197 Meters .............................................. 20, 22-26 Nozzles ...................................................... 187 Pipe Fittings ....................................... 157-158 Pipe Repair................................................ 159 Platforms & Stairs ............................. 176-177 Pumps.......................................................2-21 Railcar Equipment .................... 103, 118-119 Reels ..........................................106-112, 161 Safety & Security............................... 190-191 Sanitary Fittings.................123-143, 152-153 Sight Glass......................................... 155-156 Spill Containment/Sorbents ..178-184, 195 Storage Tank Equipment............. 193-195 Strainers........................................... 49-51, 98 Tees....................................140-141, 157-158 Tool Balancers....................................113-116 Tubing..........................................................114 Valves..........................................32-37, 40-47 Vents............................................................. 48 Washdown Equipment..................... 185-189 Wrenches..........................118, 160, 173, 176
2 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Husky Air-Operated Double Diaphragm Pumps • Maximum Fluid Working Pressure: 100 PSI • Maximum Free Flow Delivery: 7 GPM • Maximum Suction Lift: 12' dry; 21' wet • Maximum Size Pumpable Solids: 1/16" • Operating Temp. Range: 40˚ to 150˚F • Fluid Inlet and Outlet Size: ⅜" NPT(f) • Maximum Fluid Working Pressure: 100 PSI • Maximum Free Flow Delivery: 15 GPM • Maximum Suction Lift: 15' dry; 25' wet • Maximum Size Pumpable Solids: 3/32" • Operating Temp. Range: 40˚ to 180˚F • Fluid Inlet Size: ¾" NPT(f) • Air Inlet Size: ¼" NPT(f) • Air Exhaust Port Size: ⅜" • Includes bushing for ½" installation • Maximum Fluid Working Pressure: 125 PSI • Maximum Free Flow Delivery: 50 GPM • Maximum Suction Lift: 16' dry; 29' wet • Maximum Size Pumpable Solids: ⅛" • Fluid Inlet and Outlet Size: 1" NPT(f) 15 GPM 7 GPM 50 GPM SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH ⅜" Aluminum Acetal TPE TPE GRD31255 $497.42 Fluid Pressure Relief Kit (Recommended by Graco) GR238899 299.96 SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH ½" Aluminum Acetal Nitrile Rubber Nitrile Rubber GR243669 $846.27 Fluid Pressure Relief Kit (Recommended by Graco) GR238899 299.96 SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH 1" Aluminum TPE Acetal TPE GR647666 $1,045.50 1" Aluminum TPE Acetal Acetal GR647016* 918.67 Fluid Pressure Relief Kit (Recommended by Graco) GR238899 299.96 GR647016 is UL Listed. Husky 307 Aluminum Pump The Husky 307 air-operated diaphragm pump features a stall-free low pulsation air valve that provides a smooth and rapid changeover. • Quick and easy assembly and disassembly design • Easy-to-service air valve and ball checks • Operates on as little as 20 PSI (1.4 bar, 0.14 MPa) • Split manifold option pumps multiple fluids without mixing Husky 515 Dual Inlet Aluminum Pump The Husky 515 air-operated double diaphragm dual inlet pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability. • Center and end porting options • No mechanical seals to cause fluid leaks or failures • Easy-to-service air valve and ball checks • Operates on as little as 20 PSI (1.4 bar, 0.14 MPa) • Split manifold option pumps multiple fluids without mixing Husky 1050 Aluminum Pumps The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps. • Up to 5 times longer diaphragm life compared to other air-operated diaphragm pumps in its class • Expanded material offering to handle endless applications • Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation. PUMPS
3 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Husky Stainless Steel 1590 Pump The Husky 1590 air-operated diaphragm pump features a patented, high-reliability closed center air valve that is online serviceable and an epoxy-coated air section for tough environmental conditions. • The air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump Husky 716 Stainless Steel Pump The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities. • Center- and end-porting • No mechanical seals which causes fluid leaks or failures • Easy-to-service air valve and ball checks Husky Stainless Steel 2150 Pump The Husky 2150 air operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. • Highest fluid flow rate in its class • The complete air valve is externally accessible so it can be serviced fast and easy without removing the diaphragm pump SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH ¾" Stainless Steel Stainless Steel/ Teflon® PTFE PTFE GRD54211 $1,746.80 Fluid Pressure Relief Kit (Recommended by Graco) GR238428 278.80 SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH 1" Stainless Steel 316 SST PTFE PTFE/EPDM 2 Piece GR651009 $2,664.50 SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH 1½" Stainless Steel Stainless Steel/ Teflon® PTFE PTFE GRDB4311 $4,703.30 SIZE BODY SEATS BALLS/CHECK DIAPHRAGM PART # EACH 2" Stainless Steel Stainless Steel/ Teflon® PTFE PTFE GRDF4311 $6,774.20 16 GPM 50 GPM 100 GPM 150 GPM Husky Stainless Steel 1050 Pump The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. • Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation Husky Air-Operated Double Diaphragm Pumps • Maximum Fluid Working Pressure: 100 PSI • Maximum Free Flow Delivery: 16 GPM • Maximum Suction Lift: 11' dry • Max. Size Pumpable Solids: 0.09" • Maximum Operating Temp.: 150°F • Maximum Fluid Working Pressure: 125 PSI • Maximum Free Flow Delivery: 50 GPM • Maximum Suction Lift: 16' dry, 29' wet • Maximum Size Pumpable Solids: ⅛" • Maximum Fluid Working Pressure: 120 PSI • Maximum Free Flow Delivery: 100 GPM • Maximum Suction Lift: 20' dry • Max. Size Pumpable Solids: 0.19" • Maximum Operating Temp.: 150°F [200°F (93.3°C) w/ PTFE diaphragms] • Maximum Fluid Working Pressure: 120 PSI • Maximum Free Flow Delivery: 150 GPM • Maximum Suction Lift: 20' (6.1 m) dry • Max. Size Pumpable Solids: 0.25" • Maximum Operating Temp.: 150°F [200°F (93.3°C) w/ PTFE diaphragms] PUMPS
