Balcrank Lynx 3:1 Pump with Roth 165 Gallon Tank Package

SKU:
N/A
Manufacturer:
Tank Size:
165 Gal
Flow-Rate:
6.6 GPM
Type:
3:1 Pump System
Weight:
256.00 LBS
Please Choose An Option To See Price
$2,786.75 - $2,809.42
Balcrank Lynx 3:1 Pump with Roth 165 Gallon Tank Package

Balcrank Lynx 3:1 Pump with Roth 165 Gallon Tank Package

SKU:
N/A
Manufacturer:
Tank Size:
165 Gal
Flow-Rate:
6.6 GPM
Type:
3:1 Pump System
Weight:
256.00 LBS
Please Choose An Option To See Price
$2,786.75 - $2,809.42
Balcrank has partnered with Roth Industries to create the Balcrank/Roth Tank Packages. This package is suitable for storage and dispensing of DEF, diesel and bio fuels, motor oil and ATF or similar products up to SAE 90. This tank package includes a Lynx 3:1 Piston Pump and a double wall Roth tank with a four 2" FNPT bung openings. The Lynx 3:1 ratio double acting pump is engineered for outstanding performance and reliability to dispense lubricating oils and similar products up to SAE 90.

Features

Pump Features
  • Double acting pump moves product on both the up and down stroke providing smooth and reliable flow and pressure
  • Patented air valve is designed to operate with low air consumption and moist air
  • Air valve design has fewer components for reliable operation; easy and economical maintenance
  • Factory lubricated air motor needs no air lubricator
  • Built in sintered brass air filter assures clean and quiet operation
  • Anodized aluminum air piston is corrosion resistant, less sensitive to moisture in air system
  • Height adjustable 2 in. bung adapter fits all types of drums, drum covers, tanks, etc.
  • Pump inlet easily accepts a variety of extensions to fit all types and sizes of tanks and containers
Tank Features
  • Inner tank made of blow-molded, high-density, seamless polyethylene that is leak-proof and will never corrode
  • Outer tank is made of weld-free galvanized steel and roll seamed with an oil and fire-resistant seal
  • Outer tank holds 110 percent of inner tank for maximum protection
  • Extremely light, up to 50 percent lighter than conventional steel tanks
  • Can be used for DEF, diesel and bio fuels, motor oil and ATF
  • Compact, economical design (8 sq. ft. for 1000L)
  • Wide handles on each end allow you to transport and handle with ease
  • UL 2258 certified
  • Four 2 in. FNPT bung openings

Specifications

  • Tank Dimensions:
    • 5 ft. 1 in. H x 2 ft. 3.375 in. W x 2 ft. 5.375 in. L

Package Contents

  • Roth tank, double wall, 165 gallons
  • Hose Reel: Choice of Evolution series hose reel, 1/2 in. x 30 ft. or 50 ft.
  • Piston Pump: Lynx 3:1
  • DR hand w/flex-m ext. & 1/4 turn manual tip for oil
  • F/R auto drain 1/4 in. NPT(F)
  • 2.5 ft. reel inlet hose
  • 5 ft. air connecting hose
  • Air quick connect coupler & nipple
  • Sight gauge
  • Vented fill cap
  • Pump & reel bracket
  • Fully assembled (except the sight gauge)