4 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Non-Metallic, Air-Operated Diaphragm Pumps ARO Pro Series air-operated diaphragm pumps are ideal for general industrial and OEM installation applications. They can easily pump from clean, light viscosity fluids to corrosive, abrasive medium viscosity fluids and can transfer large particles without damage. Our pumps offer the ability to vary the flow outlet and discharge pressure by using just an air filter / regulator and a needle valve. • Sealless design • Can run dry without damage • Manufactured for complete corrosion resistance; Constructed with polypropylene center body, standard stainless steel fasteners, and polypropylene or acetal casing materials • Simul-Shift™ valve provides efficient, ultra-positive, reliable shift signal • ARO's patented 'Unbalanced' air valve ensures reliable, no-stall operation • Multiple porting options for your application needs • Bolted construction for leak-free fluid handling • Ease of service through modular design • Ratio: 1:1 Compact Series • Maximum Operating Pressure: 100 PSI PRO Series • Body: Polypropylene • Maximum Operating Pressure: 120 PSI SIZE AIR INLET FLUID INLET MAX GPM MAXSOLIDS DIAMETER. BODY SEAT BALL/ DIAPHRAGM PART # EACH ⅜" ¼" ⅜"—18 NPTF-1 10.6 1/16" Polypropylene Polypropylene Santoprene AROPD03PAPSPAA $377.60 ⅜" ¼" ⅜"—18 NPTF-1 10.6 1/16" Groundable Acetal Acetal PTFE/PTFE/ Santoprene AROPD03PADSDTT 545.00 ½" ¼" ½"—14 NPTF-1 14.4 3/32" Polypropylene Polypropylene Santoprene AROPD05PAPSPAAB 729.11 ½" ¼" ½"—14 NPTF-1 14.4 3/32" Groundable Acetal Acetal PTFE AROPD05PADSDTTB 824.17 ¾" ¼" ¾"—14 NPTF-1 14.8 3/32" Polypropylene Polypropylene Santoprene AROPD07PAPSPAA 712.93 ¾" ¼" ¾"—14 NPTF-1 14.8 3/32" Polypropylene Polypropylene PTFE AROPD07PAPSPTT 764.18 SIZE AIR INLET FLUID INLET MAX GPM MAX SOLIDS DIAMETER BODY SEAT BALL/ DIAPHRAGM PART # EACH 1" ¼" 1" NPTF 47 ⅛" Polypropylene Polypropylene Santoprene ARO6661AJ3EBC $928.35 1" ¼" 1" NPTF 47 ⅛" Polypropylene Polypropylene PTFE ARO6661AJ344C 1,055.07 AROPD07P… PUMPS
5 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Metallic, Air-Operated Diaphragm Pumps ARO Pro Series air operated diaphragm pumps are ideal for general industrial and OEM installation applications. They can easily pump from clean, light viscosity fluids to corrosive, abrasive medium viscosity fluids and can transfer large particles without damage. Our pumps offer the ability to vary the flow outlet and discharge pressure by using just an air filter / regulator and a needle valve. • Sealless design • Can run dry without damage • Manufactured for complete corrosion resistance; Constructed with aluminum center body, standard stainless steel fasteners, and aluminum casing materials • Simul-Shift™ valve provides efficient, ultra-positive, reliable shift signal • ARO's patented 'Unbalanced' air valve ensures reliable, no-stall operation • Compact, heavy duty design enables usage in versatile locations including limited space • Bolted construction for leak-free fluid handling • Ease of service through modular design • Ratio: 1:1 Compact PRO Series • Body: Aluminum • Maximum Operating Pressure: 100 PSI SIZE AIR INLET FLUID INLET/ OUTLET MAX GPM MAX SOLIDS DIAMETER MAX DRY SUCTION LIFT SEAT BALL/ DIAPHRAGM PART # EACH ½" ¼" ½" 12 3/32" 15.0 ft Aluminum Santoprene AROPD05AAASFAAB $896.67 ½" ¼" ½" 12 3/32" 15.0 ft Aluminum PTFE/PTFE/ Santoprene AROPD05AAASPTTB 919.17 SIZE AIR INLET FLUID INLET/ OUTLET MAX GPM MAX SOLIDS DIAMETER MAX DRY SUCTION LIFT SEAT BALL/ DIAPHRAGM PART # EACH 1" ¼" 1" 35 ⅛" 20' Polypropylene Santoprene ARO6661003EBC $1,000.38 1" ¼" 1" 35 ⅛" 20' Polypropylene PTFE/PTFE/ Santoprene ARO666100344C 1,078.90 1½" ½" 1½" 90 ¼" 19' Polypropylene Santoprene ARO6661503EBC 1,153.58 1½" ½"- 1½" 90 ¼" 19' Stainless Steel PTFE/PTFE/ Santoprene ARO666150244C 1,516.67 2" ¾" 2" 172 ¼" 27.2' Santoprene Santoprene ARO666250EEBC 1,664.00 2" ¾" 2" 172 ¼" 27.2' Stainless Steel PTFE/PTFE/ Santoprene ARO666250144C 2,315.84 3" ¾" 3" 237 ⅜" 17.6' Santoprene Santoprene ARO666300EEBC 2,550.40 3" ¾" 3" 237 ⅜" 17.6' Stainless Steel PTFE/PTFE/ Santoprene ARO666300144C 3,819.17 PRO Series • Body: Aluminum • Maximum Operating Pressure: 120 PSI ARO6661003EBC ARO6661503EBC ARO666250EEBC ARO666300EEBC PUMPS
6 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Graco ChemSafe PTFE Air-Operated Double Diaphragm Pump Graco's ChemSafe pumps feature PTFE corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. There's no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus they're dead-head capable and achieve high flow rates while minimizing air consumption and operational noise. • Max flow rate of 37.5 GPM (142 LPM) • High quality machined design provides a precision fit and superior chemical containment compared to molded pumps • Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation • Removable air motor offers easy and intuitive maintenance ensuring maximum pump performance and availability • Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater • Supports multiple guns INLET FLOW-RATE SERIES PART # EACH 1/4 in. NPT 3.7 GPM 205 GR24X429 $1,545.90 3/8 in. NPT 7.9 GPM 307 GR24X427 1,623.70 1/2 in. NPT 16.6 GPM 515 GR24X425 3,179.20 1 in. NPT 37.5 GPM 1040 GR24X423 6,212.50 1 1/2in. NPT 99.5 GPM 1590 GR24X421 11,832.90 Husky 515 3/4 in. 15 GPM Acetal Pump Dispense System with Air Control, Dispensing Hose, & Nozzle for 55 Gallon Drums The Husky 515 dispensing system provides clean and accurately controlled dispensing and supply. It's easy to install and includes an air-operated double diaphragm pump, mixer, and drum cover elevator. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability. • Easily transfer small batches of material from 55 gallon (200 liter) drums • Waterborne and solventborne compatible • Features lube-free assembly to eliminate fluid contamination • Tint dispensing from drum to scales for accuate metering by weight in paint and dye processing plants • Fully-groundable acetal model • Delivery up to 15 GPM (56.7 LPM) • Easy-to-service air valve and ball checks • No mechanical seals to cause fluid leaks or failures • Runs quietly with easy-to-use remote muffler capability for even lower noise levels • Easy-to-service air valve and ball checks • Operates on as little as 20 PSI (1.4 bar, 0.14 MPa) • Split manifold option to pump multiple fluids without mixing INLET WEIGHT FLOW-RATE TYPE PART # EACH 3/4 in. NPT 187 LBS 15 GPM Air Operated GR231418 $6,809.60 Husky 515 3/4 in. Pump Twistork Agitator Packages Fluid transfer package mixes most paints, resins, urethanes, epoxies and latex materials up to 1000 cps. Gentle whipfree mixing action reduces degradation and splashing. This closed system prevents evaporation, reducing VOC emissions. This helps maintain the purity of the material in the drum - simplifying drum agitation, plus improving efficiency and quality.. • Reduce volatile fluid evaporation while maintaining the purity of sealed drum contents • Available with acetal or polypropylene Husky 515 diaphragm pump • Quiet, versatile pump connected to agitator lifts solids from bottom of tank and mixes while maintaining suspension • Mix paint, resins, urethanesm epoxies and latex materials up to 1000 cps MATERIAL INLET WEIGHT FLOW-RATE TYPE PART # EACH Polypropylene 3/4 in. NPT 49 LBS 15 GPM Air Operated GR238859 $3,532.30 Acetal 3/4 in. NPT 51 lbs 15 GPM Air Operated GR238860 3,345.50 PUMPS
7 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Port Size Drain With Gauge Flow Capacity Part # Each 1/4" Manual Yes 72 sfcm AROP39224610 $95.78 3/8" Manual Yes 132 scfm AROP39334610 122.09 1/2" Manual Yes 172 scfm AROP39344610 109.16 "Piggyback" Filter-Regulators with Metal Bowls Filter-regulators, or “piggybacks,” combine the functions of both a filter and regulator. Piggybacks are compact and most effective when space is a constraint. Piggybacks can be ordered with different filter elements and can be modified with different springs, depending on the filtration and air regulating requirements. • Industry leadingflow rates • Low leak rates • All modular design • Full line accessory set • Locking bowls for safety • Bright, flush mount gauge with settable fan feature • 5 micron standardfilter • 2 year warranty Visit JMEsales.com for additional models and complete specifications! 1/4" Model 3/8" and 1/2" Models Size Bowl Type Drain Filter-Regulator Pt. # Part # Each 3/8" Metal Manual P39334-600 AROC38331600 $180.31 3/8" Polycarbonate Manual P39334-610 AROC38331610 193.14 3/4" Metal Manual P39354-600 AROC38351600 205.85 3/8" Metal Manual P39334-600 AROC38331600 180.31 ARO 2000 Series 3/8 in. 3-Piece Combination Filter Regulator + Lubricator w/ Metal Bowl & Manual Drain Filters, regulators, lubricators, and piggybacks can be combined together to form combinations. They are typically strung together in the F+R+L arrangement (three-piece combo) and F/R+L (two-piece combo) arrangement, although other configurations are also used depending on application needs. ARO-Flo combination FRLs are easily assembled using modular spacer kits. • Industry leadingflow rates • Low leak rates • All modular design • Full line accessory set • Locking bowls for safety • Bright, flush mount gauge with settable fan feature • 5 micron standardfilter • 2 year warranty Visit JMEsales.com for additional models and complete specifications! AROC38331600 Needrepair partsor rebuild kitsfor a pump? EXPANDEDwith even MORE MANUFACTURERS at our online parts department / pump parts: JMEsales.comor call 1-800-333-3331.
8 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL 1" Self-Priming Stainless Steel Centrifugal Pumps The AMT 300 Series Investment cast stainless steel transfer pumps are designed to handle liquids and chemicals with specific gravities to 1.6. The pumps are particularly well suited to applications involving perchloroethylene (PCE) and are recommended for use with non-flammable liquids. These pumps are fitted with Viton® mechanical seals and o-rings. AMT stainless steel transfer pumps are reliable, cost effective, and low maintenance. • 1" NPT suction and discharge ports • Maximum Working Pressure: 75 PSI • Maximum Temperature: 200°F • Maximum Flow: 66 GPM • Maximum Head: 68' • Self-Priming to 6' • Self-Cleaning, semi-open impeller • Available with Open Drip Proof (ODP) or Totally Enclosed Fan Cooled (TEFC) motor • 1/3 to 2 HP single- or three-phase motor Straight Stainless Steel Centrifugal Pumps This line of AMT Straight Centrifugal pumps is designed for continuous-duty low pressure OEM, industrial/commercial and general service applications including circulation, chemical processing, liquid transfer, and cooling. These durable and compact pumps are available in a variety of construction and seal materials to meet your specification. All have self-cleaning impellers to prevent clogging and minimize maintenance. Also, all pumps come with a NEMA 56J TEFC (totally enclosed fan cooled) motor. • NEMA 56J Single- and three-phase motors • TEFC (Totally Enclosed Fan Cooled) motors • Stainless steel motor shaft • Viton® seals • Maximum Temperature: 200˚F • NEMA base-mounted motor • Self-cleaning impeller • Discharge rotates in 90˚ increments • Front drain plug SUCTION & DISCHARGE PORT MAX WORKING PRESSURE MAX TEMPERATURE HP VOLTAGE GPM CURVE SEALS/ O-RINGS PART # EACH 1" NPT 75 PSI 200˚F 1/3 115/230-1PH 33 A Viton® AMT429498 $829.32 1" NPT 75 PSI 200˚F ½ 115/230-1PH 33 A Viton® AMT429A98 907.18 1" NPT 75 PSI 200˚F ½ 115/230-1PH 45 B Viton® AMT429598 852.66 1" NPT 75 PSI 200˚F ¾ 115/230-1PH 45 B Viton® AMT429B98 966.30 1" NPT 75 PSI 200˚F 1 115/230-1PH 60 D Viton® AMT429798 915.34 SUCTION & DISCHARGE PORT MAX WORKING PRESSURE MAX TEMPERATURE HP VOLTAGE GPM CURVE SEALS/ O-RINGS PART # EACH ¾" X ½" 75 PSI 200˚F 1/3 115/230-1PH 34 A Viton® AMT368A98 $611.64 1" X ¾" 75 PSI 200˚F ½ 115/230-1PH 47 B Viton® AMT370B98 671.74 1" X ¾" 75 PSI 200˚F ¾ 115/230-1PH 52 C Viton® AMT370A98 681.52 1¼" X 1" 75 PSI 200˚F 1 115/230-1PH 77 D Viton® AMT369C98 745.97 PUMPS
9 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL DESCRIPTION PORT SIZE PART # EACH 12-Volt DC ¾" NPT MP34141 $358.21 24-Volt DC ¾" NPT MP34296 358.21 Explosion Proof 1 Phase ¾" NPT MP36444 1,491.79 FRX 75 Centrifugal Pumps Model CFX 75 is a high performance, 316 stainless steel centrifugal pump. The pump is ideal for marine, agricultural, commercial or industrial transfer applications of compatible fluids. The CFX 75 model features all 316 stainless steel components for superior corrosion resistance when pumping chemical compounds. This pump offers up to 38 head feet and a semi-open, stainless steel impeller. A carbon / ceramic / Viton® bellows shaft seal is standard; o-ring is Viton®. Suction and discharge ports are ¾" x ¾" NPT. Marine ignition protected motors available. Pump rotation in 90° increments. FMX 75 SP Centrifugal Pumps Model FMX 75-SP is a high performance, self-priming 316 stainless steel centrifugal pump. The pump is ideal for marine, industrial, agricultural or commercial applications where suction lift is required. The FMX 75-SP model features all 316 stainless steel components for superior corrosion resistance when pumping chemical compounds. This pump offers up to 23 head feet and a semi-open, stainless steel impeller. A carbon / ceramic / Viton® bellows shaft seal is standard. Ports are ¾" NPT with ⅛" NPT fill port. The Viton® o-ring and flapper design enhances the self-priming capability to 12 feet suction lift. Marine ignition protected motors available. DESCRIPTION NPT PORT PART # EACH 12-Volt DC ¾", ⅛" Fill MP35322 $451.49 24-Volt DC ¾", ⅛" Fill MP35323 451.49 Explosion Proof 1 Phase ¾", ⅛" Fill MP39301 1,533.58 MODEL MOTOR TYPE* PORT SIZE GPM HEAD FEET PART # EACH Flomax 8 Cast Iron Honda 5.5 HP 2" NPT Up to 150 Up to 100 MP29635 1,363.43 Flomax 15 Cast Iron JD 11 HP Electric Start 3" NPT Up to 320 Up to 145 MP36655 1,780.60 Flomax 15 Cast Iron Honda 11 HP Electric Start 3" NPT Up to 320 Up to 145 MP34616 2,975.37 *All motors include base assembly. Flomax® 15 Features • Ports: 3" x 3" NPT • Construction: 316 Stainless steel, bronze, cast iron • Impeller: 6.0" Maximum diameter, semi-open • Maximum Solid Size: .625" • Motor: Up to 7.5 HP • Drive Options: Closecoupled 184TC or 215C; Engine mount 5.5, 6.5, 11 or 13 HP; Pedestal; PumPAK® (without motor) • Seal: Special combinations available; standard carbon/ ceramic/Viton® Flomax® 8 Features • Ports: 2" x 2" NPT • Construction: 316 Stainless steel, bronze, aluminum, cast iron • Impeller: 5.0" Maximum diameter, semi-open • Maximum Solid Size: .56" • Motor: Up to 3 HP • Drive Options: Close-coupled 145TC or 56C; Engine mount 5.5 or 6.5 HP; Pedestal, PumPAK® (without motor) • Seal: Special combinations available; standard carbon/ ceramic/Viton® Flomax® 8 and 15 Centrifugal Pumps Flomax® self-priming centrifugal pumps are used for hydraulic applications in agricultural, industrial and marine environments as bilge pumps, auxiliary fire pumps, ballast transfer pumps, washdown pumps, fertilizer and pesticide pumps, applicators and sprayers, blending pumps, nurse tanks, bulk transfer pumps and more. Up to 28 GPM • Marine • Agricultural • Commercial • Industrial Applications • Marine • Agricultural • Commercial • Industrial Applications Up to 21 GPM PUMPS
10 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL CHEMFLO® Pumps CHEMFLO® 1 and CHEMFLO® 2: 1½" x 1" End Suction Centrifugal Pumps Designed to be applied in a wide range of pumping applications where stainless steel is required. The pumps utilize a semi-open impeller design to allow for passage of larger solid sizes than similar sized enclosed impellers. Several seal options are available in addition to the standard type 2100 carbon / ceramic / Viton® mechanical seals. Electric and hydraulic motors can be close coupled to ChemFlo® 1 and 2 pumps or pedestal mounted versions are also available for long coupling. MODEL DRIVE SEAL GPM SUCTION X DISCHARGE PART # EACH CHEMFLO® 1 Close-Coupled 56C Viton® 100 1½" x 1" MP36429 $2,708.21 CHEMFLO® 2 Close-Coupled 56C Viton® 110 1½" x 1" MP36430 2,759.70 DESCRIPTION SEAL GAS ENGINE PART # EACH 2" Polypropylene Centrifugal Pump EPDM 6.5 HP Honda TP200P6PRORC $625.57 CHEMFLO® 1 • Suction And Discharge: 1½" x 1" NPT • Materials Of Construction: 316 stainless steel, CFB (nickel aluminum bronze) • Flow: Up to 128 GPM • Head Feet: Up to 103' • Impeller: 6" semi-open, cast 316 stainless steel • Motor: Up to 3 HP • Drive Options: Close-coupled 56C; Close-coupled 145TC; Pedestal; or PumPAK® (without motor) • Seal Material: Standard carbon / ceramic / Viton®; Other seal options available CHEMFLO® 2 • Suction And Discharge: 1½" x 1" NPT • Materials Of Construction: 316 stainless steel, CFB (nickel aluminum bronze) • Flow: Up to 108 GPM • Head Feet: Up to 103' • Impeller: 5.25" Semi-open, cast 316 stainless steel • Motor: Up to 3 HP • Drive Options: Close-coupled 56C; Close-coupled 145TC; Pedestal; or PumPAK® (without motor) • Seal Material: Standard carbon / ceramic / Viton®: Other seal options available CHEMFLO® 1 Polypropylene Self-Priming Centrifugal Pump with Roll Cage 6.5 HP, 190 GPM Tried and true, lightweight poly pumps offer an excellent combination of portability, durability, chemical resistance, and overall economy. The 6.5 HP Briggs & Stratton gas engine offers a superior design and a heavy duty flywheel for unparalleled performance. Warning: do not run pump dry, restrict or reduce port sizes, or dead head pump. This could cause component failure to pump. Do not use with flammable liquids. • Precision molded construction • Lightweight • Corrosion resistant • Superior design • Low maintenance • EPDM - An excellent choice for a wide range of chemicals at the most affordable direction • Pump end separated from engine • Large weep holes between pump and engine • High strength polypropylene PUMP • High oil fill • 6.5 HP Briggs & Stratton engine with Oil Guard® low oil sensor and overhead valve • Low maintenance PUMPS
11 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL PUMPS Dura-Pump™ Pumps & Meters 15 GPM 15 GPM 2-22 GPM PORT IN PORT OUT SEAL PART # EACH 2 in. MNPT x 1 in. FNPT 1 in. FNPT EPDM DURDP4012E $578.57 2 in. MNPT x 1 in. FNPT 1 in. FNPT VITON DURDP4012V 610.00 PORT IN PORT OUT UNITS SEAL PART # EACH 1 in. FNPT x 2 in. MNPT 1 in. FNPT Gallons/Liters EPDM DURDP3000E $287.14 1 in. FNPT x 2 in. MNPT 1 in. FNPT Gallons/Liters VITON DURDP3000V 292.86 SEAL PART # EACH EPDM DURDPE4012E $674.29 VITON DURDPE4012V 715.71 VOLT PART # EACH 12V DC DURDPABS4312V 1,368.57 110V DC DURDPABS4315V 1,431.43 SEAL PART # EACH EPDM DURDPEM4312E 958.57 VITON DURDPEM4312V 1,017.14 Dura-Pump™ 12 Volt DC Herbicide Pump Dura-Meter™ Herbicide Meter 1 in. FNPT x 2 in. MNPT Dura-Pump™ Easy Caddy System • When a 30 minute duty cycle is not observed, the motor is thermally protected from overheating • When a 30 minute duty cycle is not observed, the motor is thermally protected from overheating • Pump can be easily serviced in the field. Simply, remove 6 screws to change the cartridge and you have rebuilt the pump. • The Suction port has both a 2" Male NPT and a 1" Female NPT connection for a wide range of options. • Features 2 Year Service Warranty plan • Includes 2 Year Maintenance Program • 100% moisture-sealed circuitry makes the meter impervious to water • Supported by a Quick List reference chart • Faceplate over-molded with santoprene and filled with gel for improved shock resistance • Extended battery life with use of 4 "AAA" batteries • Can be mounted in 6 different configurations on a variety of tank/tote and drum types • Use it mounted on top of tank, on side of tank, or off the ground depending on user preference • Tanks/Totes/Drums sold separately • Conversion Kits are available to mount system on 55 Gallon Drum (DP-T4001) Call a JME Specialist at 800-333-3331 High-flow Herbicide Dura-Pump™ with 15 GPM free flow rate contains a self-priming diaphragm pump with internal by-pass, meaning you can close the hose without impacting the pump. The Dura-Pump maintains reliability in most extreme environments. 12 volt DC available with EPDM or Viton seals. Dura-Meter™ is plummed for in-line and 90° applications. Includes an impact resistant Lexan® faceplate with a menu driven backlit display. It can also can withstand impacts common in the agricultural market and beyond. This herbicide meter boasts a Quick List reference chart that allows the user to simply input a number that corresponds to the chemical viscosity and adjust up or down for more accuracy. Features a 2-year Warranty & Maintenance Program. The Dura-Pump™ Easy Caddy chemical transfer system can be mounted on top of tank or top of 55 gallon drum, on the side of tank, or off the ground depending on user preference. The Dura-Pump™ Easy Caddy chemical transfer system contains Dura Products popular Dura-Pump3 mounted conveniently in a sturdy frame. Additionally, it comes with all necessary connections for common IBC tanks and totes. You can draw from the ubiquitous 2" camlock at the bottom. Constructed from quality materials with rigorous weather and demanding applications in mind. Although it most commonly hangs on the side of a tote, you can also mount it on top of a cage tank or on top of a 55 gallon drum, on the side of a cage tank, or off the ground depending on user preference. A tote is not included with the system. Available with EPDM or Viton seals. Chemical Transfer System With Auto-Batch System Chemical Transfer System With Dura-Meter™ Chemical Transfer System DURDPABS4312V & DURDPABS4315V DURDPE4012E & DURDPE4012V DURDPEM4312E & DURDPEM4312V
12 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL FLUX F 424 Sealless Drum Pumps and Motor Kits A FLUX drum pump is always a “Two-Component-Team” consisting of a drive motor and a pump (tube set). The sealless pump F 424 is ideal for transferring various low-viscosity and aggressive media. It is suitable for media that flows quickly and does not bond or crystallize or is abrasive. With this pump you can empty drums, IBCs, and basins. How It Works: The medium enters the inner tube along the shaft. There it has the same level as the liquid level in the drum. When emptying the drum, the medium level in the drum decreases. Accordingly, the medium level in the inner tube also decreases. The fluid therein flows off through the relief openings. FLUX Drum And Container Pumps: Which Material Goes Best With Which Liquid? Stainless Steel • 1.4571/316 Ti (S) • Up to 100°C • Suitable for highly flammable liquids (up to temperatures of class T4) as well as for all neutral and non-flammable, thin liquids like solvents, organic acids, dilute anorganic acids and alkalies • Certified for use in Zone 0 • Examples of Suitable Liquids: acetone, alcohol, ammonia, petrol, flammable solvents, nitrocellulose varnishes, perchlorethylene, trichlorethylene, toluene, potassic alkali, soda alkali, phosphoric acid (up to 60 %), sulphuric acid (up to 75% and more than 96%), fruit juices, milk, salad oil and all liquids listed for aluminum alloy Polypropylene (PP) • Up to 50°C • Suitable for both, chemically aggressive and neutral liquids, together with hardly flammable liquids such as acids and alkalis • Examples of suitable liquids: formic acid, ammonia, boric acid, chromic acid (up to 10%), liquid fertilizers, acetic acid, photo developers, hydrofluoric acid (up to 70%), fruit acids, potassic alkali, copper chloride, lactic acid, soda alkali, phosphoric acid, hydrochloric acid, sulphuric acid (up to 80%), distilled water Polyvinylendene Fluoride (PVDF) • Up to 100°C • Suitable for both, chemically aggressive and neutral liquids, together with hardly flammable liquids such asacids and alkalis • Examples of suitable liquids: hydrobromic acid, chromic acid, chloric acid, hydrofluoric acid, sodium hypochlorite, nitric acid (up to 75%), sulphuric acid and all liquids listed for polypropylene (except soda alkali) IMMERSION LENGTH PUMP MATERIAL MOTOR PART # EACH 39" Stainless Steel F457 120-Volt Electric AFLX42422010F457 $1,544.14 39" Stainless Steel F4161 without Trigger Valve AFLX42422010F4161 1,624.64 39" Polypropylene F457 120-Volt Electric AFLX42440010F457 1,182.50 39" Polypropylene F4161 without Trigger Valve AFLX42440010F4161 1,264.20 39" PVDF F457 120-Volt Electric AFLX42460010F457 1,541.70 39" PVDF F4161 without Trigger Valve AFLX42460010F4161 1,622.30 47" Stainless Steel F457 120-Volt Electric AFLX42422012F457 1,501.40 47" Stainless Steel F4161 without Trigger Valve AFLX42422012F4161 1,582.00 47" Polypropylene F457 120-Volt Electric AFLX42440012F457 1,296.30 47" Polypropylene F4161 without Trigger Valve AFLX42440012F4161 1,239.50 47" PVDF F457 120-Volt Electric AFLX42460012F457 1,596.70 47" PVDF F4161 without Trigger Valve AFLX42460012F4161 1,677.30 F4161 Motor F457 Motor Motor Specs • Explosion-proof to ATEX, category 2, tested and certified according to Directive 94/9/EC • PTB Registration No. 02 ATEX D022 • Extremely lightweight and powerful motor design, overload-proof • Easily variable speed; Control by adjusting either the air supply pressure or volume Pump Specs • Spiral-shaped guide bearing in the inner tube prevents unwanted deposits in the pump and increases the service life significantly • Flow Rate: 240 GPM • No seal in the liquid area • No seal wear • Optimal emptying of the inner tube • Low wear of guide bearing and shaft • Long bearing life • Low vibration • Stainless steel version for use in hazardous areas PUMPS
13 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL MAX. GPM MAX. HEAD VISCOSITY PART # EACH 57 85' 800 FLXFEM4070120V $613.71 58 98' 1000 FLXF457120V 755.14 58 92' 900 FLXF458120V 790.29 58 92' 900 FLX460120V Explosion Proof 1,143.43 63 98' 1200 FLXF4161Air Motor 738.00 63 98' 1200 FLXF416Air Motor 839.14 MATERIAL MAX. GPM MAX. HEAD VISCOSITY IMPELLER FITS DRUM PART # EACH Polypropylene 57 85' 800 PTFE 39" FLXF424PP413639 $461.14 Polypropylene 58 98' 1000 PTFE 39" FLXF424PP4135Z39 461.14 Stainless Steel 58 92' 900 PTFE 39" FLXFP424S433839 855.43 Stainless Steel 58 92' 900 PTFE 39" FLXFP424S4337Z39 855.43 Polyvinylidene Fluoride (PVDF) 63 98' 1200 PTFE 39" FLXF424PVDF413639 861.43 Polyvinylidene Fluoride (PVDF) 63 98' 1200 PTFE 39" FLXF424PVDF4135Z39 861.43 Why FLUX Tubesets for Drum Pumps? 1. Durable design—no nuisance breakage issues. 2. “Top pull out" design for easy cleaning / inspection. 3. Oversized bearings, driveshaft. 4. Reversible Hastelloy C driveshaft (doubles life). 5. Cartridge bearing assembly (or parts) sold separately. 6. Double radial lip seals (Viton®, EPDM, PTFE or Kalrez). 7. Safe—no “weep hole." 8. Spiral bearing driveshaft support. 9. Foot piece has a screw-on design. 10. 50mm models available for added durability and performance. 11. PTFE impellers. 12. Thick wear surfaces–long life. Why FLUX Drum Motors? 1. Ergonomically designed / durable 2-wall construction for reduced noise, vibration, strength and chemical resistance. 2. Fume-protected components. 3. Quiet and low pitched. 4. Simple brush replacement. 5. More efficient / low amp draw. 6. Cotton filter-to-filter air aids cooling and reduces noise. 7. Superior cable protection sleeve. 8. Armature cooling fan. 9. Lacquer coated windings. 10. Bearing cup sleeve provides fume protection. 11. Motor repair is easy. 12. Air motors consume a max. of 17 SCFM / more powerful / more efficient 13. “Wear resistant" vanes / easier to replace What makes the best choice for Drum Pumps and Motors? Durability, wear life, performance, user- and maintenance-friendly, proprietary design! F457-120V FEM4070-120V F458-120V F460-120V F416-1 F416 • (5) pump materials: polypropylene, Kynar, stainless steel, aluminum, Hastelloy C • (5) impeller types: sealless, mechanical seal, liquid saver (complete drum drainage), pump and mixer combination, 3A sanitary • Lengths from 12" to 10' tall • Flow rates to 63 GPM • Head capability to 98° of head • Elastomer options: Viton®, EPDM, PTFE, Kalrez • Reversible driveshaft / spiral center support / top pullout • Over 30 motors to choose from: open drip proof, totally enclosed fan-cooled, explosion-proof, 12-V, 24-V, single phase, three phase, one speed, variable speed, etc. • 60 Hz, 50 Hz, continuous duty, brush motor, brushless motors, induction motor, air (pneumatic) motors PUMPS
14 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Nylon Chemical Pump • Nylon construction • Stainless steel rod • Fits 15- to 55-gallon drums • Teflon® seals Lift Style Chemical Pump • Plated-steel construction • Cast-iron bung adapter • Adapts to fit 15- to 55-gallon drums • Teflon® seal Stainless Steel Lift Chemical Pump • All stainless steel construction • Fits 15- to 55-gallon drums • Teflon® packing and seals PART # EACH NS366T $35.32 PART # EACH NS360 $37.83 PART # EACH NS365 $59.74 PART # EACH NS387 $138.48 Applications • Kerosene • Paint thinners Applications • Detergents • Antifreeze • Windshield washer fluid Applications • Detergents • Antifreeze • Windshield washer fluid • Acetone • Lacquer thinner acetone • Mek Chemical Hand Pump • Polypropylene construction • Nickel-plated steel rod • Fits 15- to 55-gallon drums • Viton® seals Applications • Detergents • Antifreeze • Acetone • Mild chemicals • Mild acids Guzzler® GH-0400N Food-Grade Hand Pump Also called the Guzzler® "2400". Pump is quoted with a silicone diaphragm, white handle, flapper style valve (white Nitrile Rubber), natural Delrin clevis and button assembly; no spring. • Versatile hand pump with wetted components made of FDA-approved materials • Ideal for pharmaceutical, food processing or biomedical applications • Accommodates ½" to 1" hose • Clamp ring adjusts to 12 different handle positions • Optional aluminum clamp ring for added durability • Maximum Service Temperature: 220°F • Maximum Pressure: 15 PSI • Lift: 12' / 22' with check valve • Volume Per Stroke: 0.44 quart PART # EACH BWG06001 $94.33 PART # EACH BWG03001 $106.92 10 GPM Guzzler® GH-0400P Polypropylene Hand Pump An all-polypropylene version of the standard Guzzler 0400 pump featuring excellent chemical resistance for a range of special fluid transfer needs. • Clamp ring adjusts to 12 different handle positions • Epoxy-coated aluminum clamp ring with stop brackets helps prevent pump over-stroking • Accommodates ½" to 1" hose • Maximum Service Temperature: 180°F • Lift: 12' / 22' with check valve • Volume Per Stroke: 0.44 quart 10 GPM PUMPS
15 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Ryton Rotary Chemical Drum Pump The National Spencer 1014R Rotary Drum Pump features Ryton construction with Viton® seals, making it great for pumping especially aggressive chemicals including chlorinated solvents, aromatic and aliphatic hydrocarbons, and alternative fuels. The 1014R rotary drum pump is lightweight,corrosionresistant and will dispense one gallon per 16 revolutions. • Dispenses 8-oz. per revolution • Lightweight and corrosion-resistant • Ryton construction • PTFE seals • Bung adapter (10217) • 1" Hose barb • ¾" Outlet BSP • 1.25" O.D. pick up tube Applications • Light Oil (Up to 30 wt) • Antifreeze • Windshield Washer Fluid • Methanol • Chlorinated Solvents PART # EACH NS1014R $124.59 Plastic Pail Pump • Low-cost polyethylene squeeze bulb pump • Fits 1-, 2½- and 5-gallon containers • Perfect for small carboys and cans • Siphon flow rate is approximately 2 GPM Pail Siphon Pump • Economical • All-polyethylene pump • Siphons 5 GPM • Bung adapter fits all 15-, 30- and 55-gallon containers with 2" IPS female threads. Drum Siphon Pump • Low-cost siphon pump • Use for 55-gallon drum applications • Use when entire contents need to be dispensed in one, simple application • Pumps 7 GPM, on average PART # EACH AP4007 $5.00 PART # EACH SNXSP606 $23.82 PART # EACH AP4005 $11.67 Applications • Industrial • Janitorial • Agrochemical • Farming 7 GPM 5 GPM 2 GPM GPM PART # EACH 8 NS1014 $83.10 Polypropylene Rotary Hand Pump • Polypropylene rotary pump is ideal for most organic acids, waxes, plating solution, detergents and water-soluble inorganic chemicals • Delivers 8 GPM • Includes 2" bung adapter • Pumps one gallon per 16 revolutions Polypropylene Chemical Pump National Spencer 375 is a lightweight and corrosion-resistant chemical pump. Dispenses maximum 12-oz. per stroke. The NS375 Drum Pump with telescoping suction tube fits 15- to 55-gallon drums. The adjustable bung adapter will fit 2" and 1¼" openings. • Includes 2" NPT bung adapter • One gallon per 10 strokes • FKM seals • For 15- to 55-gallon containers PART # EACH NS375 $48.00 Applications • Diesel Exhaust Fluids • Water-Based Fluids • Mild Acids • Alkali Solutions PUMPS
16 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Graco Fast-Flo 1:1 Air-Operated 5 GPM Piston Transfer Pump with 34.6 in. (Drum) Carbon Steel Tube Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 PSI (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options. Common applications: antifreeze, asphalts, windshield washer fluid, motor oil, used oil, hydraulic fluid, oil, inks, and colorants." • Air-powered for high reliability and low cost • Delivery up to 5 GPM (19 LPM) • Available in stainless steel or carbon steel • UL options available when installed in accordance with NFPA DRUM LENGTH WEIGHT FLOW-RATE TYPE PART # EACH 34.6 in 20 lbs 5 GPM 1:1 GR226947 $978.30 Graco Fast-Flo 1:1 Air-Operated 5 GPM Piston Transfer Pump with Stubby Carbon Steel Tube Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 PSI (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options. Common applications: antifreeze, asphalts, windshield washer fluid, motor oil, used oil, hydraulic fluid, oil, inks, and colorants. • Air-powered for high reliability and low cost • Delivery up to 5 GPM (19 LPM) • Available in stainless steel or carbon steel • UL options available when installed in accordance with NFPA DRUM LENGTH WEIGHT FLOW-RATE TYPE PART # EACH 7.1 in 11 lbs 5 GPM 1:1 GR226948 $835.00 Graco Fast-Flo 1:1 Air-Operated 5 GPM Piston Transfer Pump with 34.6 in. (Drum) SS Tube Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 PSI (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options. Common applications: antifreeze, asphalts, windshield washer fluid, motor oil, used oil, hydraulic fluid, oil, inks, and colorants. • Air-powered for high reliability and low cost • Delivery up to 5 GPM (19 LPM) • Available in stainless steel or carbon steel • UL options available when installed in accordance with NFPA DRUM LENGTH WEIGHT FLOW-RATE TYPE PART # EACH 34.6 in 20 lbs 5 GPM 1:1 GR237129 $1,936.40 Graco Fast-Flo 1:1 Air-Operated 5 GPM Piston Transfer Pump with Stubby SS Tube Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 PSI (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options. Common applications: antifreeze, asphalts, windshield washer fluid, motor oil, used oil, hydraulic fluid, oil, inks, and colorants. • Air-powered for high reliability and low cost • Delivery up to 5 GPM (19 LPM) • Available in stainless steel or carbon steel • UL options available when installed in accordance with NFPA DRUM LENGTH WEIGHT FLOW-RATE TYPE PART # EACH 9.8 in 11 lbs 5 GPM 1:1 GR237132 $1,857.80 PUMPS
17 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Flux F550S Industrial Positive Displacement Worm-Drive 12 GPM Drum Pump w/Direct Drive & 1.1 kW 1.5 HP Motor39 in. Tube The FLUX F550 S industrial eccentric progressive cavity worm -drive pump with bearing flange is suitable to pump thin to medium viscosity liquids. With the use of progressing cavity technology, this positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. The pump can be used in mobile and fixed installations. Includes a few number of components used for assembly, the pump can be easily dismantled, cleaned and serviced. • Positive displacement pump • Covers a wide range of viscosity • Smooth pumping of the liquid with very little shear • Continuous operation • Comprehensive modular system • Pump can be completely dismantled • Bearing flange between motor and shaft Flux F550GS Industrial Positive Displacement Worm-Drive 12 GPM Drum Pump w/Planetary Gear & F457 Electric Motor39 in. Tube The FLUX F55 GS industrial eccentric progressive cavity worm -drive pump has planetary gear suitable for pumping medium viscosity liquids. With the use of progressing cavity technology, this positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsationfree pumping. The pump can be used in mobile and fixed installations. Includes a few number of components used for assembly, the pump can be easily dismantled, cleaned and serviced. • Positive displacement pump • smooth pumping and with very little turbulence • Low pulsation in relation to the flow • Pump/shaft/worm can be dismantled • Comprehensive modular system for ease of maintenance • A wide range of viscosity can be covered • Transfer rate is maintained at a constant pressure • High efficiency pumping • Can be used in horizontal applications DRUM, TOTE, IBC SIZE WEIGHT FLOW-RATE PART # EACH 55 GAL 68 lbs 12 GPM FLXF550S54263911KW $4,743.15 DRUM, TOTE, IBC SIZE WEIGHT FLOW-RATE PART # EACH 55 GAL 22 lbs 12 GPM FLXF550GS542639F457 $4,348.77 PUMPS
18 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL BATTERY GPM PART # EACH 19.2-Volt Lithium 7 NS7019L $278.90 19.2-Volt NiCad 7 NS7019 249.39 19.2-Volt Rechargeable Battery-Operated Drum Pumps National Spencer Batter-Operated Drum Pumps are available with a 19.2-volt NiCad or a 19.2-volt lithium battery. The NiCad model pumps 106 gallons per charge while the lithium model pumps up to 137 gallons per charge. • Flow Rate: 7 GPM • Portable • Compatible with DEF, diesel, kerosene, detergents, antifreeze, chemical insecticides, and soaps • Includes stainless steel screened telescoping suction tube that extends from 33.5" to 40" 2" NPT bung adapter and a 2" buttress adapter for plastic drums a 79"-long corrugated P.E. hose and a polypropylene nozzle with a ¾" stainless steel spout, one battery, and one charger • Nozzle holster built into the pump body • Lithium Battery: 27.5 Wh with five cells per battery • Call for information and price on optional accessories Hand Pumps for Drums, Pails, Containers, and Totes Positive displacement piston with check valve to prevent back-flow of product (contamination) into the container for maintaining purity requirements. Non-drip nozzle can be easily removed for cleaning. PART # EACH SNDPNXF320 $28.11 PART # EACH SNDPNXF160 $39.69 DESCRIPTION PART # EACH Pump for 55-Gallon Drum SNDPNXM3NXM4200 46.01 PART # EACH SNDPNXM31BC Call 275 Gallon Pump With Measure Bottle Pump for 5-Gallon Drum/Pail Pump for 55-Gallon Drum Pump for 15-30 Gallon Containers Pump for 275-Gallon Tote With 570 X 6 Female Buttress Adapter With 560 x 6 Female Buttress Adapter With 2 in Male NPT Adapter With 2 in Male NPT Adaptor and 2 in Male Buttress Adapter PUMPS
19 PHONE: 800-333-3331| 24 HOUR FAX: 800-563-8848| WEB: JMESALES.COM/CHEMICAL Sotera™ Systems 12/24 Volt DC Chemical Pumps The 400B series of diaphragm pumps from Sotera™ Systems offers proven technology that combines the attributes of an airoperated diaphragm pump with the convenience, portability, and efficiency of an electric driven design. The 400B uses less power than other conventional chemical pumps for maximum efficiency. Direct current (DC) input for those applications out in the field. The one-way valve feature inherently conforms to the EPA’s 2011 mandate requiring that package designs don’t allow back filling of totes or drums. This unique design improves fluid-handling capabilities with low material sheering, solids handling up to 1/10", and dry-run capabilities. The power distribution is a unique reciprocating, spring-driven, double diaphragm configuration that retains constant pressure, regardless of the load. Motor amperage is actually reduced as back pressure increases. No internal bypass required—the pump automatically goes neutral when the end of hose valve is shut off. Nutating Disc Chemical Flow Meters Sotera Positive Displacement - Nutating Disc meter is ideal for end of hose use, in line or mounted to one of our Rotary Vane or 400B Series Diaphragm Pumps. It is able to store and display the current flow amount (total) or the cumulative flow amount (totalizer) in any of six user-specified units. The rugged corrosion-resistant body for the most demanding applications is easy to install with consistent accuracy up to ±0.2%. Battery powered, LCD display. 850 Series The 850 has a mass air sensor that distinguishes between fluid and air. That means the 850 stops metering when you’ve finished emptying a container, adding an extra degree of accuracy. • 2–20 GPM • Pressures up to 125 PSI max • -10° F to 130°F temperature range • 360° Positioning display • Quick, one-step calibration • Waterproof, corrosionresistant • Glass-filled polypropylene housing • 1 FNPT port • Fluorocarbon seals • LCD display • Two alkaline (AA) batteries included • 2–20 GPM flow • Pressures up to 120 PSI max • Mass air sensor • 1" FNPT ports • -10°F to 130°F temperature range • 360° Positioning display • Quick, one-step calibration • LCD display • Waterproof, corrosion-resistant • Fluorocarbon seals • Glass-filled polypropylene housing • Two alkaline AA batteries included PART # EACH TUFR210B $869.99 TUFR410BEXP MOTOR PART # EACH ¼ HP Motor TUFR410B $824.99 Ul, Explosion-Proof Motor TUFR410BEXP 844.99 DESCRIPTION PART # EACH 1" Flow Meter TU825 $174.99 1" Flow Meter with EPDM Gaskets for Lumax and Lexar TU825X700 174.99 PART # EACH TU850 $224.99 • 12-Volt DC motor • 2" Bung adapter • Hytrel diaphragms • Viton® seals • Glass-filled polypropylene housing • Thermal overload protection • 13 GPM and 15 PSI • 130°F max. temperature • 10' Suction lift • Up to 0.1" diameter solids • 1" x 12' Nitrile Rubber hose • Telescoping steel suction hose • Manual nozzle and nozzle boot 12-Volt DC Pump Units • Glass-filled polypropylene housing • UL listed, non-explosion proof motor • Thermal overload protection • Manual nozzle and nozzle boot • Telescoping steel suction tube • 1" x 12' Nitrile Rubber hose • 24-Volt DC motor • 2" Bung adapter • Hytrel diaphragms • Viton® seals • 13 GPM and 15 PSI • 10' Suction lift • 130°F max. temperature • Up to 0.1" diameter solids 24-Volt DC Pump Unit 825 Series PUMPS AND METERS
